This Operator's Manual is an integral part of the safe operation of this

machine and must be maintained with the unit at all times. READ,

UNDERSTAND, and FOLLOW the Safety and Operation Instructions

contained in this manual before operating the equipment. C01-Cover

Schulte Industries Ltd.

PO Box 70

Englefeld Saskatchewan

Canada S0K 1N0

Tel. (306) 287-3715

Fax. (306) 287-3355

Parts Fax. (306) 287-4066

Web: www.schulte.ca

SRW1000

PIVOTING ROCK WINDROWER

S/N R90010001708-R90010040804 Inclusive

OPERATOR'S MANUAL

Part No. R900-010C

Table of Contents

Summary of Contents for Schulte SRW1000

Page 1 READ, UNDERSTAND, and FOLLOW the Safety and Operation Instructions contained in this manual before operating the equipment. C01-Cover Schulte Industries Ltd. PO Box 70 Englefeld Saskatchewan Canada S0K 1N0 Tel.
Page 2 To the Owner/Operator/Dealer All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded operator who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to be used with all its safety equipment properly attached to minimize the chance of accidents.
Page 3 DEALER’S PREDELIVERY SERVICE GUIDE for the SCHULTE SRW1000 DETAILS OF ITEMS LISTED BELOW ARE COVERED IN THIS OPERATOR’S MANUAL ____Shipping damage corrected ____Set up machine as outlined in the shipping instructions attached to these instructions. ____Check that all safety decals are in good condition, replace if necessary.
Page 5: Table Of Contents
Table of Contents SAFETY SECTION ......................1-1 GENERAL SAFETY INSTRUCTIONS AND PRACTICES ................1-2 OPERATOR SAFETY INSTRUCTIONS AND PRACTICES ................1-3 EQUIPMENT OPERATION SAFETY INSTRUCTIONS AND PRACTICES ............1-5 CONNECTING OR DISCONNECTING IMPLEMENT SAFETY INSTRUCTIONS AND PRACTICES ....1-8 TRANSPORTING SAFETY INSTRUCTIONS AND PRACTICES ..............1-9 MAINTENANCE AND SERVICE SAFETY INSTRUCTIONS AND PRACTICES ..........
Page 6 DRIVELINE ATTACHMENT ..........................4-12 PRE-OPERATION INSPECTION AND SERVICE ................... 4-12 Tractor Pre-Operation Inspection/Service ....................... 4-13 Windrower Pre-Operation Inspection/Service ....................4-13 DRIVING THE TRACTOR AND IMPLEMENT ....................4-19 Starting the Tractor ............................4-20 Brake and Differential Lock Setting ......................... 4-20 Working Position .............................. 4-20 Crossing Ditches and Steep Inclines .......................
Page 8: General Safety Instructions And Practices
Safety Messages. Always use good common sense to avoid hazards. (SG-2) Si no lee ingles, pida ayuda a alguien que si lo lea para que le traduzca las medidas de seguridad. (SG-3) SRW1000 08/17 Safety Section 1-2 © 2017 Alamo Group Inc.
Page 9: Operator Safety Instructions And Practices
(SG-I7) Always read carefully and comply fully with the manufacturer’s instructions when handling oil, solvents, cleansers, and any other chemical agent. (SG-22) SRW1000 08/17 Safety Section 1-3 © 2017 Alamo Group Inc.
Page 10 Be sure you have adequate knowledge of the property you will be working on. Take time to make yourself aware of any area underwater or underground lines or cables. Contact with buried lines or cable could result in serious injury or death. (STL-1) SRW1000 08/17 Safety Section 1-4 © 2017 Alamo Group Inc.
Page 11: Equipment Operation Safety Instructions And Practices
Place the tractor shift lever into a low range or parking gear to prevent the tractor from rolling. Never dismount a Tractor that is moving or while the engine is running. Operate the Tractor controls from the tractor seat only. (SG-9) SRW1000 08/17 Safety Section 1-5 © 2017 Alamo Group Inc.
Page 12 (SG-23) Do not exceed the rated PTO speed for the Implement. Excessive PTO speeds can cause Implement driveline or blade failures resulting in serious injury or death. (SG-26) SRW1000 08/17 Safety Section 1-6 © 2017 Alamo Group Inc.
Page 13 Stop the Tractor and Implement immediately if a bystander or animal comes near the equipment. (STL-13) Raise the unit to the transport position and secure with the retaining pins before traveling on public roads and when storing. (STL-16) SRW1000 08/17 Safety Section 1-7 © 2017 Alamo Group Inc.
Page 14: Connecting Or Disconnecting Implement Safety Instructions And Practices
Use the Tongue Jack for lifting the Implement only. Overloading the Tongue Jack can cause failure with possible serious bodily injury or even death. (STI-04) SRW1000 08/17 Safety Section 1-8 © 2017 Alamo Group Inc.
Page 15: Transporting Safety Instructions And Practices
