Getting Started
2
There are five (six, Option 10G) identical SMA female connectors on the front
panel: two data inputs, two data outputs, one TRIGGER CLOCK output, and
one 10G CLK output (Option 10G). Refer to Figures 2 and 3 on page 8.
The module receives power through the Tekprobe- -Sampling interface. The
Power LED indicates the clock recovery circuitry is on and programmed to the
requested bit rate.
CAUTION. To prevent electrostatic damage to the 8000 Series instrument and
module, follow the precautions described in this manual and the manuals
accompanying your instrument. (See Electrostatic Discharge starting on
page 5.)
80A05 Electrical Clock Recovery Module User Manual
