Monogram ZV48R Installation Instructions Manual page 12

2A
INSTALL HOOD ONTO WALL
SKIP THIS STEP IF INSTALLING BENEATH A
SOFFIT OR CABINET, GO TO STEP 2B.
below the 20" marked line.
20"
Bottom
of
Hood
using at least 2 of the 4 supplied long screws.
IMPORTANT: Screws must penetrate at least 1-1/2" into
vertical studs. Countersink screws into support.
NOTE: The mounting screws must remain in their
original shipping location. These screws are positioned
to engage the keyhole slots in the back of the hood.
1/4"
Gap
support until they protrude 1/4" forward. This 1/4" gap
will provide clearance to hang the hood.
IMPORTANT:
supporting up to 150 lbs.
12
Installation Instructions
Wood
Support
Centerline of
Installation
Space
Original Mounting
Screws as Shipped
Install Transition Onto Top of Hood
IMPORTANT: Remove shipping tape from damper and
check that damper moves freely.
and secure with 4 screws
provided.
connection. Check to be sure
the damper moves freely.
Hang Hood On Wood
Support
Route house wiring through the knockout and into the
mounting screws engage the keyhole slots in the back
of the hood. Tighten the screws.
WARNING
Continue to provide additional support
while the hood is mounted with only these 2 screws.
These screws will not support the weight of the hood. The
hood could fall resulting in damage or personal injury.
AVERTISSEMENT
Continuez à fournir un soutien
corporelles ou des dommages matériels.
ADVERTENCIA
campana sea montada sólo con estos 2 tornillos. Estos tornillos
produciendo daños o lesiones personales.
Test Duct Cover Fit
over the top of the
hood to check for
hood up or down if
necessary.
Install Bottom
Mounting Screws
holes. Enlarge the holes if they did not enter studs
to 3/8". Insert anchors for wall fasteners into bottom
holes. Remove anchor screws and add flat washers
provided. Drive screws into anchors and tighten.
hood and into the wood support.
Duct
Transition
Bottom
Mounting
Holes
30"
Centerline of
to
Installation
36"
Space
31-2000856 Rev. 0
