  • Page 1 INSTRUCTION MANUAL Tonometer - Pachymeter...
  • Page 2 Instruction Manual Corvis® ST (GA/72100/0213/ja)
  • Page 3 Notes on this instruction manual Thank you for your purchase and the trust you have placed in this OCULUS product. The Corvis® ST has been manufactured and tested according to strict quality criteria. You have selected a modern and well-engineered product.
  • Page 4 ii / vi Instruction Manual Corvis® ST (GA/72100/0213/ja)

  • Page 5: Table Of Contents

    Table of Contents Table of Contents Scope of Delivery ........................1 Type plates............................. 2 Safety Instructions........................3 About this Manual ...................... 3 3.1.1 Graphic symbols used ................3 Safety Instructions for Use ..................4 Indications for Use........................6 Contraindications ........................6 Warnings............................
  • Page 6 Table of Contents 14 Working with the Corvis® ST on a PC ................42 15 Connecting the Corvis® ST with a PC................43 15.1 Installing the Corvis® ST Software..............43 15.2 Installing the Driver Softwaren ................44 15.3 Changing the Settings.....................44 15.4 Corvis® ST Software: Settings 2 ................44 15.5 Settings in the Patient Data Management: "Interface"...
  • Page 7 Table of Contents 18.4 Attach paper to the chin rest ................82 18.5 Insert new printing paper roll ................83 19 Dismantling, transport and storage..................85 19.1 Removal.........................85 19.2 Transport and Storage.....................87 20 Disposal of Used Devices.......................87 21 Troubleshooting ........................88 22 Terms of Warranty and Servicing ..................89 22.1 Liability for proper function or damages ............89 22.2...
  • Page 8 Table of Contents vi / vi Instruction Manual Corvis® ST (GA/72100/0213/ja)

  • Page 9: Scope Of Delivery

    1 Scope of Delivery Scope of Delivery Component Order number  Corvis® ST 72210 Eye patch 44560   Dust protection cover 6010005001 Paper for chin rest 65313   Paper roll (3 rolls) 65311 Power supply 05150280  Instruction Manual G/72100..en ...

  • Page 10: Type Plates

    2 Type plates Type plates 1 Company logo + address Read the operating instructions 2 Disposal with household waste is Power supply number prohibited 3 CE Fuse rating 4 Protection class Serial number 5 Matrix Device name and number 6 Application part of type BF Fig.

  • Page 11: Safety Instructions

    3 Safety Instructions Safety Instructions About this Manual  Read the instruction manuals carefully.  Carefully store the instruction manuals near the device.  Observe the legal regulations with regard to accident prevention. The instruction manuals describe the following versions: ...

  • Page 12: Safety Instructions For Use

    Only operate the Corvis® ST using original accessory parts supplied by us, and only when the device is in technically correct working order.  Before first use: Let OCULUS or an authorized dealer train you in the operation of the Corvis® ST. ...
  • Page 13 3 Safety Instructions Information for Maintenance  The operating company must ensure that the device undergoes tech- nical measurement testing every 2 years according to MPBtreibV, Ap- pendix 2 Tonometer. To ensure that it functions correctly and safely we recommend the follow- ing: ...

  • Page 14: Indications For Use

    4 Indications for Use Electromagnetic Compatibility (EMC) / Cables Attention Personal or property damage caused by electromagnetic interference Portable and mobile RF communications equipment can affect medical electrical equipment sect. 25.1, page  Make sure that portable and mobile RF communications equipment do not cause interference.

  • Page 15: Transport To Installation Location

    7 Transport to installation location Transport to installation location The transport and storage conditions according to IEC 60601-1 with the ap- propriate packaging are valid for a period of up to 15 weeks, see “Transport and storage requirements (according to IEC 601 - 1)” on page ...

  • Page 16: Device Description

    8 Device Description Device Description Overview of Device Components Side - view 1 Gauge head 5 Joystick 2 Chin rest 6 Function keys 3 Xyz-base 7 Display 4 Control knob 8 Printout slot Fig. 8-1: Corvis® ST: Side view 8 / 92 Instruction Manual Corvis®...
  • Page 17 8 Device Description ront - view 1 Forehead rest On/Off switch 2 Air nozzle / window of the slit lamp Control LED 3 Lens protection glass Mains connection 4 LED to illuminate the eye USB port 5 Marking for the eye height Safety stop Fig.

