Cascade iForks User Manual page 13

C
HARGING BATTERIES
3 4
6 M3×25
Place 4 full D-cell batteries in each batterypack. Replace the top housing of the battery
pack and tighten the 6 Phillips-head screws M3 x 25 (not to tight).
10
4
Replace the battery packs of the iForks
5 若电池是可充电式的，可对其
Charge the rechargeable battery packs (option).
The system additionally can be equipped with rechargeable battery packs and a charger. Charge the battery
for at least 8 hours. This will prevent loss of battery capacity. Check by reading the battery-pack label to make
sure this battery pack is equipped with rechargeable batteries. Only battery packs with rechargeable D-cells can
be re-charged.
1
2
3
First position the battery pack inside the charger module, then plug the adaptors into the mains voltage.
When the battery is being charged, the red LED on the charger is lit. After at least 8 hours charging,
the battery packs are full again. The red LED will stay on, even when the battery packs are fully charged.
8
4
8
8
8 hours
