Summary of Contents for HobbyKing Prime Jet Pro
- Page 2 Packing list : Electronic equipment : 1. PP JET-8 Fuselage X 1 1. Motor 2208-2216 2200-2600kv X 1 2. Carbon tube X 1 2. Prop 5-6 inch X 1 3. Carbon sheet X 4 3. ESC 40AX 1 4. Poll Rod X 2 4.
- Page 5 AP.11 1 ¥.illfl No.fiDatllue in carbon sheet. Don't glue too much. Assemble Wing attach ment on. wing by foam glue. Notice wait Smins after applying foam glue...
- Page 6 Press wing attachment appropriate. Notice the hole.
- Page 7 Assemble carbon tube with hot melt glue gun , the glue must be well-distributed.
- Page 8 �! !! !=-i ii ii ii ii• •- -- - Assemble carbon tube with hot melt glue gun , the glue must be well-distributed. Make sure it's flat. Also use No.502glue fix carbon sheet.
- Page 9 Now we start ass r_ mble fuselage.
- Page 10 Applying foam glue on fuselage(See picture), glue must be well-distributed.
- Page 11 Assemble fuselage on body from the back forward. A••emblewood motor mount on fu•el•ge by hot melt glue gun.
- Page 12 Then assemble motor with 4 pcs M3 screws.
- Page 14 Assemble hinge with foam glue.
- Page 15 Assemble the pull rod. Adjust arm this step.
- Page 16 Use carbon tube through the hole, then applying foam glue. Place the battery in the battery compartment and check the C of G. The optimum C of G is 15mm in front of the main carbon wing spar. This can be adjusted slightly after the first flights to suit your style of flying.
