  • Page 1 AM100 Series User Guide Milesight IoT...
  • Page 2 Do not place the device close to objects with naked flames, heat source (oven or sunlight), cold source, liquid and extreme temperature changes. The device is not intended to be used as a reference sensor, and Milesight will not should ...
  • Page 3 For assistance, please contact Milesight technical support: Email: iot.support@milesight.com Tel: 86-592-5085280 Fax: 86-592-5023065 Address: 4/F, No.63-2 Wanghai Road, Software Park, Xiamen, China Revision History Date Doc Version Description Apr. 7, 2020 V 1.0 Initial version May 19, 2020 V 1.1 App pictures replacement Aug.

  • Page 4: Table Of Contents

    5.1 Installation Note..........................21 5.2 Wall Mounting..........................22 6. Milesight IoT Cloud Management......................22 6.1 Add a Milesight Gateway......................22 6.2 Add AM104/AM107 to Milesight IoT Cloud................24 7. Device Payload............................25 7.1 Basic Information..........................25 7.2 Sensor Data............................25 7.3 Downlink Commands........................26 Appendix...............................

  • Page 5: Product Introduction

    LoRaWAN ® enables encrypted radio transmissions over long distance while consuming very little power. The user can obtain sensor data and view the trend of data change through Milesight IoT Cloud or through the user's own Network Server. 1.2 Features Robust LoRa connectivity for indoor or HVAC environments ...

  • Page 6: Hardware Overview

    ⑤Light Sensor Back Panel: ⑥Power button ⑦Battery Cover ⑧Mounting Holes ⑨Type-C Port 2.3 E-link Screen 2.3.1 Screen Description AM100 series provide 3 types of display modes: AM104 Mode 1 Mode 2 Mode 3 AM107 Mode 1 Mode 2 Mode 3...
  • Page 7 To learn what an icon means, find it below. Icon Description Screen Update Battery level 24 hours Sync time with software or mobile App 1 min The device joins the network. According to join status The device fails to join the network. Temperature 1 min Humidity...

  • Page 8: Screen Mode Switch

    Show alarm when CO exceeds the threshold value.(1200 ppm by default) Note: AM100 series will do a full-screen refresh every 30 minutes in order to remove ghosting.  Please refer section 4.5.3 for TVOC and CO threshold settings.  AM100 series shows current value on the screen and uplink the average value of the ...

  • Page 9: Power Supply

    Remove the battery cover and install two new AA/LR6 batteries. Batteries can be replaced on the fly. Note: AM100 series can also be powered by type-C USB port (5V, 100mA). When batteries and  external power are both connected, external power will power the device first.
  • Page 10 1) Ensure the location of smartphone NFC area and it’s recommended to take off phone case. 2) If the smartphone fails to read/write configurations via NFC, keep the phone away and back to try again. 3) AM100 series can also be configured by dedicated NFC reader, which can be purchased from Milesight IoT.

  • Page 11: Usb Configuration

    ToolBox: V6.8 and above  Steps: 1. Download ToolBox from Milesight IoT website. 2. Connect the device to computer via type-C port. 3. Open the ToolBox and select type as “General”, then click password to log in ToolBox. (Default password: 123456) 4.

  • Page 12: Lorawan Settings

    4.2 LoRaWAN Settings LoRaWAN settings is used for configuring the transmission parameters in LoRaWAN network. ® Step 1: Go to “LoRaWAN Settings -> Basic” of ToolBox software or “Device->Setting->LoRaWAN Settings” of ToolBox App to configure join type, App EUI, App Key and other information. You can also keep all settings by default.
  • Page 13 1) Please contact sales for device EUI list if there are many units. 2) Please contact sales if you need random App keys before purchase. 3) Select OTAA mode if you use Milesight IoT cloud to manage devices. 4) Only OTAA mode supports rejoin mode.
  • Page 14 If frequency is one of CN470/AU915/US915, you can enter the index of the channel that you want to enable in the input box, making them separated by commas. Examples: 1, 40: Enabling Channel 1 and Channel 40 1-40: Enabling Channel 1 to Channel 40 1-40, 60: Enabling Channel 1 to Channel 40 and Channel 60 All: Enabling all channels Null: Indicates that all channels are disabled...

