Re-Connect The Dongle With The Shinelanbox - Growatt ShineLink-X Setup Guidance

Re-connect the dongle with the ShineLanBox

1) Push the reset button at the bottom of the ShineLanBox until all four lights are on.
2) Go to your inverter, push the reset button on the RF stick for 6 seconds until LED become solid
blue.
3) Go back to the ShineLanBox, short push the reset button, then you can find that the bottom light
starts to flash.
4) Go to your inverter again, short push the reset button on the RF stick. Re-pair finish, the bottom
light should be completely off and the third light starts to flash. Please wait until, the LED on the RF
stick shows slowly flashing Blue.
Re-pair the LanBox and the RF stick
(No need to Reset if third light on the box is flashing green)
GROWATT NEW ENERGY TECHNOLOGY CO.,LTD
－ Powering Tomorrow
8
