Growatt ShineLink – X
Quick Installation Manual
SOLSOL s.r.o.
Králova 298/4, Brno 616 00, Czech Republic
podpora@solsol.cz
www.solsol.cz
For more info, please download from
http://server.growatt.com
Telephone: +86 755 2747 1942
Fax: +86 755 2747 2131
e-mail:
service@ginverter.com
website:
www.growatt.com
Advertisement
Related Manuals for Growatt ShineLink-X
Summary of Contents for Growatt ShineLink-X
- Page 1 Growatt ShineLink – X Quick Installation Manual SOLSOL s.r.o. Králova 298/4, Brno 616 00, Czech Republic podpora@solsol.cz www.solsol.cz For more info, please download from http://server.growatt.com Telephone: +86 755 2747 1942 Fax: +86 755 2747 2131 e-mail: service@ginverter.com website: www.growatt.com...
-
Page 2: Step 2: Electrical Connection
Step 1: Unpacking Unpack the box and take out ShineLanBox, ShineRFStick-X, and other accessories according to the following list: Item Name Quantity ShineLanBox ShineRFStick-X Network cable Power adapter Fixing screws Wall plastic posts User manual Step 2: Electrical connection 1. Rotate the USB cover of the photovoltaic device counterclockwise 2. - Page 3 After the installation, if the LED light of ShineRFStick-X flashes quickly, it means that the installation works. If the LED light is off, please recheck the connection between ShineRFStick and the inverter. ShineRFStick -x’s LED status Status of the ShineRFStick-X Always on The ShineRFStick-X is initialing Always off...
- Page 4 Note: 1. Make sure you install the newest version. 2. For more information please visit server.growatt.com 2. After installing the ShinePhone app, click on log in, and then click on register, and then enter your county and city.
- Page 5 4. Fill in all the customer information and click next to go to the add datalogger page 5. Scan or type in the bar code on the ShineLanBox, click register, and then it will automatically switch to the My Plant page.
- Page 6 6. On the My Plant page, you can monitor all the devices to check solar device information 7. On the My Plant page, you can monitor all the devices to check solar device information Note: after you successfully add the datalogger, you can see the ShineLanBox’s conditions, if you cannot find ShineLanBox please check the status of the LED light to find out the problem:...
- Page 7 Tip 1: Add new ShineRFStick device Note: Only after resetting ShineLanBox or adding a new ShineRFStick-X, you need to pair ShineLanBox and ShineRFStick-X, all the devices will be paired by the manufacturer. Quick press ShineRFStick-X (in less than 2 seconds), then quickly press ShineLanBox’s button, you can enter pairing mode, at this point, the ShineLanBox’s pairing light is flashing, ShineRFStick-X ’s Blue light is flashing quickly if the pairing is successful, ShineLanBox’s pairing light is off, ShineRFStick-X ’Blue web light change to slow flashing.
