Getting Started

Product Description

80A05 Electrical Clock Recovery Module User Manual
The Tektronix 80A05 Electrical Clock Recovery Module will recover the clock
from electrical data for all Tektronix electrical modules. The 80A05 Electrical
Clock Recovery Module provides a solution for triggering the mainframe from
single-ended or differential electrical signals. The 80A05 can also be used as a
general purpose clock recovery solution.
NOTE. Proper operation of the 80A05 module requires that the operating system
software installed on the main instrument is version 2.0 or greater. To display
the version installed, select About TDS/CSA8000 from the Help menu in the
user interface.
The module provides the characteristics shown in Table 1. See Specifications for
a full list of product specifications.
Table 1: 80A05 module characteristics
Characteristic
Number of inputs
Input/output impedance
Input/output connectors
Input/output coupling
Recovered clock timing jitter
Maximum input voltage
Analog bandwidth
Minimum clock recovery sensitivity
CAUTION. To prevent electrostatic damage to the CSA/TDS8000 Series instru-
ment and modules, follow the precautions described in this manual and the
manuals accompanying your instrument.
(See Electrostatic Discharge starting on page 5.)
Value or description
2
50 Ω
SMA
DC
50 Mb/s to 2.7 Gb/s: 0.5% of unit interval
2.0 V
p-p
3dB to 20 GHz
8 mV
p-p