Implement behind a truck or other type of vehicle. Never tow the Implement and another Implement connected in tandem. Never tow the Implement at speeds over 20 MPH. (STI-06) SRW1000 08/17 Safety Section 1-9 © 2017 Alamo Group Inc.
Page 16: Maintenance And Service Safety Instructions And Practices
Implement, any of its components or any Implement function. (SG-8) Never attempt to lubricate, adjust, or remove material from the Implement while it is in motion or while tractor engine is running. (SG-20) SRW1000 08/17 Safety Section 1-10 © 2017 Alamo Group Inc.
Page 17 These parts are made and tested to Schulte Industry specifications. Non-genuine "will fit" parts do not consistently meet these specifications. The use of “will fit” parts may reduce the performance, void Schulte warranties, and present a safety hazard. Use genuine Schulte parts for economy and safety.
Page 18: Concluding Safety Instructions And Practices
Safety Messages and operation instruction in each of the appropriate sections of the Tractor and Equipment Manuals. Pay close attention to the Safety Signs affixed to the Tractor and Equipment. (SG-18) SRW1000 08/17 Safety Section 1-12 © 2017 Alamo Group Inc.
Page 20 SAFETY NOTE: Schulte supplies safety decals on this product to promote safe operation. Damage to the decals may occur while in shipping, use, or reconditioning. Schulte cares about the safety of its customers, operators, and bystanders, and will replace the safety decals on this product in the field, free of charge (Some shipping and handling charges may apply).
Page 27: Federal Laws And Regulations
Some regulations specify that no one under the age of 16 may operate power machinery. It is your responsibility to know what these regulations are in your own area or situation. (Refer to U.S. Dept. of Labor, Employment Standard Administration, Wage & Home Division, Child Labor Bulletin #102.) SRW1000 08/17 Safety Section 1-21 © 2017 Alamo Group Inc.
Page 30 When ordering replacement parts for the Gearboxes and the Drivelines, be sure to specify the serial number. The serial number is located on the left hand side attached to the SRW1000 hitch pole. Driveline Integral Shields, and Gearbox Shields are standard equipment and are to be used at all times.
Page 31 NOTE: Warranties are honored only if completed “Owner Registration and Warranty” forms are received by Schulte within thirty days of delivery of the implement. 3. Record the Windrower Model and Serial Numbers on the Warranty page at the front of the Operator’s Manual.
Page 34: Srw-1000 Assembly From Shipping Configuration
• Guard Rods (Left and Right) • Driveline 2. Attach lifting device to both the drum and the Drum Carriage to keep the drum from falling when removing shipping brackets. SRW1000 08/17 Assembly Section 3-2 © 2017 Alamo Group Inc.
Page 35 ASSEMBLY 3. Remove shipping brackets and mount plates. 4. The lower drum clamps are used to assemble the machine. The rest of the brackets can be discarded. SRW1000 08/17 Assembly Section 3-3 © 2017 Alamo Group Inc.
Page 36 6. Raise Drum and Carriage assembly into place and attach with drum clamps that were removed in step 4. 7. Install the Hydraulic Cylinder to the Drum Carriage and Main Frame. Clamp Hydraulic Hoses to the main frame using the bolts on the frame. SRW1000 08/17 Assembly Section 3-4 © 2017 Alamo Group Inc.
Page 37 8. Install the Light Mount Bars. Bars should be set to the out most part of the frame. The Main Harness wire should be run along the frame in the same location and style as the Hydraulic Hoses. 9. Install the Rubber Assembly. SRW1000 08/17 Assembly Section 3-5 © 2017 Alamo Group Inc.
Page 38 ASSEMBLY 10. Install Driveline. 11. Install Rod Guards; one on each side of drum. SRW1000 08/17 Assembly Section 3-6 © 2017 Alamo Group Inc.
Page 39 A setting higher than 2-1/4” may result in the tires contacting the drum. Also see “Operating the Windrower” in the Operation Section of this manual. SRW1000 08/17 Assembly Section 3-7 © 2017 Alamo Group Inc.
Page 40: Before Operation
Check tire inflation pressure. Higher pressures may cause excessive bouncing over rough ground. Lower pressure may cause excessive wear. Refer to maintenance section for recommended tire pressure. Gearbox output driveline should be installed with the shear bolt torque limiter at the gearbox. SRW1000 08/17 Assembly Section 3-8 © 2017 Alamo Group Inc.
Page 41: Drum Sprocket
Using the supplied wrench, pre-load the tightener until the slot lines up with 1/2" bolt hole in the side plate and the bolt can be inserted. Tighten both bolts. SRW1000 08/17 Assembly Section 3-9 © 2017 Alamo Group Inc.
