AIRCRAFT SPECIFICATIONS:
Top Wing Span: 1200mm/47.25in
Top Wing Area:20.08 Sqdm/311.29 Sqin
Bottom Wing Span: 1159mm/45.63in
Bottom Wing Area: 20.45 Sqdm/ 316.93 Sqin
Lenght:938mm/36.93in
Flying Weight: 1650g less battery
RECOMMENDED EQUIPMENT:
Motor: BL2826
Radio: 4ch+4servos
Warning! This model is not a toy.
It is designed for maximum performance. Please seek
advice if one is not familiar with this kind of electric
powered precision model.
Operating this model without prior preparation may cause
in juries.
Remember, safety is the most important thing. Always keep
this instruction manual at hand for quick reference.

Advertisement

loading
Need help?

Need help?

Do you have a question about the PT-17 and is the answer not in the manual?

Questions and answers

Summary of Contents for HobbyKing PT-17

  • Page 1 AIRCRAFT SPECIFICATIONS: Top Wing Span: 1200mm/47.25in Top Wing Area:20.08 Sqdm/311.29 Sqin Bottom Wing Span: 1159mm/45.63in Bottom Wing Area: 20.45 Sqdm/ 316.93 Sqin Lenght:938mm/36.93in Flying Weight: 1650g less battery RECOMMENDED EQUIPMENT: Motor: BL2826 Radio: 4ch+4servos Warning! This model is not a toy. It is designed for maximum performance.
  • Page 2 1. Wing Wings Part List Fix the wings with epoxy glue Fix the bottom wing hinge with instant Fix the bottom wing abdominal cover with glue epoxy glue and drill two diameter 10mm hole for fixing the bottom wing Drill two diameter 4mm hole for Cut the covering away for passing fixing the bottom wing through the servo’s extension line...
  • Page 3 Drill 2 diameter 3mm hole for Cut the covering away for fixing the fixing the bottom wing aileron servo Fix bottom wing aileron servo and Completed the bottom wing servo’s horn installing Cut the covering away for fixing the Wing Support Part List Wing support...
  • Page 4 Apply epoxy glue Fix the top wing hinge with instant Fix the bottom wing glue Cut the covering away for fixing the Cut the covering away for fixing the Wing support Wing support...
  • Page 5 Apply epoxy glue Apply epoxy glue Fix the aluminium wing support with Fix the plywood wing support with 8pcs M3*12 Socket head screw and 8pcs M3*12 Socket head screw and 8pcs M3 nut 8pcs M3 nut...
  • Page 6 Completed top wing and bottom wing Fix the top wing horn installing Completed the top wing and bottom wing aileron servo system installing 2.Main Landing Wheel Main Landing Wheel Part List Cut the covering away for fix the main landing wheel...
  • Page 7 Applay epoxy glue Passes the shaft through the wheel and the main landing chassis. Then fixed with M4 skidproof nut Fix the main landing wheel 3.Stabilizer/Vertical/Tail Wheel Draw a line for cutting the covering Stabilizer / Vertical / Tail Wheel away Part List...
  • Page 8 Draw a line for cutting the covering Judging by the line to cutting the away covering away Fix the horizontal tail and the vertical Cut the wood away and drill a diameter 2mm tail with instant glue hole for fixing the elevator linkage rod Fix the hinge with instant glue Fixing the elevator linkage rod with epoxy glue...
  • Page 9 Install the tail wheel and bend the steel Fix the tail wheel with 4pcs tapping wire screws Cut away the wood and drill a diameter 2mm Fix the tail wheel steel wire with hole for fixing the tail wheel steel wire epoxy glue and fix the hinge with instant glue Fix the rudder’s horn...
  • Page 10 Install the elevator push-and-pull Install the rudder push-and-pull Completed the elevator and rudder servo’s system installing 4.Canopy/Cowling/Motor Mounting Fix the motor with 4pcs M3*15 Socket Cowl/Motor mounting Part List head screw and 4pcs M3 skidproof nut...
  • Page 11 Fix the PVC ornament with epoxy glue Draw a mark for drilling the cowling’s hole Judging by the mark to drilling the Fix the cowl hole Fix the PVC ornament with epoxy glue Install the canopy...
