Introducing the RHINO2

The R 2 family of scooter controllers provides a reliable, refined, cost-effective control solution
HINO
for most mobility scooters and includes:
R 2
DS90 - HINO 90A Controller
R 2
DS120 - 120A Controller
HINO
R 2
DS160 - HINO 160A Controller
R 2 – DS90 and DS120
HINO
90, 120 and 160A models provide the power you want when you need it
Programmable acceleration curves, improved rollback on slopes, and improved motor matching
algorithms ensuring better curb-climbing and hill-starting capabilities
Speed reduction wiper (SRW) technology provides a seamless speed reduction in curves for extra
stability
Intelligent motor and battery management providing automatic power flow optimisation, auto
battery configuration, 5V and 12V battery capacity outputs (TruCharge™) and in-depth battery
logging and analysis tools
Support for a range of battery types, multi-function pins and flexible drive inhibits
Advanced diagnostics and servicing tools, including event and drive time logging, and
programmable servicing scheduler
2 Drive profiles, brake and reverse lights, reversing beeper and electronic park brake release
IP54 ingress protection
A separately available aluminium terminal cover provides increased protection to IP55 when
fitted
Compliant with EU Directive 2002/95/EC of 27 Jan. 2003 – restrictions on use of Hazardous
Substances (RoHS)
Optional single actuator output (with Wig-wag or dedicated switch activation).
Rhino to RHINO2 Conversion Guide
R 2
DS90-ACT - HINO 90A Controller with actuator
R 2
DS120-ACT - 120A Controller with actuator
HINO
R 2
DS160-ACT - HINO 160A Controller with actuator
R 2 – DS160
HINO
