Dynamic Rhino Conversion Manual page 10

Adapting DS72KA to DS90-ACT
To adapt a DS72KA loom to a DS90-ACT loom,
use the DS90 MTR/PB ADAPT LOOM (part no.,
GLM51981), and the R
HINO
LOOM (part no., GLM51984).
For more information, see the
Installation Manual,
R 2
HINO
section 3.4
GLM51981: Fit to existing motor loom
connector
GLM51984: Fit to existing battery / actuator
loom connector
GLM51984: Fit to R 2 actuator connector
HINO
socket
Warning:
Do not plug the scooter's battery / actuator connector directly into the DS90-ACT
as this will cause the actuator to be driven.
Rhino to RHINO2 Conversion Guide
2 BATT/ACT ADAPT
GLM51981: Fit to R
GLM51981: Fit to R
socket
GLM51984: Fit to R
socket
2 motor connector socket
HINO
2 park brake connector
HINO
2 battery connector
HINO
