Specifications

80A05 Electrical Clock Recovery Module User Manual
This section contains specifications for the 80A05 Electrical Clock Recovery
Module. All specifications are guaranteed unless noted as "typical." Typical
specifications are provided for your convenience but are not guaranteed.
All specifications apply to all models of module unless noted otherwise. To meet
specifications, three conditions must first be met:
H The instrument must have been calibrated/adjusted at an ambient tempera-
ture between +20 _C and +30 _C.
H The oscilloscope must have been operating continuously for 20 minutes
within the operating temperature range specified.
H The instrument must be in an environment with temperature, altitude, and
humidity, within the operating limits described in these specifications
Table 4: Module characteristics
Specifications Characteristics
Mainframe interface Tekprobe-Sampling, Level 3. Hot switching is not permitted.
Number of inputs 2
Input and output SMA
connectors
Data input/output DC
coupling
Maximum Either inputs: 2.5 V
non-destruct range
Maximum operating Single-ended operation:
range Either input: 2.0 V
Maximum operating Complementary operation:
range Each input: 1 V
±2.0 VDC
Maximum DC offset
Electrical Return Loss Data in+, data in- - ,data out+, data out- - :
15dB or better
Data in+, data in- - ,data out+, data out- - :
10dB or better
DC to 12.5 GHz: 6.6 dB ±0.6 dB
Electrical data attenu-
ation
Propagation delay Either inputs:
875 ps
Propagation Delay Either inputs:
mismatch <15 ps
pk-pk
pk-pk
pk-pk
DC to 10GHz
10GHz to 20GHz
11
