DataMan
8072 Verifier
Quick Reference Guide
2019 October 08
Revision: 6.1.6SR1.5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DataMan 8072 Verifier and is the answer not in the manual?

Questions and answers

Summary of Contents for Cognex DataMan 8072 Verifier

  • Page 1 ® DataMan 8072 Verifier Quick Reference Guide 2019 October 08 Revision: 6.1.6SR1.5...
  • Page 2 MAY CAUSE SERIOUS INJURY. To reduce the risk of injury or equipment damage, observe the following precautions when you install the Cognex product: Route cables and wires away from high-current wiring or high-voltage power sources to reduce the risk of damage or malfunction from the following causes: over-voltage, line noise, electrostatic discharge (ESD), power surges, or other irregularities in the power supply.
  • Page 3: Product Overview

    Product Overview WARNING: LASER LIGHT, DO NOT STARE INTO BEAM Imager and Lens Optical System Illumination Removable Standoff Trigger (press and release) Lanyard hook Indicator light Communication module insertion point Status indicators: Communication: GREEN = good verification RED = bad verification...
  • Page 4 DataMan 8072 Verifier Kits The DataMan 8072 Verifier is available in the following kits: Model number Description DMV-8072V-S-0200 DataMan 8072 Verifier Ethernet Kit with Stand: - 8072 Verifier - Standoff - Ethernet Slide-In - Ethernet Cable Attachment - Standard Ethernet Cable...
  • Page 5 DataMan 8072 verifier and stand-off Ethernet or USB slide-in Stand accessory Calibration card...
  • Page 6 Serial/USB 2.0 Slide-In DMCM-USB2EN-00 Power Supply for USB 2.0 Slide-In DM100-PWR-000 POE hub CPS-AC-POE1A-US DMV-8072V-STAND Stand Accessory DMV-CCC Cognex Basic Calibration Card DMV-WCC GS1 Conformance Calibration Card DMV-GS1CC Validation Protocol DM8072V DMV-VPS-DPM Cables USB Cable for USB 2.0 Slide-In, 2.5 m DM8500-USBC-02...
  • Page 7 Connecting the Verifier 1. Connect the slide-in to the reader, and tighten the screws to lock the slide- 2. Insert the plug. Slide the cable lock up to the verifier, and twist the cable lock in place. Note: Disconnect the DataMan 8072V Verifier from power or remove the battery before inserting/removing the communication modules.
  • Page 8: Installation

    Installation procedures and specifications are presented in detail in the DataMan 8072 Verifier Reference Manual, which is installed with the DataMan Setup Tool. From the Windows Start menu, select the following to access the manual: All Programs > Cognex > DataMan Software vx.x.x > Documentation. Note: Cables are sold separately.
  • Page 9 DataMan 8072V Verifier Specifications 400 g (including grip assembly with battery) Weight Operating Temperature 0ºC — 45ºC (32ºF — 113ºF) 0ºC — 60ºC (32ºF — 140ºF) Storage Temperature Maximum Humidity 95% (non-condensing) Environemntal IP65 2-D barcodes: Data Matrix (IDMax and IDQuick: ECC200), QR Code Codes USB: bus powered (optionally: external 6W max LPS or NEC class 2 power supply +5V Power Supply...
  • Page 10 LED Wavelengths The following table shows LED types and the related wavelengths: λ [nm]...
  • Page 11 Please read these guidelines carefully before using your device. Note: For the most current CE declaration and regulatory conformity information, see the Cognex support site: cognex.com/support. Regulator Specification FCC Part 15B, Class A...
  • Page 12: Led Safety Statement

    Safety and Regulatory FCC Part 15, Class A This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 13: For European Community Users

    For European Community Users Cognex complies with Directive 2012/19/EU OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 4 July 2012 on waste electrical and electronic equipment (WEEE). This product has required the extraction and use of natural resources for its production.
  • Page 14 The crossed out wheeled bin symbol informs you that the product should not be disposed of along with municipal waste and invites you to use the appropriate separate take-back systems for product disposal. If you need more information on the collection, reuse, and recycling systems, please contact your local or regional waste administration.
  • Page 15 中 国 大 陆 RoHS (Information for China RoHS Compliance) 根 据 中 国 大 陆 《 电 子 信 息 产 品 污 染 控 制 管 理 办 法 》 ( 也 称 为 中 国 大 陆 RoHS), 以...
  • Page 16 Copyright © 2019 Cognex Corporation. All Rights Reserved.
