Connecting Cables
NOTE.
Before connecting the following cables, power off your instrument. The power is supplied from your AWG5012B through a
TekLink cable.
1. Connect a TTL-level signal to the Table
Event Input connector.
2. Use a TekLink cable to connect the
connector adapter and your AWG5012B.
TTL Event to TekLink LVDS Connector Adapter User Manual
Installation
5