  • Page 15: Time Synchronization

    4.3 Time Synchronization Mobile App Configuration: Open Toolbox App and go to “Device ->Status”to click “sync” to sync the time on the screen. Software Configuration: Log in Toolbox and go to “Status” page to sync the time on the screen.

  • Page 16: Basic Settings

    4.4 Basic Settings Go to “Device Settings->Basic” of ToolBox software or “Device->Setting->General Settings” of ToolBox App to change the reporting interval, screen mode, etc. Parameters Description Reporting interval of transmitting data to network server.Default: 600s Reporting Interval Note: RS232 transmission will not follow the reporting interval. Change the temperature unit displayed on the ToolBox and screen.

  • Page 17: Calibration Settings

    4.5.2 Calibration Settings ToolBox supports numerical calibration for all items. Go to “Device Settings->Basic” of ToolBox software or “Device->Setting->Calibration Settings” of ToolBox App to type the calibration value and save, the device will add the calibration value to raw value. Besides numerical calibration, ToolBox provides more calibration methods for CO Manual Calibration: Put the device in an open outdoor environment more than 10 minutes and click this button to calibrate the CO...

  • Page 18: Threshold Settings

    4.5.3 Threshold Settings AM100 series will upload the current data instantly after the threshold is triggered. AM107 will also show alarms of CO and TVOC on the screen. Go to “Device Settings->Basic” of ToolBox software or “Device->Setting->Threshold Settings” of ToolBox App to enable the threshold settings and input the threshold.

  • Page 19: Backup

    Step 2: Click “Up to date” to search for latest firmware of devices. If your firmware is latest version, ToolBox will prompt “Your device is up to date”. Note: Any operation on ToolBox is not allowed during upgrade. 4.6.2 Backup AM100 devices support configuration backup for easy and quick device configuration in bulk.

  • Page 20: Reset To Factory Default

    Note: Slide the template item left to edit or delete the template. Click the template to edit the configurations. 4.6.3 Reset to Factory Default Please select one of following methods to reset device: Via Hardware: Hold on power button more than 10s. Via ToolBox Software: Go to “Maintenance->Backup and Reset”...

  • Page 21: Installation

    In order to ensure the best detection and LoRaWAN ® communication effect, it is recommended to install AM100 series as follows: There should not be any isolates or barriers in PIR and light detection range.  Do not mount the device where the temperature is below/above operating range and ...

  • Page 22: Wall Mounting

    4. Mount the device on the wall. 6. Milesight IoT Cloud Management AM100 series can be managed by Milesight IoT Cloud platform. Milesight IoT cloud is a comprehensive platform that provides multiple services including device remote management and data visualization with the easiest operation procedures. Please register a Milesight IoT Cloud account before operating following steps.
  • Page 23 Step 2: Go to “My Devices” page and click “+New Devices” to add gateway to Milesight IoT Cloud via SN. Gateway will be added under “Gateways” menu. Step 3: Check if gateway is online in Milesight IoT Cloud.

  • Page 24: Add Am104/Am107 To Milesight Iot Cloud

    Step 1: Go to “My Devices” page and click “+New Devices”. Fill in the SN of device and select associated gateway. Step 2: After the device is online in Milesight IoT Cloud, you can check the data via webpage or mobile App and create dashboard for it.

  • Page 25: Device Payload

    18 (Sensor Status) 00 7f 7f=>0111 1111 means all sensors are open 7.2 Sensor Data AM100 series sensors report sensor data according to reporting interval (10min by default). Battery level is reported every 24 hours. Channel Type Data Example Description 64=>100...

  • Page 26: Downlink Commands

    TVOC = 7 ppb 73（Barometric 68 27=>27 68=10088 68 27 Pressure） Pressure=10088*0.1=1008.8hPa 7.3 Downlink Commands AM100 series sensors support downlink commands to configure the device. Application port is 85 by default. Channel Type Data Example Description 03(Set Reporting Interval) b0 04 b0 04 =>...
  • Page 27 Workplace exposure limit (as 8-hour TWA) in most 5000ppm jurisdictions. Exposure may lead to serious oxygen deprivation >40000ppm resulting in permanent brain damage, coma, even death. -END-...
