Page 1: Table Of Contents
Contents Information about this document 4.3.4 Prepare the door frame for the rod Contents and purpose striking plate Target group 4.3.5 Prepare the door leaf for the switch lock Other applicable documents Abbreviations 4.3.6 Prepare the door leaf for the lower rod Symbols used guide 1.5.1... -
Page 2: Information About This Document
Mounting instructions Information about this document Information about this Example of an integrated warning document Caution! Danger of injury from cutting! Contents and purpose SVI locks are mounted in the fixed leaf and SVA 1.5.2 More symbols locks in the active leaf of a 2-leaf unit. The locks are available in various designs for tubular frame doors and solid doors. -
Page 3: Safety
Other combinations on request. • Use only in combination with the SVA locks offered by dormakaba. Combinations with locks from other manufacturers must be approved by dormakaba. • Panic locks may only be mounted on fire and... -
Page 4: Product Description
Mounting instructions Product description Product description 3.1.2 Automatic opening The SVI lock on the fixed leaf serves as a strike box for the SVA lock. The SVI lock locks automatically by extending the espagnolette bolt as soon as the fixed leaf is closed. -
Page 5: Technical Information
Mounting instructions Product description Technical information Variants Versions of the SVI locks are available for various All SVI locks applications: Temperature range -25°C to +70°C • The SVI 5000 is a mechanical lock. When the door is closed, the lock locks automatically. -
Page 6: Overview
Mounting instructions Product description Overview 3.4.1 Tubular frame locks 3.4.2 Solid door locks optional optional Fig. 4 Fixed leaf with tubular frame lock Fig. 5 Fixed leaf with solid door lock SVI Lock WN 059741 45532 2019-12... -
Page 7: Classification
Mounting instructions Product description Classification 3.5.1 Tubular frame locks 3.5.2 Solid door locks dormakaba Deutschland GmbH dormakaba Deutschland GmbH DORMA Platz 1 - 58256 Ennepetal DORMA Platz 1 - 58256 Ennepetal 0432-CPR-00026-11 0432-CPR-00026-11 SVI 2000 RR 3 7 7 B* 1 4 5 2 A C SVI 2000 VB... -
Page 8: Tubular Frame Locks
Mounting instructions Product description Tubular frame locks 3.6.1 Parts included □9 Fig. 6 Parts included SVI Lock Forend (pre-mounted if necessary) OKFF Screws for mounting the lock Screws for mounting the forend 62,5 Other required sets (40) (45) • SVI Accessories Set 24mm or SVI Accessories Set 20mm •... -
Page 9: Lock And Forend Dimensions
Mounting instructions Product description 3.7.2 Lock and forend dimensions ø7 13,2 OKFF 65/80/100 62,5 Position of the espagnolette bolt variable (4.4.2 on page 16) X = Backset - 35 Y = Backset - 27 Fig. 10 Lock and forend dimensions (forend depending on item ordered) 3.7.3... -
Page 10: Other Components
Mounting instructions Product description Other components 3.8.1 Masking plate 3.8.3 Switch lock 90° ø10.9 ø5.9 ø10.5x90° ø5.5 ø18.5 Fig. 16 Switch lock dimensions 3.8.4 Lower rod guide Fig. 13 Masking plate dimensions 90° ø10.4 ø10.9 ø6 ø25 ø11.6x90° ±2 ø6... -
Page 11: Mounting
Mounting instructions Mounting Mounting max. 1300 max. 1300 Safety during mounting WARNING 2.5-5 Danger to life from crowding in front of a jammed door. If the door leaf is deformed by more than 5 mm, the door may not always open reliably! max. -
Page 12: Preparatory Work
Mounting instructions Mounting Preparatory work 4.3.1 Mill-cut and drill door leaf for tubular frame locks 32/37 42 32/37 42 ø10 ø10 OKFF OKFF *1) ST 3.9x19 A2-70 (EN ISO 7050) *1) ST 3.9x19 A2-70 (EN ISO 7050) *2) 45 at backset 35... -
