Set Up Park Brake Management Parameters; Set Up Battery Management Parameters; Set Up Actuator Parameters (Where Fitted); Fine Tune Load Compensation - Dynamic Rhino Conversion Manual

Warning:
Follow these instructions carefully. The
than Rhino. Ensure that these motor management parameters are set to that
of the existing motor and no greater than that of the table below. Failure to
follow these settings can result in damage to the scooter or serious injury to
the user.
For example, when swapping a DS72K to a R
to 10A, and the Boost Time to 3 seconds.
Rhino R 2
HINO
DS72K DS90
DS112K DS120
DS162K DS160

Set up park brake management parameters

Set R 2 Park Brake Testing (4.4.6.1) to "Driving" if the Rhino's PB Open Circuit Drive Test
HINO
is set to "Yes", otherwise, set it to "Pre-drive". DO NOT set it to "None" as this will
contravene an ISO7176 requirement.
Set R 2 Park Brake Neutral Delay (4.4.6.2) to a similar value to Rhino's Park Brake Delay.
HINO
Note that the RHINO2's value is displayed in milliseconds, rather than seconds.
Set R 2 Park Brake Release Delay (4.4.6.3) to "0".
HINO

Set up battery management parameters

Set R 2 Undervoltage Rollback Start (4.4.7.1) to 19.6V.
HINO
Set R 2 Undervoltage Rollback End (4.4.7.1) to 17.6V.
HINO
Set R 2 Battery Gauge Low Warning (4.4.7.3) to 23.4V.
HINO

Set up actuator parameters (where fitted)

Set R 2 Actuator Time-Out (4.4.8.2) to "60" to match the Rhino. This value can be
HINO
decreased for greater protection if the travel of the actuator takes less than 60 seconds to
complete under full load.

Fine tune Load Compensation

Fine tune Load Compensation (4.4.5.5). Do not over compensate. For more details, see the
RHINO2 Installation Manual (4.4.5.5 Load Compensation).

To finish

Save a copy of the profile to your computer, and write the profile to the controller.
Calibrate the throttle with the DX-HHP or the Wizard's HHP emulator
3
If you do not have access to the DX-HHP, then use the Wizard's HHP emulator. This can be found by selecting
"Tools", "Plug-ins", "HHP Emulation" and clicking on the 4 soft keys, or pressing the "1", "2", "3" or "4" numeric
keys on the keyboard.
Rhino to RHINO2 Conversion Guide
2 DS90, set the Current Limit to 70A, Boost Current
HINO
R 2 R
Current Limit
HINO
70A
110A
160A
R 2
's current capability is higher
HINO
2 R
Boost Current
HINO HINO
10A
10A
20A
3
2
Boost Time
3 seconds
3 seconds
3 seconds
