Checklist for Correct Configuration

Overview
Once you reached this step, the installation is nearly complete. Before you finish work
you should carefully check the correctness of the configuration steps and of the actual
measurement values.
You need to verify that the measurements are correct. Do that before you finish
the installation.
Please perform three checks:
1. Quick Check
2. Checklist for Electrical Parameters
3. Checklist for Total Measurements
Quick Check
At this moment, the installation should meet the following criteria:
Check Description
1. The Smappee has been correctly powered on, according to the
instructions and checks.
2. The Smappee is connected to the Internet and the Smappee
cloud. This is indicated by a GREEN BREATHING light.
3. You see (some) real-time power values in the Bubbles of the App
or the Dashboard.
4. You have configured the individual CTs in the Smappee Expert
Portal.
Checklist for Electrical Parameters
In the menu item Configuration, please check the following parameters.
Check Description
1. The parameters in the "Configuration menu" panel should match the
electrical installation.
2. Auto-Detection should be OFF (unflagged)
3. Monitor mode = "use channel configuration menu".
4. The three voltage values should be approximately the same for each
phase.
5. The Current of each CT should show plausible values.
6. The Cos fi should be above 80%.
This check should be done during periods of high consumption.
Smappee Pro Installation Manual
Version 1.6.1, 12-05-2017, rev 226
Details on
page 15
page 17
page 17
page 21
Page 28 of 32
