Summary of Contents for OCULUS UB 4
- Page 1 OCULUS Universal Trial Frame UB 4 This product bears the CE mark in compliance with the terms of Directive 93/42/EEC on medical products. Instruction Manual...
-
Page 2: Table Of Contents
Content Content ..................20 Technical data ................21 Overview ..................22 Intended use .................. 24 Product specifications ..............24 Operating instructions ..............24 Polarizing filter (optional) ..............28 Intended use .................. 28 Warranty ..................32 Cleaning and care ................32 01 / 13... -
Page 3: Technical Data
Technical data Universal Trial Frame UB 4 Scope of delivery PD adjustment range 46 - 80 mm OCULUS Universal Trial Frame 42500 UB 4 PD scale division 1 mm Weight approx. 64 g Nose pad Arm length 88 - 124 mm... -
Page 4: Overview
Overview 03 / 13... - Page 5 Knob for adjusting pupillary distance (PD) Height-adjustable, pivoted nose pad Scale for horizontal pupil centring (pupillary Lens holder, front distance) Lens holder, back Mark for horizontal pupil centring (pupillary Toothed rack with nose pad, pivoted distance) Knob for height adjustment and locking into Screw for resistance place of toothed rack with nose pad Scale for reading axis and base positions;...
-
Page 6: Intended Use
Intended use Operating instructions Adjusting arm length ⑨: The OCULUS Universal Trial Frame UB 4 is used for subjective refraction. Only use OCULUS tls trial Pull out and/or push in arm. lenses with a diameter of 38 mm that comply with The temple end is flexible and can be adjusted... - Page 7 Reading off vertex distance (VD) at the Changing VD: sighting bars ⑧: Swivel rack ⑯. To do so, you must overcome a slight resistance. The transparent sighting bar has two scales. The inner scale must be aligned with the outer scale for a parallax-free reading of VD.
- Page 8 Adjusting nose pad height: Adjusting and reading PD: Turn knob ① to desired height. Turn the knob ⑦. Take PD reading from appropriate scale ⑤ and mark ④. 07 / 13...
- Page 9 Setting axis position for trial lenses with Resistance of knobs for axis or base position ⑪: cylindrical power and/or basis position of trial lenses with prismatic power: Increase: Turn brake in direction of arrow. Turn knob ⑫. Decrease: Turn brake against direction of arrow. Reading axis and/or basis position: Take reading from scale ⑥.
-
Page 10: Polarizing Filter (Optional)
Instruction Manual of the Universal visual impressions of the left and right eye during Trial Frame UB 4. Please note, depending on the refraction. They are exclusively intended for use device you need the linear OR cirular polarization with the OCULUS Universal Trial Frame UB 4 (item filter. - Page 11 Using polarizing fi lter Mounting polarizing fi lter: Clip holder Insert the pin ⓖ into the provided receptacle Rotary knob for turning polarizing fi lter ⑥ of the universal measuring goggles UB 4. (only 45886) Swivel joint (only 45886) Polarizing fi lter...
- Page 12 Polarizing fi lter linear 45886 V position Polarizing fi lter can simply be swung aside when A position not needed. Changing polarization direction: ⓑ Use knob to set polarizing fi lter to following positions: 11 / 13...
- Page 13 Polarizing fi lter circular 45883 Replace knobs and pad ⑫ Replace nose pad Pull off nose pad and mount new one. ⓑ ①,⑪,⑯& Replace knobs ( Pull off knob and mount new one. Circular polarizing fi lters cannot be rotated. 12 / 13...
-
Page 14: Warranty
Cleaning and care For disinfection of the trial frame we recommend Clean UB 4 and optional equipment when the products of: Schülke & Mayr GmbH. necessary with a soft, lint-free cloth only. In case of heavy soiling we recommend using Disinfecting wipes washing-up liquid on a moistened cloth.