  • Page 18: Mode Of Operation Of The Corvis® St

    8 Device Description Mode of Operation of the Corvis® ST The Corvis® ST is a non-contact tonometer equipped with an optical Pachymetry function. The Corvis® ST measures intraocular pressure without contact with the eye by applying an air puff to the eye. During the air puff the eye gets illumi- nated by a 9 mm slit through the apex and a built-in high-speed camera re- cords the movement of the eye with more than 4000 images per second.

  • Page 19: Start-Up

    Attention Incorrect measurements / equipment damage due to a lack training  Before first use: Let OCULUS or an authorized dealer train you in the operation of the Corvis® ST. Incorrect measurements / equipment damage due to incorrect set-up ...

  • Page 20: Adjustments After An In-House Transport

    9 Start-up Adjustments after an in-house transport Note Equipment damage due to incorrect lifting If the Corvis® ST is lifted by the forehead rest, it can break off.  Grab the Corvis® ST from below to lift it. 9.3.1 Device set-up ...

  • Page 21: Device Connection

    9 Start-up  Unlock the transport safety device if it is locked (1). "Locked" position 2 "Unlocked" position Fig. 9-2: Unlock transport safety device  Press down gently on the transportation safety device and turn it counter-clockwise to the "unlocked" position (2). The spring will push the transport safety device up.

  • Page 22: Daily Operation

    9 Start-up Daily operation Switching on the Corvis® ST  Make sure that the mains voltage is the same as the voltage specified on the rating plate.  Switch on the Corvis® ST with the On/Off Switch (1). Setting the safety stop The safety stop (2) is a lock that prevents the air nozzle from touching the patient's eye.

  • Page 23: Using The Control Pad

    10 Using the control pad 10 Using the control pad You enter and manage patient data with the control panel. In addition, you start the measurements and can view the results with it. 1 Display 4 Joystick button 2 Control knob 5 Screen-dependent Buttons 3 Joystick Fig.

  • Page 24: Display With Touch Screen

    10 Using the control pad 10.1 Display with Touch Screen In addition to the screen-dependent buttons, you can also use the buttons on the touch screen. The buttons change depending on the function of the display.  Lightly press the corresponding buttons on the touch screen to enable the function.

  • Page 25: Using Patient Data Management

    11 Using Patient Data Management 11 Using Patient Data Management When you turn on the Corvis® ST, Patient Data Management is shown first. Fig. 11-1: Corvis® ST switch on Use Patient Data Management to associate examinations with a patient or when you want to save them long-term.

  • Page 26: Entering New Patients

    11 Using Patient Data Management 11.1 Entering new patients  To input a new patient, press the button [New Patient] in the patient data menu. The following screen is displayed: Fig. 11-2: Touch-screen keyboard, enter patient data  Use the touch-screen as described in (sect.

  • Page 27: Select An Existing Patient

    11 Using Patient Data Management You will be asked if you want to save the new patient data.  Select "Yes". The patient's name appears in the list. Fig. 11-4: Patient list  Press the [Start] button to switch to measure mode. 11.2 Select an existing patient Choose a patient whose data is already stored, and whom you wish to ex- amine again.

  • Page 28: Delete A Patient Or An Examination

    11 Using Patient Data Management 11.3 Delete a Patient or an Examination If you want to delete a patient or an examination:  Select the patient in question.  Press the [Pat./Exam Delete] button. Fig. 11-5: Delete a Patient or an Examination To delete a patient: ...

