- Page 1 INSTRUCTION MANUAL MODEL 7360V VERTICAL CURING CHAMBER Revision G– APRIL 2021 98-0520 ____________ 2001 N. Indianwood Ave. Tulsa, Oklahoma 74012 U.S.A. TEL: (918) 250-7200 • FAX: (918) 459-0165 E-mail: chandler.sales@ametek.com Website: www.chandlereng.com...
- Page 2 This publication contains the following trademarks and/or registered trademarks. AMETEK, CHANDLER ENGINEERING. These trademarks or registered trademarks and stylized logos are all owned by AMETEK, Inc. All other company, product and service names and logos are trademarks or service marks of their respective owners.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Table of Contents General Information ............... P-1 Initial Inspection ..........................P-1 Features ..............................P-1 High Temperature Alarm ......................... P-1 Specifications ............................P-1 About the High Pressure Seal ......................P-2 Where to Find Help ..........................P-3 Section 1 - Installation ..............1-1 Site Requirements .......................... - Page 4 T-i i TABLE OF CONTENTS Section 4 - Maintenance and Servicing ...........4-1 Maintenance ............................4-1 Troubleshooting ........................... 4-1 Section 5 – Replacement Parts ............5-1 Section 6 - Drawings and Schematics ..........6-1...
-
Page 5: General Information
PREFACE General Information Initial Inspection The Model 7360V Vertical Curing Chamber was tested and inspected before the unit was shipped from Chandler Engineering. The curing chamber was run through a typical temperature and pressure profile prior to shipment. Carefully uncrate and inspect the curing chamber and any accessories. -
Page 6: About The High Pressure Seal
PREFACE Heater power: 3000 Watts Heater type: External, 2 piece, mica band-heater Heater control: Solid-state relay with temperature feedback Power Requirements Input voltage: 220 ± 10% VAC, single phase Input power: 3.2 kVA Input frequency: 50 or 60 Hz Mechanical Height: 20 in/51 cm Width:... -
Page 7: Where To Find Help
Metal Seal Where to Find Help In the event of problems, the local sales representatives will be able to help or the personnel at Chandler Engineering can be contacted. • Telephone: 918-250-7200 • FAX: 918-459-0165 • E-mail: chandler.sales@ametek.com • Website: www.chandlereng.com... -
Page 9: Section 1 - Installation
SECTION 1 - INSTALLATION Section 1 - Installation Site Requirements This instrument has been designed with operator safety as a primary consideration. The following safety procedures are recommended to help ensure safety for both operator and other laboratory personnel. • Locate the instrument in a low traffic area. •... -
Page 10: Connecting Power To The Curing Chamber
INSTALLATION Connecting Power to the Curing Chamber This instrument operates on 220 ± 10% VAC, 50 or 60 Hz, single phase, 15A electrical current. The instrument is equipped with a power cord and should be connected to an appropriately rated power source. (The earth ground connection on the rear of the instrument should be connected to a metal water pipe, a metal rod driven in the ground, or other appropriate earth ground.) Note: Remove ALL power connections from the unit before opening the covers or... -
Page 11: Section 2 - Curing Chamber Controls
SECTION 2 – CURING CHAMBER CONTROLS Section 2 - Curing Chamber Controls Safety Procedures The following safety procedures are recommended to help ensure operator safety: • Read and understand the instructions before operating the instrument. • Never exceed the temperature or pressure ratings listed on the front panel. •... -
Page 12: Drain Cylinder/Fill Cylinder Switch
CURING CHAMBER CONTROLS Please refer to the 9050,9051,9060,9061,9080,9081 Controller manual for detailed instructions on the operation of the temperature controller. Drain Cylinder/Fill Cylinder switch The DRAIN CYLINDER/FILL CYLINDER switch is used to fill the cylinder with water or to remove water from the cylinder. When the switch is in the FILL CYLINDER position, the cylinder will fill with water. -
