BSP Firmware Download
Download and unzip the
Board Support Package
Hardware Setup
1. Open the virtual COM (VCOM) function by changing Nu-Link2-Me VCOM Switch No. 1 and 2 to
ON.
2. Connect the ICE USB connector shown in Figure 4-4 to the PC USB port through USB cable.
Mar.
08, 2021
(BSP).
Figure 4-3 Open VCOM Function
Figure 4-4 ICE USB Connector
Page 25 of 38
NuMaker-ML51SD
Rev 1.01
