SPECIFICATIONS：
WingSpan: 3715mm/146.26in
Wing Area: 96.55Sqdm/1496.5Sqin
Weight: 2300g less battery
Fuselage Length 1861.5mm/73.29in
RECOMMENDED EQUIPMENT：
Motor: Jeti Phasor 2014G
Battery: 4S/5S 3300mah-5000mah
ESC: 60A~80A
Radio: 5 channels 6servos
Warning! This model is not a toy.
It is designed for maximum performance. Please seek advice if
one us not familiar
With this kind of engine powered precision model. Operating this
model without
Prior preparation may cause injuries .Remember, safety is the
most important thing. Always keep this instruction manual at hand
for quick reference.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for HobbyKing Aether 3700 EP
Summary of Contents for HobbyKing Aether 3700 EP
- Page 1 SPECIFICATIONS： WingSpan: 3715mm/146.26in Wing Area: 96.55Sqdm/1496.5Sqin Weight: 2300g less battery Fuselage Length 1861.5mm/73.29in RECOMMENDED EQUIPMENT： Motor: Jeti Phasor 2014G Battery: 4S/5S 3300mah-5000mah ESC: 60A~80A Radio: 5 channels 6servos Warning! This model is not a toy. It is designed for maximum performance. Please seek advice if one us not familiar With this kind of engine powered precision model.
- Page 2 1. Wing Part Wing Part List Apply instant glue to fix the flap’s hinge Apply epoxy glue to fix the stringy tube Apply instant glue to fix the aileron’s hinge Cut the covering away for installing flap’s Cut a hole to passing the servo’s extend line servos...
- Page 3 Cut the covering away for installing Pass through the aileron’s servos extend aileron’s servos line Apply epoxy glue to bond the aileron’s Fixed the aileron’s servos servo installing wood Fixed the servo mounting plate Fixed the aileron’s horn...
- Page 4 Completed the aileron’s servos installing Scuffed the wing latchplate with sand paper and install the flap’s servos like this way to ensuring a good glue bond Apply epoxy glue to fix the wing latchplate Passed the aileron’s servos extend line and wing tube through the middle wing Apply epoxy glue to bond the middle wing...
- Page 5 2. Stabilizer/Vertical Apply epoxy glue to bond the stabilizer’s Stabilizer/Vertical Part List installing mounting Apply instant glue to fix the elevator’s Installed the elevator’s servo hinge Fixed the stabilizer Fixed the elevator’s horn...
- Page 6 Completed the elevator’s servo installing Cut the covering away for installing the rudder’s servo Apply instant glue to fix the hinge Cut the covering away for installing the rudder’s servo Apply epoxy glue to bond the servo Installed the rudder’s servo installing wood...
- Page 7 Fixed the servo mounting plate Fixed the rudder’s horn Complete the rudder’s servo installing Installed the rudder Apply epoxy glue to bond the fuselage and Installed the main wings carbon fibre tube...
- Page 8 Installed the canopy...
