- Page 2 Packing list : Electronic equipment : 1. PP JET-8 Fuselage X 1 1. Motor 2208-2216 2200-2600kv X 1 2. Carbon tube X 1 2. Prop 5-6 inch X 1 3. Carbon sheet X 4 3. ESC 40AX 1 4. Poll Rod X 2 4.
- Page 5 AP.11 1 ¥.illfl No.fiDatllue in carbon sheet. Don't glue too much. Assemble Wing attach ment on. wing by foam glue. Notice wait Smins after applying foam glue...
- Page 6 Press wing attachment appropriate. Notice the hole.
- Page 7 Assemble carbon tube with hot melt glue gun , the glue must be well-distributed.
- Page 8 �! !! !=-i ii ii ii ii• •- -- - Assemble carbon tube with hot melt glue gun , the glue must be well-distributed. Make sure it's flat. Also use No.502glue fix carbon sheet.
- Page 9 Now we start ass r_ mble fuselage.
- Page 10 Applying foam glue on fuselage(See picture), glue must be well-distributed.
- Page 11 Assemble fuselage on body from the back forward. A••emblewood motor mount on fu•el•ge by hot melt glue gun.
- Page 12 Then assemble motor with 4 pcs M3 screws.
- Page 14 Assemble hinge with foam glue.
- Page 15 Assemble the pull rod. Adjust arm this step.
- Page 16 Use carbon tube through the hole, then applying foam glue. Put the battery in the canopy. And adjust center of gravity base on the mark. Flying weight is 479g, use 2200mah 3s battery + 40A ESC + 2212/2200kv motor+ 6035 Prop. The thrust-weight ratio is 1.6.
