Installation
Unpack the connector adapter and check that you received all of the items listed below as parts list. Check the Tektronix Web
site (www.tektronix.com) for the most current information.
Products
The TTL Event to LVDS Connector Adapter can be used only with the AWG5012B.
AWG5012B Option 09, Subsequence and Table Jump
AWG50BUP Option S39, Upgrade to Option 09 for the AWG5012B
Parts List
Table 1: AWG5012B Option 09
Description
Converter Box, TTL Event to LVDS TekLink
Connector Adapter
TekLink Cable, 200 cm
User Manual, printed
TTL Event to TekLink LVDS Connector Adapter User Manual
Part number
850-0108-xx
174-5019-xx
071-2674-xx
Installation
Quantity
1 each
1 each
1 each
1