  • Page 29: Perform A Measurement

    12 Perform a Measurement 12 Perform a Measurement Attention Risk of contact of the patient's eye with the air nozzle  Before starting a measurement, make sure the safety stop is set cor- rectly, “Setting the safety stop” on page 14.
  • Page 30 12 Perform a Measurement Button Function Adjust height Back to Patient Data Management Measure mode, automatically enabled 22 / 92 Instruction Manual Corvis® ST (GA/72100/0213/ja)

  • Page 31: Select A Measuring Mode

    12 Perform a Measurement 12.1 Select a measuring mode Depending on th version you can select d the measuring mode.  Press this button. Tono + Pachy Press this button to select the measuring mode „Tono + Pachy“.   12.2 Corvis®...

  • Page 32: Fine Adjustment

    12 Perform a Measurement Attention Risk of contact of the patient's eye with the air nozzle Fast and/or uncontrolled movements may cause the air nozzle to touch the patient's eye.  When operating the Corvis® ST, move it carefully toward the patient's eye.

  • Page 33: Start Measurement

    12 Perform a Measurement  Example Move the joystick to the right.  Turn the joystick clockwise. Arrow Camera movement Joystick movement right Move the joystick to the right left Move the joystick to the left forward Move the joystick toward the patient back Move the joystick away from the pa- tient...

  • Page 34: Saving Data

    12 Perform a Measurement After the start, the measurement is calculated. You have to wait for this process before you can view the results (sect. 12.7, page 28) or can save (sect. 13, page 36) them. 12.4 Saving data Depending on the installation, your data is stored on a USB flash drive or transferred to a PC / laptop.

  • Page 35: Re-Using Data With The Usb Flash Drive (Optional)

    12 Perform a Measurement 12.5 Re-using data with the USB flash drive (optional) If your Corvis® ST is not connected to a PC, your data is stored on a USB flash drive that is connected on the inside of the unit. You can save the data onto a USB flash drive that is inserted in the device.

  • Page 36: Complete Measurement

    12 Perform a Measurement 12.6 Complete measurement  After each patient remove one of the paper sheets from the chin rest. See also sect. 18.4, page  Disinfect the forehead rest after each patient, sect. 18.2, page Attention Risk of infection after examining a sick patient If you perform a measurement on a sick patient, the air nozzle and the front cover can be contaminated.

  • Page 37: Keyboard Layout

    12 Perform a Measurement Keyboard layout Button Function You can view the recorded Scheimpflug images as a video. This shows the deformation of the cornea in slow motion. Switch between views Button is displayed after a measurement. Saves the patient's examination data sect.
  • Page 38 12 Perform a Measurement Applanation length (mm)  Progress of the applanation length (flattened area) during the mea- surement. Fig. 12-8: Graph Applanation length  Corneal velocity (m/s) Progress of the corneal velocity (from the apex) during the  measurement. Fig.
  • Page 39 12 Perform a Measurement Display IOP / Pachy values (3) Fig. 12-10: IOP / Pachy values In this table the IOP/Pachy values and corneal deformation values are shown in figures. Parameter Designation Time The time between the two images is defined by the frame rate of 4330 frames per second.
  • Page 40 12 Perform a Measurement Parameter Designation Deform. Ampl. The deformation amplitude is determined by the deformation of the apex before, during and after the air blast. The position of the apex for each image is calcu- lated using the Scheimpflug analysis. Show individual images (6) ...
  • Page 41 12 Perform a Measurement Depending on the setting, lines as shown in this illustration are displayed 1 Front of the cornea 3 Back of the cornea 2 Applanation 1 of the cornea 4 Strongest curvature of the cornea Fig. 12-12: Importance of the lines on Scheimpflug images Applanation 1 shows the applanation of the cornea before deformation by the air blast Fig.

  • Page 42: View Video

    12 Perform a Measurement Applanation 2 shows the applanation of the cornea after deformation by the air blast Fig. 12-14: Camera image applanation 2 Strongest curvature  shows the strongest curvature of the cornea from the air blast; in other words, the apex at the greatest distance from its original position Fig.
  • Page 43 12 Perform a Measurement Print teh results of the measurement (5)  Press this button to print measurement results. Note The printer uses thermal paper. The readability of the thermal paper is re- duced by ageing.  Copy the prints to keep the measurement results safely. Instruction Manual Corvis®...

