- Page 1 Growatt monitoring device setup guidance JABOR － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 2 Bar codes at the back Reset button inside the rubber cap • Bar codes at the back They both only compatible with 2.4Ghz Wi-Fi. 5Ghz and 2.4&5 Ghz combined in one wifi signal are not compatible. － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 3 Indicators on the dongle Both Shinewifi-X and Shinewifi-S have the same indicator Safety information Flashing Red • the initial state of the configuration Solid Blue • Dongle is launching hotspot, waiting to use AP mode method Flashing Blue • Dongle has been connected to router Solid Green •...
- Page 4 Indicators on the dongle Release Multiple Flashing Shinephone Flashing Blue Color configuration Succeed Single tap Hold AP mode Solid Green Solid Blue method Fail Single tap Hold － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 5 Shinephone App registration Before you begin, please make Before opening the Shinephone sure that the dongle‘s light is App, make sure your mobile device flashing. is connected to the 2.4Ghz Wi-Fi. － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 6 Shinephone App registration Please use your own email address as username Enter the same email address again Installer code can leave as blank － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 7 The following Australia Time Zone information about the address will From GMT +7 to GMT +10 be filled in automatically Fill in the inverter rated power Check the state first － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 8 For Shinewifi-X, scan the QR to get SN and CC. Shield the sunlight, aimed at scanning code. For Shinewifi-X, scan the Bar code at back to get SN and CC. The serial number on the inverter is different from that of the dongle.
- Page 9 Shinephone App configuration When making sure your phone is connected to a 2.4ghz network, only the first option can be choosing. Please don't try the second way. － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 10 After the phone is connected to the 2.4ghz network, the Wi-Fi name is automatically filled in the blank. Please fill in the correct password for Wi-Fi, and pay attention to case sensitivity － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 11 If it succeed, it will turn Click on ‘Yes’ back to the and wait for dashboard it counting directly and down. show this success information － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 12 If you see “Existing datalogger SN” as the picture, please follow the steps from next page (Follow the red arrows to click). － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 13 Click in your plant － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 14 Press the SN number and hold it After clicking the Configure datalogger, please go back to page 9 to do the configuration again － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 15 AP MODE － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 16 Please make the indicator on the dongle to Solid Blue. Only in the constant blue state, the dongle will make the hot spot. If it changes to other colors, the hot spot will disappear. － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 17 • Due to the different security Settings of each phone, the connection to the hotspot may drop and the original Wi-Fi will be automatically connected back. Please reconnect to the hotspot － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 18 Please open a browser and enter the IP address 192.168.10.100 • Click go to see the interface shown in the picture on the left • Username is ‘admin’ • Password is ‘12345678’ • Click ‘Login’ － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 19 Wi-Fi name and password WiFi list as these parts are capital sensitive. WiFi name input WiFi password • Please click on ‘Apply’ if you are sure the name and password are right. － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 20 Ap Mode Method When the website turns to the right page, please click on ‘Restart Immediately’ Check the indictor, Blue flashing means it is connected. Solid Green light means it is not connected. － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
-
Page 21: Troubleshooting
Datalogger already exist Click on the 'Configure datalogger' and do the configuration Existing datalogger again If there is no datalogger there, please contact Growatt After configuration in Shinephone, the dongle's Please reset the dongle to flashing red and do the light is not flashing blue or configuration again. - Page 22 Forget the home wifi connection from mobile phone. Verify wifi name and Use the same wifi password entered in the AP mode method password redo the wifi connection on mobile phone. Check to see if the password is correct － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 23 Dongle cannot change to single tap the button again. Flashing Red 2. If still cannot change to flashing red, please contact Growatt to check AP mode login page cannot 1. Check if the hotspot of dongle is connected to your phone.
- Page 24 Contact us Growatt New Energy Australia Pty Ltd C1, 27-29 Fariola Street, Silverwater, NSW 2128 Service Hot Line +61(0)2 80651298 1800 476 928 － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