Page 13: Mill-Cut And Drill The Door Leaf For Solid Door Locks
Mounting instructions Mounting 4.3.2 Mill-cut and drill the door leaf for solid door locks min. ø15 DIN left DIN right 65/80/100 min. ø15 OKFF X = Backset - 35 Y = Backset - 27 Fig. 21 Recesses and pre-drilled holes in door leaf with a lipped forend min. -
Page 14: Prepare The Floor For The Masking Plate
Mounting instructions Mounting 4.3.4 Prepare the door frame for the rod SVI 2000 striking plate SVI 2000F SVI 4000 21/25 SVI 5000 Fig. 27 Recesses for the rod striking plate Fig. 24 Recesses and pre-drilled holes in the door leaf for 4.3.5... -
Page 15: Mount Locks
Mounting instructions Mounting Mount locks 2. If necessary, screw the forend to the lock with 1.5 Nm (Fig. 31). 4.4.1 Mount tubular frame lock TIPS AND RECOMMENDATIONS Adjust the forend (Fig. 30). Only use the self-locking screws supplied. If these screws are loosened again, they must be replaced by new self-locking screws. -
Page 16: Mount Solid Door Lock
Mounting instructions Mounting 4.4.2 Mount solid door lock 4. Insert the lock into the door leaf recess (Fig. 33). Adjust the forend (Fig. 35). Fig. 33 Insert lock 45° 5. Screw lock tight (Fig. 34) Fig. 35 Dimensions of the adjustments 2. - Page 17 Mounting instructions Mounting WARNING 5. Pull in the connecting cable SVP-A 1100/2100 and connect it to the lock (Fig. 38). Danger to life from jammed door. Incorrect positioning of the grub screw at SVI 2000 the top of the lock may prevent the door...
-
Page 18: Mount Fixed Leaf
Mounting instructions Mounting Screw lock tight (Fig. 40) Fig. 41 Mount spacers 2. Determine and mark the length of the upper espagnolette bolt (Fig. 42). Fig. 40 Screw lock tight Mount fixed leaf TIPS AND RECOMMENDATIONS • The parts to be mounted are included in the other required sets. - Page 19 Mounting instructions Mounting Fig. 44 Insert plastic plug 6. Insert the locking clamp into the SVI lock (Fig. 45). Fig. 47 Screw in upper espagnolette bolt Insert the lower espagnolette bolt into the fixed leaf and screw it into the lock with 3.5 Nm (Fig.
-
Page 20: Adjust Upper Espagnolette Bolt
Mounting instructions Mounting M5 x 20, A2-70 Spax 4.5 x 30 90° ±0.5° 45° Fig. 49 Mount switch lock Fig. 52 Dimensions of the adjustments 12. Function test: Operate the switch lock and check 17. Mount the rod striking plate for the upper whether the rod extends (Fig. -
Page 21: Fix Upper Espagnolette Bolt
Mounting instructions Mounting Fig. 54 Completely attach the adjustment tool 5. Move the fixed leaf in the closing direction and check how much air there is between the adjusting tool and the rod striking plate in the door frame. -
Page 22: Mounting Active Leaf
Mounting instructions Displays SVA 2000F integrated Power Mounting active leaf Reserve module test TIPS AND RECOMMENDATIONS The internal Power Reserve module is tested 5 • Observe the applicable documents for the minutes after the power is turned on and then every SVA lock. -
Page 23: Complete Mounting
If not, call dormakaba Service Disconnect and reactivate the power supply for the door. If the General error error persists, call dormakaba Service. Check correct wiring, especially the SVA-SVI bus connection interrupted wiring of the SVA and SVI lock. -
Page 24: 10 Maintenance
The SVI solid door locks have a permanent dry lubrication with bonded coating. • If necessary, supplementary lubrication with Teflon spray (acetone-free) is permitted. dormakaba Deutschland GmbH DORMA Platz 1 58256 Ennepetal Germany T: +49 2333 793-0 F: +49 2333 793-4950 www.dormakaba.com...
