Installation instructions | Operating instructions
Secos - Simplex Energy Control System
Terminal
Description
designation
Shield
Screen interface
GND BUS
Ground interface
A
Channel A for data communication interface
B
Channel B for data communication interface
+24V BUS
Power supply interface
System bus
Reverse-polarity-protected plug to the system manifold
GND
Ground analogue output switching valve 0 - 10 V
AO
Signal analogue output switching valve 0 - 10 V
GND
Ground external condensation monitor
0..20 mA
-
0..10V
Input signal external condensation monitor
+24V 40mA
Power supply of external condensation monitor
pt-
Temperature sensor for supply line, polarity freely selectable
pt+
Temperature sensor for supply line, polarity freely selectable
C/O GND
Ground changeover (potential-free)
C/O IN
Input signal changeover (potential-free)
L1 – L8
Power supply of the room thermostats
N1 – N8
Neutral conductor of the room thermostats
Switching signal of the respective room thermostats
Output lowering signal for room thermostat 1 - 7 (slave)
out 1 - 7
Input lowering signal from room thermostat 8 (master)
in
C/O out
Changeover signal for display on room thermostat 8 (Master)
L out
Phase pump for 230 V output
N out
Neutral conductor for 230 V output
Protective conductor for 230 V output
Protective conductor for power supply system
L
Phase energy supply system
N
Neutral conductor for power supply system
20
Secos - Simplex Energy Control System
EN
Interface to building management systems
(BMS) and other systems. Table with data
points available in a separate document
"Connectivity Guide". The document can be
downloaded from the following address: www.
simplex-armaturen.de/manuals/secos.