  • Page 44: Change Settings

    13 Change settings 13 Change settings Here you can adjust the default settings for your individualized measure mode. Fig. 13-1: Switch to [Settings] screen  Press this button to display the "Settings 1" screen. On each screen you can set the values as follows: ...

  • Page 45: Settings 1

    13 Change settings 13.1 Settings 1 You can configure the measurement start and display settings on the "Set- tings 1" screen.  Press this button to get to the "Settings 1" screen. Fig. 13-2: Display: Settings 1 Measure Mode Group Box: Measure Mode Here you can view the combinations of the measuring functions:...

  • Page 46: Settings 2

    13 Change settings  Enable the check box "Save Video": The video of the cornea deforma- tion process is stored in the examination data.  Enable the "Load Video" checkbox: The video is also loaded when load- ing an examination. ...
  • Page 47 13 Change settings Set parameters for the start-up screen Group Box: Start-up screen  Enable the radio button "Pat.List" to start the Patient Data Manage- ment on start-up.  Enable the radio button "Measure Mode" to start a measurement right after start-up.
  • Page 48 13 Change settings Select contact control of the touch screen Group Box: Kbd Mode  Select the contact control of the touch screen: "Key Down": Character input through direct contact with the touch screen "Key Up": Character input by releasing the Touch Screen "Key Up+": Character input by releasing the Touch Screen In addition, the entered character is also displayed on the display: Fig.

  • Page 49: Settings 3

    Note Settings 4/4 is used only for service purposes. These settings can only be set by the OCULUS service or authorized distributors. Instruction Manual Corvis® ST (GA/72100/0213/ja) 41 / 92...

  • Page 50: Working With The Corvis® St On A Pc

    14 Working with the Corvis® ST on a PC 14 Working with the Corvis® ST on a PC You must have the following programs installed on your PC: Corvis® ST program  Patient Data Management program  "Grabber" program  If you have connected the Corvis®...

  • Page 51: Connecting The Corvis® St With A Pc

    15 Connecting the Corvis® ST with a PC Connecting the Corvis® ST with a PC This chapter offers you information how to connect the Corvis® ST with an external PC and which settings have to be made. 15.1 Installing the Corvis® ST Software You will find detailed information in the Software Installation.

  • Page 52: Installing The Driver Softwaren

    15 Connecting the Corvis® ST with a PC 15.2 Installing the Driver Softwaren If applicable you have to install the driver software. Administrator rights are required.  Open the drive of the device software in Windows Explorer: C:\CORVIS\DRIVER  Double click "Setup.exe" to start the installation ...

  • Page 53: Settings In The Patient Data Management: "Interface" Tab

    15 Connecting the Corvis® ST with a PC 15.5 Settings in the Patient Data Management: "Interface" tab Further information in sect. 15.6, page  Open patent data management.  Select „Settings" > „Interface. 1 [Enable] check box 2 Settings for Grabber import Fig.

  • Page 54: Start Patient Data Management

    15 Connecting the Corvis® ST with a PC 15.6 Start Patient Data Management You can use the patient data from the Corvis® ST with the Patient Data Management user interface. To do this, you have to transfer the data using a USB cable, or load the data from the USB flash drive.

  • Page 55: Importing Patient Data

    15 Connecting the Corvis® ST with a PC 15.7 Importing patient data You can import patient data from a USB flash drive, see sect. 13, page Note Loss of data due to computer viruses Computer viruses can cause loss of data. ...

  • Page 56: Enter A New Patient

    15 Connecting the Corvis® ST with a PC  In the dialog box, select the directory or the file on the USB flash drive where the patient data is located: .DAT and .BMP.  Confirm your selection with [OK] or [Save]. The patients that are located and the associated examinations are dis- played in the lower part of the dialog.

  • Page 57: Select An Existing Patient

    15 Connecting the Corvis® ST with a PC 15.7.2 Select an existing patient The patient list on the left-hand side of the screen displays all previously ex- amined patients in alphabetical order. Fig. 15-7: Patient list  Press the [Search] button to quickly find the patient you require in the list.

