Dynamic Rhino Conversion Manual page 8

Warning:
The motor and battery adaptor looms are only suitable for use with scooter
wiring that uses genuine AMP/Tyco housings and terminals and/or genuine
Dynamic housings as specified in the Rhino installation manual.
Type
6-way 250 series Plug Housing
4-way 250 series Plug Housing
250 series Receptacle w/o latch 14-12 AWG
AMPINNERGY Connector Contact dual-beam 10-12 AWG
Dynamic 4-way Connector Housing
Terminal kits
Alternatively, you can use the following terminal kits to re-terminate your existing looms. These kits
are available from your Dynamic Controls supplier.
Terminal kit
RHINO2 - Loom Kit Logic
RHINO2 – Loom Kit 4W MTR 6W BAT
RHINO2 - Loom Kit Ring Term
Warning:
Only use genuine AMP or MOLEX crimp tools. Failure to properly crimp the
terminals may result in high resistance terminations.
Note:
A DS90-ACT can be used to replace a DS52K or DS72K using the same looms as required by the
DS90 and simply leaving the actuator pins unused. Plug the scooter's battery lead directly into
the DS90-ACT. Do not use a GLM551984 "RHINO2 BATT/ACT ADAPT LOOM".
Similarly a DS120-ACT can replace a DS112K with the same looms as required by the DS120, and
a DS160-ACT can replace a DS162K with the same looms as required by the DS160.
Rhino to RHINO2 Conversion Guide
Part No. Details
GSM51982 2, 4 and 14 pin connectors and terminals
GSM51988 4-way and 6-way housings and spade
receptacles to suit DS90 and DS120
GSM51989 8 ring terminals rated for 10-12 AWG wire,
to suit DS160 only
Part No.
171898-1
172134-1
170258-2
556880-2
GCN51315
Page 8
