Note: The following TruCheck metrics are only available for devices with TruCheck verifier capability, such as the
DM475 Verifier and the DM8072 Verifier.

TruCheckMetric

A graded verification parameter that has a measurement associated with it.
Property Type
grade string
raw float
numericGrade
float

TruCheckMetricGradeOnly

A graded verification parameter that has a measurement associated with it.
Property Type
grade string
numericGrade float

TruCheckApplicationStd

Property Type
grade
string The data title for each section of the parsed data.
data string The raw parsed data.
check string A Pass/Fail assessment determined by the specific application standard selected.

TruCheckCodeword

Property Type
codeword integer
isCorrected boolean Returns a 0 if the codeword is not corrected using error correction; returns a 1 if the codeword
TruCheckEncodationAnalysis
Property Type
name string
mode
string
result string
TruCheckMetricGeneral
Property
contrastUniformity integer The contrast uniformity value is the minimum modulation of any codeword according
horizontalBWG
MRD
verticalBWG
xDimension
TruCheckMetricModulation
The grade of quality in a range from grade A to F, where A is the highest.
The raw metric.
The continuous grade value as shown in ISO 15416:2016.
The grade of quality in a range from grade A to F, where A is the highest.
The continuous grade value as shown in ISO 15416:2016.
Outputs the codewords associated with the parsed data.
is corrected using error correction.
Outputs the codeword for the parsed data.
Outputs the encodation mode in effect.
Outputs the raw data decoded.
Type
to ISO 15415.
integer Print growth in the horizontal axis.
integer Minimum difference between the brightest bar and the darkest space within the
symbol.
integer Print growth in the vertical axis.
float The normal cell size spacing in mils (thousandths of an inch).