  • Page 58: Use Other Functions Of The Patient Data Management Software

    15 Connecting the Corvis® ST with a PC 15.8 Use other functions of the Patient Data Management software When you have completed an examination, you can  work with the results on your PC, sect. 14, page 42 continue processing the patient data in Patient Data Management ...

  • Page 59: Data Backup

    15 Connecting the Corvis® ST with a PC The options for import and export of data are set as defaults in the "set- tings" field, see also sect. 15.12, page Depending on the settings you may not have to perform all of the following steps (e.g.

  • Page 60: Backup Data

    15 Connecting the Corvis® ST with a PC The general rules for security backups apply to backup copies created with the help of the Patient Data Management user interface. Storage of backup files should always be done on a separate system (e.g. on a USB flash drive with adequate capacity).

  • Page 61: Reconstruct Data

    15 Connecting the Corvis® ST with a PC 15.11.2 Reconstruct data If a loss of data occurs, the data from a previous backup can be re-imported into the Patient Data Management user interface.  Press the [...] button to the right of the "Backup directory" box (3). ...

  • Page 62: Main" Tab

    15 Connecting the Corvis® ST with a PC The following information and buttons are available to you on all tabs: The version of the Patient Data Management program is displayed on  the lower right (3). There are two buttons below and to the left for saving (1) or discarding ...
  • Page 63 15 Connecting the Corvis® ST with a PC "Optional items for patient" box Besides the five standard attributes of first name, last name, date of birth, gender, and ID, up to five additional attributes can be freely defined.  Enter the identifiers for the attributes in the fields Option 1 to 5, for example, "Comments".

  • Page 64: Devices" Tab

    15 Connecting the Corvis® ST with a PC The selection of attributes in the context menu is done in the same manner. The currently selected attributes are marked with a check. 15.12.2 "Devices" tab Drop-down list for selecting a database Path for the currently selected device "Load while starting"...

  • Page 65: Import/Export" Tab

    15 Connecting the Corvis® ST with a PC activate a user (or the assigned database) in this list. The patient list and the associated examinations are updated when the active user is changed.  You can also select the "load while starting" option (2) for exactly one user.
  • Page 66 15 Connecting the Corvis® ST with a PC "Automatic backup" box In addition to the manually executed backup (sect. 15.11, page 51), there is also the option to perform a backup when the Patient Data Management user interface is closed. The settings required for this can be specified in the group box.

  • Page 67: Email" Tab

    15 Connecting the Corvis® ST with a PC 15.12.4 "Email" tab Select e-mail connection SMTP connection selection Standard text for subject and body text Fig. 15-17: "Email" tab With the three radio buttons in the upper part of the tab (1), you can deter- mine whether the email connection is active, and if it is, how the transfer of data should take place.

  • Page 68: Interface" Tab

    15 Connecting the Corvis® ST with a PC 15.12.5 "Interface" tab Settings for HL7 Settings for Grabber Import Settings for GDT Inbox for Grabber import. Settings for Default.pat Fig. 15-18: "Interface" tab Use this tab to enter the folder for different interface types and to enable or disable them.

  • Page 69: Smartcardreader" Tab

    15 Connecting the Corvis® ST with a PC 15.12.6 "Smartcardreader" tab [Config] button [Active] checkbox Fig. 15-19: "Smartcardreader" tab You can configure a smartcard reader on this tab to be able to directly im- port patient data from the patient's insurance card into the Patient Data Management user interface.

  • Page 70: Misc" Tab

    15 Connecting the Corvis® ST with a PC 15.12.7 "Misc" tab   1 Checkbox to manage the Check box to import a database database Fig. 15-20: "Misc" tab The Patient Data Management user interface is available in two different versions: V2.x and V6.x.

  • Page 71: Reconcile Directory Paths

    15 Connecting the Corvis® ST with a PC 15.13Reconcile directory paths In order for the Corvis® ST examination results to be automatically exported to your PC/laptop with the USB cable, the directory paths in the Grabber software and Patient Data Management software have to be reconciled. ...

