  • Page 1: Table Of Contents

    Contents Information about this document Parameterization (SVA 2000/2000F only) Contents and purpose LED display Target group 5.2 Adjustable parameters Other applicable documents 5.2.1 Operation mode Abbreviations 5.2.2 Bus address Symbols used 5.2.3 Terminating resistor 1.5.1 Hazard categories 5.3 Default settings 1.5.2 More symbols 5.4 Display at system start Safety...

  • Page 2: Information About This Document

    All versions of a door lock; the 4000, 5000, exact lock type is marked with 3 6000 digits instead of zeros. Software for the dormakaba TMS Soft® door management system (TMS) DCW® is short for "DORMA Connect & Work". A dormakaba-owned fieldbus DCW®...

  • Page 3: Safety

    • The following SVA door locks are suitable for use on fire and smoke protection doors: SVA 5000, SVA 4000, SVA 6000, SVA 2000F. • The SVA 2000 may only be used in fire and smoke protection doors in combination with the external Power Reserve module "SVP-PR DCW®" (item no: 70922601).

  • Page 4: Product Description

    Installation situation Fig. 3 Electrical installation situation (example) 3.1.1 Mechanical opening Active leaf with SVA 2000/2000F Fixed leaf with SVI 2000F Panic door fitting Cable transfer CT, cable spiral CS and if necessary detachable cable transfer DT Connecting cable SVP-A 1100/2100 Operator inc.

  • Page 5: Technical Information

    Contact load capacity 100 mA at max. 30 V DC • The locks SVA 2000 and SVA 2000F are compatible SVA 6000 with an ED100 or ED250 from the ED firmware version V2.200 upwards. If the EDs have an older Status messages via potential-free contacts firmware version, this must be updated.

  • Page 6: Overview

    Mounting instructions Product description Overview 3.5.1 Tubular frame locks 3.5.2 Solid door locks optional optional Fig. 4 Active leaf with tubular frame lock Fig. 5 Active leaf with solid door lock SVA door locks WN 059743 45532 2019-07...

  • Page 7: Classification

    Mounting instructions Product description Classification 3.4.1 Tubular frame locks 3.4.2 Solid door locks dormakaba Deutschland GmbH dormakaba Deutschland GmbH Postfach 4009 - 58247 Ennepetal Postfach 4009 - 58247 Ennepetal 0432-CPR-00026-96 0432-CPR-00026-19 SVA 4000 RR EN 12209:2003/ SVA 4000 VB EN 12209:2003/ 3 X 6 1 0 G 7 B B 2 0 3 X 9 1 0 G 7 B B 2 0 SVA 5000 RR...

  • Page 8: Tubular Frame Locks

    Mounting instructions Product description Tubular frame locks 3.6.1 Parts included Fig. 6 Parts included Door lock Screws 3.6.2 Lock dimensions SVA 4000 SVA 5000 SVA 6000 X = 23 SVA 2000 SVA 2000F X = 16 Fig. 7 Lock dimensions...

  • Page 9: Solid Door Locks

    Mounting instructions Product description Solid door locks 3.7.1 Parts included Fig. 8 Parts included Door lock Screws Cylinder fixing screw (SVA 2000 and 2000F only) 3.7.2 Lock dimensions 10,7 ø22 65 / 80 / 100 ø17 A/B/C/D Fig. 9 Lock dimensions 3.7.3...

  • Page 10: Mounting

    Mounting instructions Mounting Mounting Requirements for mounting • The door corresponds to the specifications in Abb. 12 and is deformed by a maximum of 5 mm. Safety during mounting • For mounting along escape routes: The door opens in the escape direction. If the door...

  • Page 11: Preparatory Work

    Mounting instructions Mounting Preparatory work 4.4.1 Mill-cut and drill door leaf for tubular frame locks ST 3.9x19 A2-70 (EN ISO 7050) *2) depending on fitting *3) 45 at backset 35 50 at backset 40 55 at backset 45 Fig. 13...

  • Page 12: Mill-Cut And Drill The Door Leaf For Solid Door Locks

    Mounting instructions Mounting 4.4.2 Mill-cut and drill the door leaf for solid door locks Ø 22 ø 22 ø7 ø10 Ø 10 ø7 65/8 100 Fig. 14 Recesses and pre-drilled holes in door leaf SVA 2000 SVA 2000 SVA 2000F...

  • Page 13: Mount Locks

    Mounting instructions Mounting Mount locks 3. Screw the door lock tight (Abb. 18). 4.5.1 Mount tubular frame lock Connect the cable (Abb. 16). TIPS AND RECOMMENDATIONS In the case of earthed door frames, the bridge on the plug must be disconnected.

  • Page 14: Mount Solid Door Lock

    SVA 2000 and SVA 2000F. Mount the door handle and locking cylinder (Abb. TIPS AND RECOMMENDATIONS 24). For SVA 2000/2000F locks, use only the In the case of earthed door frames, the cylinder screw supplied with the lock to secure the bridge on the plug must be disconnected.

  • Page 15: Parameterization (Sva 2000/2000F Only)

    Mounting instructions Parameterization (SVA 2000/2000F only) Parameterization must be set on the second SVA door lock (see chapters (SVA 2000/2000F only) 5.6.1 and 5.6.2). 5.2.3 Terminating resistor LED display In the CAN bus operation mode, the terminating With the SVA 2000 and SVA 2000F, colored light...

  • Page 16: Parameterization

    Mounting instructions Parameterization (SVA 2000/2000F only) Parameterization Symbol Operating method The parameters are set from the inside of the door in To jump from one selection to the its installed state. The switches in the door lock are next: operated with a door handle or key.

  • Page 17: Set For Dcw® Bus

    Mounting instructions Parameterization (SVA 2000/2000F only) 5.6.1 Set for DCW® bus ‣ The LED flashes red or green. Address assignment is only required in conjunction The signal repeats itself after a 2 s pause. with a SafeRoute system with multi-door application.

  • Page 18: Sva 2000F Integrated Power Reserve Module

    Mounting instructions SVA 2000F integrated Power Reserve module test SVA 2000F integrated Power Reserve module test The internal Power Reserve module is tested 5 minutes after the power is turned on and then every 48 hours. If the test completes with an error, the corresponding flashing code appears once according to the error messages (see chapter 9).

  • Page 19: Smoke Detector

    Mounting instructions Complete mounting Smoke detector Control 24 V power supply unit Option: Door contact Fig. 28 Wiring of smoke detectors with a SVP 2000/SVP 2000F Complete mounting Check all gaps. If necessary, adjust the leaves in the door frame (Abb. 12).

  • Page 20: Error Messages

    CAN bus connection interrupted Check correct wiring. Disconnect and reactivate the power supply for the door. If the General error error persists, call dormakaba Service. 10 Maintenance Disassembly and disposal Perform the following maintenance steps at least once Disassembly is carried out in reverse order of the a month to ensure safe use of the SVA door lock: mounting instructions.
