Property Type
float
raw
string
grade

Reader Properties

The following tables list the details of the reader properties.

ReaderProperties

Reader properties not tied to the actual decode result.
Property Type
string
name

Trigger

trigger
Statistics
stats
string
inputstr
Trigger
Describes the details of the initiating trigger event.
Property Type
integer
type
integer
index
integer
burstLength
interval integer
integer
delayType
integer
startDelay
integer
endDelay
creationTime integer
creationTicks integer
The raw metric.
The grade of quality in a range from grade A to F, where A is the highest.
The name of the device that decoded the image.
The details of Trigger property type are listed in the Trigger table below.
The details of the Statistics property type are listed in the Statistics table below.
This property serves the same function as the <Input String> data formatting token in
Standard Formatting: it holds the string that was sent to the reader via the InputString feature
(only configurable through DMCC).
These are the available trigger types:
single
l
presentation
l
manual
l
burst
l
self
l
continuous
l
The format of this property is "trigger.type.single".
The unique trigger identifier.
The number of images in case of burst trigger.
The trigger interval in microseconds.
These are the available trigger delay types:
none
l
time
l
distance
l
The format of this property is "trigger.delayType.none".
The trigger start delay in milliseconds (when using Trigger.delayTime.time) or
millimeters (when using Trigger.delayTime.distance).
The trigger end delay in milliseconds (when using Trigger.delayTime.time) or
millimeters (when using Trigger.delayTime.distance).
Creation time.
Encoder ticks corresponding to trigger signal time.
DataMan Application Development
Description
Description
Description