  • Page 72: The Corvis® St Program On The Pc

    Double-click the selected patient name to start the Corvis® ST pro- gram.  After selecting a patient: press the [Corvis ST] button to start the Cor- vis® ST program. Fig. 16-1: Start Corvis® ST program 16.2 Working with the Corvis® ST program If you started the Corvis®...
  • Page 73 16 The Corvis® ST Program on the PC An overview of the measurement is shown. 1 Patient and examination data 5 Video buttons 2 Corneal deformation parameters 6 Image buttons 3 IOP / Pachy values 7 Menu bar 4 Camera image Fig.

  • Page 74: Patient And Examination Data View (1)

    16 The Corvis® ST Program on the PC 16.3 Patient and examination data view (1) On each screen of the Corvis® ST program the patient and examination data are displayed. 16.4 Working with the Menu Bar (7) You can access the menu bar from any screen of the Corvis® ST. Fig.
  • Page 75 16 The Corvis® ST Program on the PC Export videos and images  Select the menu item [Export] and then click on the desired item. Export Examination Video 1 [Codec options] button [Include examination information] checkbox 2 Drop-down list [Export Video] button Fig.
  • Page 76 16 The Corvis® ST Program on the PC Export Examination Images 1 [Export all] radio button [Include examination information] checkbox 2 [Export one Image] radio button [Export sequence] radio button 3 Slider to display the sequences [Export] button Fig. 16-5: Export images Export All Images ...
  • Page 77 16 The Corvis® ST Program on the PC  Specify the destination directory for the export. The images are automatically numbered and saved in .jpg format. Change settings  Select the menu item [Export] and then click on the desired item. The following screen appears: 1 "General"...
  • Page 78 16 The Corvis® ST Program on the PC Change general settings (1)  Enable the check box "Show curves" - the front and back are shown in red and green colors:  Enable the "Start video after loading" checkbox: The video will contin- ue to play while an examination is loading.

  • Page 79: Show Corneal Deformation Parameter In Enlarged View

    16 The Corvis® ST Program on the PC 16.5 Show corneal deformation parameter in enlarged view  Click on the curve that you want to enlarge, see Fig. 16-2, page item 2 For more information see page 29. 16.6 View IOP / Pachy values In this table, the curve values are shown in figures Fig.

  • Page 80: Csv Files

    17 CSV Files 17 CSV Files The data of th examinatios can be transferred to an Excel file.  The Corvis® ST program creates automatically files (CSV files) which can be opened with Excel. 17.1 Generate CSV Files  Open the patient data management. Fig.

  • Page 81: Export Data With Call-All

    17 CSV Files 17.1.1 Export Data with Call-All Call all examinations of all patients (F11)  In the Patient Data Management Menu, click the shortcut "F11". The following window is displayed. Fig. 17-2: “ Automatic Examination Call“ window  You cab choose between the following options. Name Description CALL-ALL...
  • Page 82 17 CSV Files You can find them in your selected database-folder. Database path Fig. 17-3: Tab “Devices“ Note Creating new CSV-files by the CALL-ALL routine can take a long time, de- pending to the amount of the data. We recommend to perform this procedure at the end of a day or on a week- end.
  • Page 83 17 CSV Files The following window is displayed:  Confirm by clicking [OK]. The following window is displayed. Fig. 17-5: “ Automatic Examination Call“ window  Activate the automatic examination call by clicking [OK]. All examinations of all patients will be appended to already existing CSV- files.

  • Page 84: Content Of A Csv File

    17 CSV Files 17.2 Content of a CSV file If you open a CSV file an Excel file with the following parameters will be generated. Date information The format for date information corresponds with that which is set in the Corvis®...

  • Page 85: Cleaning, Disinfection And Maintenance

    18 Cleaning, Disinfection and Maintenance 18 Cleaning, Disinfection and Maintenance This chapter describes how to clean, disinfect, and maintain the Corvis® ST. Attention Electrical Shock Hazard  Unplug the power cord before cleaning the cabinet, disinfecting the device, or performing maintenance. Note Equipment damage due to moisture ...

