- Page 1 Growatt monitoring device setup guidance SHAWN － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 2 ShineLink Monitoring Devices Overview Safety － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 3 • Tricolor indicating light (RGB) inverter with RS232 port • • Reset button underneath Tricolor indicating light (RGB) • QR code inside the rubber cap • Reset button inside the rubber cap － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 4 Please plug the ShineLanBox into your home router and plug the dongle into the communication port underneath your inverter, If the port is occupied by the original WiFi dongle, you have to replace the old one with the new RF stick. － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 5 ShineLanBox and the dongle. Solid Green Flashing Green When the connection is established successfully, the top two lights should be solid green and the third light should be flashing intermittently. － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 6 Indicators on the dongle Both ShineLink-X and ShineLink have the same indicator Safety information Flashing Blue Fast • RF Stick is waiting to be paired with the ShineLanBox Flashing Blue Slow • RF Stick has been connected with the ShineLanBox －...
- Page 7 If the top two lights are green and the third light is completely off, please follow the instructions on the next page as this will help you to make these two devices paired again properly. － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 8 4) Go to your inverter again, short push the reset button on the RF stick. Re-pair finish, the bottom light should be completely off and the third light starts to flash. Please wait until, the LED on the RF stick shows slowly flashing Blue. － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 9 Shinephone App registration After setting the RF stick and the ShineLanBox Please start setting your account in the ShinePhone App as follow － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 10 Shinephone App registration Before you begin, please pair Download the ShinePhone App and the dongle with the start the register process ShineLanBox first. － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 11 Shinephone App registration Please use your own email address as username Enter the same email address again Installer code can leave as blank － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 12 The following Australia Time Zone information about the address will From GMT +7 to GMT +10 be filled in automatically Fill in the inverter rated power Check the state first － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 13 Add Datalogger Scan the bar code at the back of the ShineLanBox, after scanning, this datalogger will be added into your account and you will be able to monitor your solar system. － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
- Page 14 Contact us Growatt New Energy Australia Pty Ltd C1, 27-29 Fariola Street, Silverwater, NSW 2128 Service Hot Line +61(0)2 80651298 1800 476 928 － Powering Tomorrow GROWATT NEW ENERGY TECHNOLOGY CO.,LTD...
