Step 4 – Set up the scooter profile
The following section involves programming various parameters to set up the scooter profile. For
more information on programming, including cable requirements, see the Programming section on
page 17.

Set up throttle parameters

Set R 2 Swap Throttle Direction (4.4.1.3) to match the Rhino's Pot Reverse setting.
HINO
Set R 2 Throttle Input (4.4.2.2) to "Single".
HINO
Set Throttle Neutral Offset based on Rhino's Speed Pot Neutral setting. Please see Throttle
Neutral Offset (page 20) for more information.
Note:
Use the HHP to calibrate the unit instead of setting a value manually, see 'Throttle calibration'
in section 4.1.1.3 of the RHINO2 Installation Manual for details.
Set R 2 Throttle Full Scale Deflection (4.4.2.4) to ensure that the scooter's full speed can
HINO
be attained with the throttle's movement. For more information, please see the R
Installation Manual, section 4.4.2.4.
Set R 2 Throttle Response (4.4.2.5) to match the Rhino's Demand Curve setting, typically
HINO
80%.
Set R 2 Speed Limit Pot (4.4.2.11) to "No".
HINO

Set up drive performance parameters

Set R 2 parameters in the Drive Performance (4.4.3) section of the R
HINO
acceleration and deceleration, to meet the scooter's requirements. See Acceleration and
Deceleration Settings (page 19) in this guide for more information.
Set R 2 Soft Start Period (4.4.3.9) to a similar level of Rhino.
HINO
Set R 2 Soft Finish (4.4.3.10) between 25 to 28% in order to match Rhino deceleration
HINO
characteristics.

Set up motor management parameters

Set R 2 Motor Reverse (4.4.5.4) to match the Rhino's Motor Reverse setting.
HINO
Set R 2 Load Compensation (4.4.5.5) to match the Rhino's Motor Resistance setting; this
HINO
parameter will be fine-tuned later.
Set R 2 Load Compensation Damping
HINO
behaviour to that of the Rhino.
Set R 2 Remembered Load Compensation
HINO
to give a similar performance to that of Rhino.
Set R 2 Stall Timeout (4.4.5.11) to match the Rhino's Current Limit Time (Stall Time)
HINO
setting (typically 10 – 15 seconds).
Set R 2 Motor Testing (4.4.5.12) to "All" (unless motor faults cause problems during
HINO
testing).
Set R 2 Current Limit (4.4.5.9) as shown in the next table (page 15).
HINO
Set R 2 Boost Current (4.4.5.10) as shown in the next table (page 15).
HINO
Set R 2 Boost Time (4.4.5.10) as shown in the next table (page 15).
HINO
1
This parameter is new to R
2
This parameter is new to R
Rhino to RHINO2 Conversion Guide
1
2– please see R 2 Installation Manual, section 4.4.5.7 for more details.
HINO HINO
2– please see R 2 Installation Manual, section 4.4.5.8 for more details.
HINO HINO
(4.4.5.7) to, initially, 25% to give a similar
2
(4.4.5.8) to near zero (but not actually zero)
2
HINO
2 profile, for
HINO
Page 14