  • Page 86: Clean The Front Panel

    18 Cleaning, Disinfection and Maintenance 18.1.1 Clean the front panel 1 Forehead rest Lens protection glass 2 Air nozzle Chin rest Fig. 18-1: Clean lens protection glass and air nozzle Clean forehead (1) and chin (4) rests During the measuring process, sweat, cosmetics, etc. from the patient can get on the forehead and chin rest.
  • Page 87 18 Cleaning, Disinfection and Maintenance Clean lens protection glass (3) The openings in the housing for the optics are covered by protective glass covers which must be kept dust and dirt-free.  Clean the lens protection glass with a lint-free cloth moistened with alcohol.

  • Page 88: Cleaning The Housing

    18 Cleaning, Disinfection and Maintenance 18.1.2 Cleaning the housing Wipe the forehead rest after each examination, and the housing as required.  Turn the Corvis® ST off, “Switching off the Corvis® ST” on page  Unplug the power cord.  When cleaning, use a damp cloth and make sure that no liquid enters the Corvis®...

  • Page 89: Disinfection

    18 Cleaning, Disinfection and Maintenance 18.2 Disinfection Required materials: Disinfection and Cleaning Kit (included),   Alternatively: Pursept®-A Xpress disinfectant wipes,  Merz+Co company D-60318 Frankfurt: Tel: +49 69 1503 1 Fax: +49 (69) 596 21-50 E-mail: merzpr@merz.de  Turn the Corvis® ST off, “Switching off the Corvis®...

  • Page 90: Maintenance

    18 Cleaning, Disinfection and Maintenance Note Equipment damage due to disinfectant solution The disinfectant solution may damage the finish if it is sprayed directly on  Only spray the disinfectant solution onto a cleaning cloth, not directly on the device 18.3 Maintenance ...

  • Page 91: Insert New Printing Paper Roll

    18 Cleaning, Disinfection and Maintenance 18.5 Insert new printing paper roll  Open the cover with the display. Fig. 18-4: Open the cover with the display The following screen appears: Fig. 18-5: Change printer paper You can advance and reverse the printer paper by pressing the buttons "Printer Feed"...
  • Page 92 18 Cleaning, Disinfection and Maintenance  Remove the feed roller from the holder and pull the metal pin out.  Push the metal pin into a new printer roller and insert the printer roller into the holder.  Slide the white paper through the slot from below. ...

  • Page 93: Dismantling, Transport And Storage

    19 Dismantling, transport and storage 19 Dismantling, transport and storage Before you transport or store the Corvis® ST you may have to dismantle it properly. 19.1 Removal  Switch off the Corvis® ST with the On/Off Switch (3).  Unplug the power cord. ...
  • Page 94 19 Dismantling, transport and storage  Lock the transport safety device (2). Press down gently on the transport safety device and turn it counter- clockwise to the "unlocked" position (3). The transport safety device must be engaged. Opening of the transport safety device Spring "Locked"...

  • Page 95: Transport And Storage

    20 Disposal of Used Devices 19.2 Transport and Storage The transport and storage conditions according to IEC 60601-1 with the ap- propriate packaging are valid for a period of up to 15 weeks, see 92. Note Equipment damage due to incorrect lifting If the Corvis®...

  • Page 96: Troubleshooting

    21 Troubleshooting 21 Troubleshooting Attention Persons or equipment damage due to incorrect troubleshooting  Do not plug in or unplug any cables while the Corvis® ST is switched  If an error occurs which you are unable to correct by following the in- structions below, label the device as "out of order"...

  • Page 97: Terms Of Warranty And Servicing

    On request, and for this purpose, OCULUS will supply authorized per-  sons with spare parts lists and additional descriptions. Make sure that only original OCULUS parts are used for service and  maintenance. Instruction Manual Corvis® ST (GA/72100/0213/ja)

  • Page 98: Address Of The Manufacturer And Service Department

    22.2 Address of the manufacturer and service department Our service department or authorized representatives will furnish you with additional information. Address of the manufacturer and service depart- ment: Germany: OCULUS Optikgeräte GmbH Münchholzhäuser Straße 29 35582 Wetzlar, Germany Tel.: 06412005-0 Fax: 06412005-255 E-mail: sales@oculus.de...

