- Page 1 COGNEX ® DataMan ® Quick Reference Guide...
-
Page 2: Setting Up Your Dataman
Getting Started Section Title Page 2 • General Information and Imager Specifications • For Page 4 More Information • DataMan 60 Systems • Reader Layout • DataMan 60 Accessories Setting Up Your DataMan Setting the Focus Position • Field of View and Reading Page 11 Distances •... - Page 3 Release Notes list detailed system requirements and additional information about this DataMan software release. Image Acquisition up to 60 fps at full resolution Cognex->DataMan Software v x.x->Documentation->DataMan v x.y.z Release Notes Lens Type 3 focal position M12 lens 4 DataMan 60 Quick Reference Guide...
- Page 4 DataMan 60 Systems DataMan 60 Reader Layout The following image shows the characteristics of the DataMan 60 reader. Omni-directional IDQuick™ — 1DMax+™ with 1-D Code Reading HOTBARS™ Well marked 2-D Code 3-position Reading lens cap DataMan 60L √ (DMR-60L-00) Focal position indicator Internal DataMan 60QL...
-
Page 5: Dataman 60 Accessories
DataMan 60 Reader Layout (Continued) DataMan 60 Accessories CABLES USB Cable, 1.5 m (DM100-USB-000) Ethernet RJ-45 USB Cable, 3 m connector (DM100-USB-030) USB & Flying Leads I/O Cable, 2.0 m (DM-USBIO-00) Directly connected cable RS-232 Cable, 1.5 m terminating in a (DM100-RS232-000) DB15 connector Extension Cable, 5 m... -
Page 6: Setting The Focus Position
DataMan 60 Accessories (Continued) Setting the Focus Position POWER SUPPLY DataMan 60 can operate in one of three distance ranges. To set the Power Supply, 6V focus position: (DM100-PWR-000) Remove lens cover. MOUNTING BRACKETS Pivot Mounting Bracket (DM100-PIVOTM-00) Universal Mounting Bracket (DM50-UBRK-000) CONTROL BOX Control Box (DM-CTRLBOX-00) -
Page 7: Field Of View And Reading Distances
Field of View and Reading Distances This chart shows the horizontal field of view for the DataMan 60 at a range of This chart shows the supported range of reading distances at 70 mm working distances, together with the supported range of reading distances at focus position. - Page 8 Field of View and Reading Distances (Cont.) Dimensions Observe the following DataMan 60 reader dimensions when installing This chart shows the supported range of reading distances at 110 mm focus your reader. position. 31.75mm 40.96mm 1.25in 1.61in 110 mm 29.71mm 10 mil 58-121 mm (2.2-4.7 in) 1.17in 12 mil 54-133 mm (2.1-5.2 in)
-
Page 9: Installing Dataman Software And Connecting The Reader
1. Check the DataMan Release Notes for a full list of system 0.93in requirements. 2. Download the DataMan Setup Tool from http://www.cognex.com/ support/dataman and follow the on-screen steps. 3. Connect the DataMan 60 reader to your PC. 4. Launch the Setup Tool and click Refresh. -
Page 10: Troubleshooting An Ethernet Connection
Troubleshooting an Ethernet Connection Industrial Protocols Based on your network configuration, the Setup Tool may not be able to The DataMan 60 supports the following industrial protocols: communicate with the reader and it will not appear in the list of Network •... -
Page 11: External Triggers
If you are using external triggering you can use any of these methods to DataMan 60 readers support the following trigger modes: trigger your DataMan 60 series reader: • Self: At an interval you configure, the reader automatically detects • Send a pulse on the I/O cable: and decodes codes in its field of view. -
Page 12: Multi-Reader Triggering
I/O Cable Multi-Reader Triggering The I/O cable provides access to trigger and high-speed outputs. Unused wires can be For trigger modes other than Presentation, the DataMan 60 supports clipped short or tied back using a tie made of non-conductive material. multi-reader triggering, also known as master-slave configuration. - Page 13 USB & Flying Leads I/O Cable RS-232 & Flying Leads I/O Cable You can connect a cable with USB & flying leads to the cable that is attached You can connect a cable with RS-232 & flying leads to the cable that is to the device.
-
Page 14: Flying Leads Cable
Flying Leads Cable Digital Input Lines You can connect a cable with flying leads to the cable that is attached to the Inputs are not galvanic isolated but need to be referenced to ground. device. The following table shows the pinout and color description of the flying leads. -
Page 15: Digital Output Lines
External Wiring Examples: Digital Input Digital Output Lines Lines (Continued) The digital outputs can be used as either NPN (pull-down) or PNP (pull- up) lines. For NPN lines, the external load should be connected between DM60 the output and the positive supply voltage (<24V). The outputs pull down to less than 3V when ON, which causes current to flow through the load. - Page 16 External Wiring Examples: Digital Output Digital Output Lines (Continued) Lines PNP (pull up) output type characteristics are the following: Output voltage range 24V or less Residual voltage 0.8V or less Maximum source current 25mA Short-circuit current 50mA or less DM60 Short-circuit protection multifuse - 50mA 50 mA...
- Page 17 External Wiring Examples: Digital Output Illumination Strobe Output Lines (Continued) The strobe output is provided by a diode that is added to the push-pull circuit, with series to the pull-up transistor. This diode blocks the higher voltage when the output is pulled up when used as open-collector type Output driving, but enables the driving of high level in TTL mode.
- Page 18 Illumination Strobe Output (Continued) External Load Strobe Output The following figure shows the wiring diagram of the illumination strobe output. +5VDC LOAD 50 mA Output-Strobe DM60 ESD Protection Strobe (Internal signal) DM60 50 mA LOAD 34 DataMan 60 Quick Reference Guide DataMan 60 Quick Reference Guide...
-
Page 19: Multi-Port Connections
2: Tx Data 3: Rx Data 5: GND Because of the large number of possible configurations, Cognex does not supply cabling for multi-port DataMan 60 connections. Instead, you must construct your own cable that meets the requirements of your system configuration. - Page 20 Configuring for Multi-Port Operation Multi-Port Usage Notes You must connect the Setup Tool to each DataMan 60 in turn and enable multi- You can obtain the best results when using multi-port connections by port operation. Click the Communication Settings task and check the Enable keeping the following usage guidelines in mind as you design your Multi-Port (RS-232 Sharing) check box.
-
Page 21: Dataman 60 Specifications
Warnings and Notices DataMan 60 Specifications Weight NOTE: For product support, contact http://support.cognex.com 76 g (including cable) Operating Temperature 0ºC — 40ºC (32ºF — 104ºF) CAUTION: IP protection is ensured only when all connectors are attached to cables or shielded by a sealing cap. -
Page 22: Compliance Statements
A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equip- Cognex Corporation shall not be liable for use of our product with equip- ment is operated in a commercial environment. This equipment generates, ment (i.e., power supplies, personal computers, etc.) that is not CE... - Page 23 Compliance Statements (Continued) This product has required the extraction and use of natural resources for its production. It may contain hazardous substances that could impact health and the environment, if not properly disposed. In order to avoid the dissemination of those substances in our environment and to diminish the pressure on the natural resources, we encourage you to use the appropriate take-back systems for product disposal.
-
Page 24: Reader Programming Codes
Reboot Scanner Factory Defaults Copyright © 2015 Cognex Corporation All Rights Reserved. This document may not be copied in whole or in part, nor transferred to any other media or language, without the written permission of Cognex Corporation. The hardware and portions of the software described in this document may be covered by one or more of the U.S.
