Specifications
Table Event Input (AWG5012B option 09)
Characteristic
Number of Event Jump
destination
Strobe
Minimum pulse width
Latency to analog output,
typical
Hold off time, typical
TTL Event to TekLink LVDS Connector Adapter User Manual
Description
Up to 16
On/Off selectable
64 ns
Max 650 ns @1.2 Gsps
Max 1300 ns @650 Msps
From D-type connector on the TTL to LVDS converter to Analog output when Asynchronous
Jump is selected
Maximum 500 sample clock cycles (when Asynchronous Jump is selected)