Page 13: Pump Pressure Adjust Regulator
SECTION 2 – CURING CHAMBER CONTROLS from exceeding the set point. Maintaining the pressure above a certain level can be done by adjusting the PUMP PRESSURE ADJUST regulator. Pump Pressure Adjust Regulator The PUMP PRESSURE ADJUST regulator is used to control the maximum pressure of the hydraulic pump. -
Page 15: Section 3 - Operation
SECTION 3 – OPERATION Section 3 - Operation Preparation of Cement Sample Assemble two side plates, one bottom plate, two end plates, and three partitions of the mold assembly. Do not over-tighten nuts. Fill the greased molds with cement slurry prepared in accordance with API Specification 10, Specification for Materials and Testing for Well Cements. -
Page 16: Temperature Control
SECTION 3 - OPERATION Temperature Control Complete instructions on the programming and operation of the Temperature Controller can be found in the 9050,9051,9060,9061,9080,9081 Controller manual. Pressure Control 1. Turn the HIGH PRESSURE LIMIT REGULATOR knob all the way in (clockwise). 2. -
Page 17: Running The Test
SECTION 3 – OPERATION Running the Test If necessary, press the RESET button to reset the TEMPERATURE LIMIT ALARM. Make certain the FILL CYLINDER switch is in the ON position; the HEATER switch is in the ON position; and the COOL CYLINDER switch is in the OFF position. Also make certain the CYLINDER DRAIN valve is closed and the cylinder is filled with water. -
Page 18: Draining The Cylinder
SECTION 3 - OPERATION 6. When the cylinder has cooled below 200°F/93°C the PRESSURIZE CYLINDER switch may be turned to the OFF position and the CYLINDER DRAIN valve may be opened which will allow water to circulate through the cylinder for more rapid cooling. 7. -
Page 19: Section 4 - Maintenance And Servicing
SECTION 4 – MAINTENANCE AND SERVICING Section 4 - Maintenance and Servicing The 7360V Curing Chamber was designed to require little maintenance and servicing. The following guidelines are recommended to help insure years of trouble free service. In the event a problem occurs, a troubleshooting guide is listed following the maintenance guidelines. - Page 20 MAINTENANCE AND SERVICING TROUBLESHOOTING Symptom Possible Cause Remedy Heater will not operate Temperature Limit Find cause and correct, Alarm press reset Open circuit in heater Find and eliminate open wiring circuit Instrument not receiving Instrument not plugged in Plug into appropriate power outlet Blown fuse on rear panel...
-
Page 21: Section 5 - Replacement Parts
SECTION 5 – REPLACEMENT PARTS Section 5 – Replacement Parts Part Number Description 04237-24 Fuse Holder 19-0057 Thermocouple Assembly 07-0454 Cooling Coil Seal, Copper 7750-0213 Rear Cover 7750-0232 Front Cover 98-0103 Cylinder Plug 98-0106 Cylinder 98-0112 Seal Ring 98-0117 Cooling Coil, Cylinder Assembly 98-0210 Mold Assembly 98-0500... -
Page 23: Section 6 - Drawings And Schematics
SECTION 6 – DRAWINGS AND SCHEMATICS Section 6 - Drawings and Schematics Drawing Number Description 98-0006 Piping Schematic 98-0518 Wiring Diagram... - Page 24 CHANDLER ENGINEERING...
- Page 26 cut out postcards on dotted lines Please Send Us Your Comments on This Manual Model Number ____________________________ Serial Number __________________________ Printing Date of this manual (from the Title Page) ______________ Please circle a response for each of the following statements. Use: (1)= Strongly agree (2) =Agree (3) =Neutral, no opinion (4) =Disagree (5) =Strongly disagree a) The manual is well organized.
- Page 27 cut out postcards on dotted lines...
- Page 28 4903 W. Sam Houston Parkway, N., Suite A-400, Houston, TX 77041 2001 North Indianwood Avenue, Broken Arrow, OK 74012 Tel: +1 713-466-4900 Fax: +1 713-849-1924 Tel: +1 918-250-7200 Fax: +1 918-459-0165 e-mail: chandler.sales@ametek.com www.chandlereng.com Printed in the U.S.A. © 2008, by AMETEK, Inc. All rights reserved. XM808PDF (360000)
