Real-Time Measurements
This section displays the real-time measurements and electrical parameters for each
input.
Detailed Parameters
The following table explains the parameters of the Real-Time Data.
Parameter
Info
Channel
Current
Active power
Reactive power
Cos phi
Smappee Pro Installation Manual
Version 1.6.1, 12-05-2017, rev 226
Explanation
Input on the Smappee.
Measured channel. In Smappee Pro, this is identical to the Info
column.
Current measured on that CT (Ampere).
Active Power (Watt).
Reactive Power (var).
Power Factor. Note: A "
emphasized by yellow highlighting.
of less than 60% is visually
Page 24 of 32
