C
HARGING BATTERIES

Low Battery Indication iForks

Exchangeable battery packs supply power to the iForks .
When the voltage level of the battery packs is running low, the low bat indicator will light up and the pointer of the relating fork - "F1", "F2" or both - will start blinking in
the display. The blue LED's on the relating fork will start blinking very slowly (twice every 10 sec). The iForks will switch off automatically after 10 minutes.
8
货叉系统
LED 10
NET
e1 e2 e3 F1 F2
ID CODE PT TOTAL PCS KG/LB
CLR
蓝色 LED 灯功能介绍 FUNCTIONALITY BLUE LED
DURING POWERING ON
电量充足 FULL BATTERY
Working Mode
Sleep Mode
电量不足 Low BATTERY
Working Mode
Sleep Mode
F1
2 10
货叉
5 ON for 5 sec.
Blink Time Interval
1.5 Once every 1.5 sec.
4 Once every 4 sec.
10 Once every 10 sec.
10 Once every 10 sec.
F2