  • Page 99: Declaration Of Conformity

    23 Declaration of conformity 23 Declaration of conformity OCULUS OCULUS Optikgeräte GmbH Münchholzhäuser Str.29 KONFORMITÄTSERKLÄRUNG / D-35582 Wetzlar DECLARATION DE CONFORMITE / Tel: ++49 641 / 20 05 – 0 Fax: ++49 641 / 20 05 - 255 DECLARATION OF CONFORMITY /...

  • Page 100: Technical Data

    24 Technical Data 24 Technical Data Measure Mode IOP + pachymetry Tonometer Measuring range 6 to 60 mmHg Working distance 11 mm (0.4 in) Scheimpflug camera Frame Rate 4330 frames/s Measuring range 8.5 mm (0.3 in) horizontal cov- erage  Pachymeter measuring range 300 to 1200 Measuring points...
  • Page 101 24 Technical Data Electrical Specifications Power input 49.5 VA Voltage External 110/220 VAC Frequency 50/60 Hz Fuses Built-in overcurrent shutdown Other information Dimensions (W x D x H) 270 x 520 x 495-520 mm (10.7 x 20.5 x 19.5-20.5 in Weight approx.

  • Page 102: Appendix

    Medical Electrical Equipment needs special precautions regarding EMC, and must be installed and operated according to the accompanying information contained in the EMC documentation. No special measures need to be observed for OCULUS devices and systems. Portable and mobile HF sets can interfere with electrically operated medical devices.

  • Page 103: Guidelines And Manufacturer's Declaration  Electromagnetic Immunity

    Electromagnetic immunity Electromagnetic radiation, IEC 60601-1-2, 6.8.3.201, Table 201 The Corvis® ST from OCULUS is intended for use in the electromagnetic environment specified below. The user of the Corvis® ST should ensure that it is used in such an environment.
  • Page 104 25 Appendix Electromagnetic immunity, IEC 60601-1-2, 6.8.3.201, Table 202 IEC 60601-  Immunity tests Conformity level Electromagnetic environment - Test level Guidelines Electrostatic discharge ± 6 kV contact ±6 kV Floors should be wood, concrete (ESD) according to IEC 61000-4-2 discharge...
  • Page 105 25 Appendix Electromagnetic immunity, IEC 60601-1-2, 6.8.3.201, Table 204 Immunity IEC 60601 test Conformity level Electromagnetic environment - Guidelines tests level Conducted HF = 3 V Portable and mobile RF communications equip- eff  disturbances ac- 150 kHz to 80 MHz ment, including the cables, should not be used ...
  • Page 106 25 Appendix Recommended separation distances between portable and mobile  Electromagnetic radiation, IEC 60601-1-2, 6.8.3.201, Table 206 The Corvis® ST is designed to operate in an electromagnetic environment in which HF disturbances are controlled. The user of the Corvis® ST can help to prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the device - depending on the specified output power of the communication device, as shown below.

  • Page 107: Index

    Index Index Corneal deformation parameters 29 Corneal speed 30 Adjust Corvis® ST settings 36 Corvis® ST 36 Cross slide 8 Adjust height 24 Adjusting base 8 Adjustment 23, 24 Daily operation 14 Air nozzle 9 Declaration of Conformity 91 Clean 79 Deformation amplitude 29 Applanation 33, 34 Delivery 1...
  • Page 108 Index Interface Grabber 39 Menu bar 66 IOP values 31, 71 Program 64 View examination data 66 View patient data 66 Joystick 8, 15, 25 Power strip 5 Joystick button 15 Power supply 93, 94 Printout Configure 41 Control 9 Footer 41 Illumination of the eye 9 Protection class 2...
  • Page 109 Index Software Installieren 43 Start-up 11 Stop Adjusting base 9 Storage 87 Storage conditions 92 Strongest curvature 34 Switching off 14 Switching on 14 Target group 4 Technical data 92 Touch Screen 16 Training 4, 11 Transfer data 36 Transport 7, 87 Transport conditions 92 Transport safety device Lock 86...
  • Page 110 Index 102 / 102 Instruction Manual Corvis® ST (GA/72100/0213/ja)
