Procedure

The procedure for swapping a Rhino system to a R
and programming some specific parameters. A summary is outlined below:
Step 1 – Capture the Rhino's existing profile
Step 2 – Replace the Rhino controller with the
Step 3 – Adapt the cables
Install the motor, park brake and battery cable adaptors
Install the logic cable adaptor
Step 4 – Set up the scooter profile
Set up throttle parameters
Set up motor management parameters
Set up battery management parameters
Set up drive performance parameters
Set up park brake management parameters
Set up actuator parameters
Step 5 – Test drive
In step 3, choose and install the correct cable adaptors for your scooter system.
For step 4, the Wizard programming tool is required to program specific parameters (see
Programming, in the Further information section). For each parameter, a reference is provided next
to the parameter's name (for example, Speed Limit Pot (4.4.2.11)). This refers to the section in the
R 2 Installation Manual where you will be able to find out more information on that particular
HINO
parameter.
Before you start!
Make sure that you have a copy of the R
details of mounting the new controller, setting the controller's profile, and detailed further
information.
Rhino to RHINO2 Conversion Guide
2 system involves both adapting the cabling,
HINO
controller
R 2
HINO
2 Installation Manual at hand. This is important for
HINO
