Preface
This manual describes the installation and
operation of the TTL Event to TekLink LVDS
Connector Adapter. The connector adapter
converts a TTL signal to an event signal for the
AWG5012B arbitrary waveform generator.
Key Features
The AWG5012B Option 09 supports the following features:
Subsequence
Table jump
NOTE.
The AWG software must be version 3.3 or later to enable the Option 09 features. To check the software version of your
AWG5012B, select Help > About Tektronix AWG... from the menu bar.
TTL Event to TekLink LVDS Connector Adapter User Manual
AWG5012B (TekLink connector)
TTL to LVDS
Generator (TTL signal)
converter box
Preface
ix
