Secos - Simplex Energy Control System
5.

Technical data

5.1. General
Secos energy saving controller
Number of connectable room thermostats
Number of operable heating circuits per control zone
Dimensions H x W x D
Protection code
Permissible ambient conditions
Supply voltage
Power consumption
Output voltage for circulating pump
Interface for building management system
Frequency range for wireless connection
Maximum transmitting power
Secos system manifolds
Number of heating circuits
Dimensions
Max. operating temperature:
Max. operating pressure:
Volume flow per heating circuit
Operating medium:
Pressure loss system manifold complete
Primary connections
Secondary connections
Material of manifold bar
Material of valves
Secos supply line temperature sensor
Closing stroke ceramic valve
Secos actuator
Dimensions H x W x D
Operating temperature
Protection code
Secos multisensor
Measuring range for flow rate
Measuring range for temperature
Sensor characteristics
Temperature 10 °C
Multisensor [Ω] 52.0
Temperature sensor 1039
for supply line [Ω]
15 °C 20 °C 25 °C 30 °C
52.9 53.9 54.9 55.8
1058 1078 1097 1117
Up to 8
1 - 14 heating circuits
328 x 97 x 61 mm
IP 20
-10 - 60 °C, max. relative humidity 80 %, air pressure 750 - 1050 hPa
230V AC / 50-60 Hz
max. 500 W
230V AC / 50-60 Hz
Modbus RTU
2402 - 2484 MHz
5 dBm
4 - 14 heating circuits
(See Dimensions table)
75 °C
10 bar
0 - 8 l/min
Heating water according to VDI 2035
kvs 1.19 m³/h
G1" F
G3/4" M Eurocone
Stainless steel
ceramic disc valves
Ø 6 x 50 mm
90°
47 x 77 x 57 mm
-10 to 60 °C
IP 20
0 - 8 l/min
+10 to +75 °C
35 °C 40 °C 45 °C 50 °C
56.8 57.8 58.7 59.7
1136 1155 1175 1194
The illustrations are symbolic and may deviate from the respective product.
Subject to technical modifications and errors.
EN
55 °C 60 °C 65 °C 70 °C
60.7 61.6 62.6 63.5
1213 1232 1251 1271
Product range
75 °C
64.5
1290
