Application Diagram - Altronix AL125220 Quick Start Manual

Red
ON
OFF
Slow Blink
Rapid Blink
Fig. 1
Fig. 1a - SW1 & SW2
OPEN SWITCH
CLOSED SWITCH
Normal Open
Access Control
- 3 -
Power Supply Status
Normal condition.
No DC output.
Loss of AC.
Unit is triggered, awaiting reset. Fire alarm interface activated.

Application Diagram:

Triggering
Device
Normal Open
Reset Device
VR1
NO GND NO GND
TRIG INPUT FACP1 FACP2
RESET + AUX -- COM--
FACP
NC
FACP
SW2:
12VDC - Open
24VDC - Closed
STRIKE+ LOCK+
MAG LOCK
Card
Reader
NO
Com-
{ }
2.2K EOL
(supplied)
Fig. 2
STRIKE+ LOCK+
ELECTRIC
STRIKE
AL125220 series
