Smappee Pro Installation Manual page 26

Type: Consumption, Production or Unused?
The type menu, you can choose between 3 options:
Option
Consumption (Load)
Production
(Solar/Wind)
Unused
Connection: Grid, Off-Grid or Sub-Meter?
The table shows the three connection types for the inputs.
Connection Description
type
Grid Measures Total Consumption on the Main Circuit Board
Indicates that this CT is connected directly to the main circuit board,
and thus measures the Grid Total.
Note: For each phase (L1, L2, L3) there can be only ONE input
configured as GRID.
Bubble in the App or the Pro Dashboard.
Off-grid Measures Extra Power on a separate Circuit Board
Indicates that the CT is connected to a separate circuit board that is
not connected to the main circuit board.
The value is ADDED to the total of GRID. Consequently, the
measurements will be added to the grey Consumption-Bubble.
Submeter Measures a sub-circuit of the Grid
Indicates that the CT is connected to a sub-circuit, that is connected
to the Main Circuit Board.
The values of these CT's will NOT be added to the total GRID.
Rogowski Coil Limitations
If you use Rogowski coils some of the combinations of configuration may be invalid. For
more details, see section "Special Cases - Rogowski Coils" on page 27.
Smappee Pro Installation Manual
Version 1.6.1, 12-05-2017, rev 226
Description
This input measures an appliance (that is an consumer van
energy).
This input measures an energy producer, such as a
photovoltaic installation.
You choose this option if the CT entry is not used.
will be displayed in the grey Consumption-
Page 26 of 32