Page 42: Transport Lock Pin
(Note: These shields may also be chained.) The shields must be regularly greased and checked that they rotate freely on the driveline. Refer to the Lubrication section for greasing intervals. SRW1000 08/17 Assembly Section 3-10 © 2017 Alamo Group Inc.
Page 43: Light Kit
Secure with 1/2” locknuts provided. Installation of Lights Install the lights onto the light bars using 5/16” hardware provided. Ensure that the red lights are inside and facing to the rear. SRW1000 08/17 Assembly Section 3-11 © 2017 Alamo Group Inc.
Page 44: Pre-Delivery Customer Checklist
Is machine equipped with proper operator protection  Is drum rotation correct? Are teeth hard surfaced?  Does implement operate smoothly at normal operating speed? Implement should not vibrate excessively. SRW1000 08/17 Assembly Section 3-12 © 2017 Alamo Group Inc.
Page 46 SRW1000, tractor, or a thrown object. Do not operate the SRW1000 if passersby, pets, livestock, or property are within 25 feet of the unit.
Page 47: Standard Equipment & Specifications
Always Wear Safety Glasses • Hard Hat • Steel Toe Safety Footwear • Gloves • Hearing Protection • Close Fitting Clothing • Respirator Filter Mask (depends operating conditions) OPS-U- 0002 SRW1000 08/17 Operation Section 4-3 © 2017 Alamo Group Inc.
Page 48: Tractor Requirements
Tractor Safety Devices ......Slow Moving Vehicle (SMV) emblem, lighting, PTO master shield • Tractor Horsepower -Recommended ..SRW1000 40-80 HP (30-60kW) • Drawbar............Set length according to operating speed and driveline type, rated to carry weight of the mower, safety chain attachment point •...
Page 49: Tractor Safety Devices
The recommended tractor HP for the SRW1000 is 40-80 HP (30-60 kW). Operating the implement with a larger tractor will greatly increase the risk of damaging the implement.
Page 50: Power Take Off (Pto)
Before getting onto the tractor, the operator must read and completely understand the implement and tractor operator manuals. If any part of either manual is not completely understood, consult an authorized dealer for a complete explanation. OPS-U- 0007 SRW1000 08/17 Operation Section 4-6 © 2017 Alamo Group Inc.
Page 51: Boarding The Tractor
Place the tractor shift lever into a low range or parking gear to prevent the tractor from rolling. Never dismount a Tractor that is moving or while the engine is running. Operate the Tractor controls from the tractor seat only. (SG-9) SRW1000 08/17 Operation Section 4-7 © 2017 Alamo Group Inc.
Page 52: Starting The Tractor
Use extreme caution when connecting the SRW1000 to the tractor. The SRW1000 should be securely resting at ground level with the parking jack foot. Place a block in front of and behind wheels to prevent the SRW1000 from moving. Keep hands and feet out from under the SRW1000 and clear of pinch points between the tractor and SRW1000.
Page 53: Connecting The Windrower Tongue To The Tractor
Implement and Tractor hitches. (S3PT-15) 4. To attach the SRW1000 insert the hitch pin through the drawbar and tongue clevis. Once the pin is inserted, attach the snap ring pin through the hole on the hitch pin and snap in place.
Page 54: Safety Tow Chain
Never leave a disconnected hose end open and cap the tractor hydraulic outlet ports when not in use. If the tractor ports, SRW1000 ports and hydraulic hose ends become contaminated, wipe clean with a rag before connecting.
Page 55: Setting The Windrower
4. Loosen the bolts holding the axle plates, and adjust the plates so the right axle is 1” lower than the left axle plate. This is to help bring material to the surface. Periodically re-check the tightness of the axle plate bolts especially before transporting the machine on public roads. SRW1000 08/17 Operation Section 4-11 © 2017 Alamo Group Inc.
Page 56: Driveline Attachment
Never work under the Implement, the framework, or any lifted component unless the Implement is securely supported or blocked up to prevent sudden or inadvertent falling which could cause serious injury or even death. (SG-14) SRW1000 08/17 Operation Section 4-12 © 2017 Alamo Group Inc.
Page 57: Tractor Pre-Operation Inspection/Service
Before each implement use, a complete inspection and service is required to ensure the implement is in a good and safe working condition. Damaged and/or broken parts should be repaired and/or replaced immediately. To ensure the implement is ready for operation, conduct the following. SRW1000 08/17 Operation Section 4-13 © 2017 Alamo Group Inc.
Page 58 • Ensure the driveline slip clutches are properly adjusted and the friction plates are not frozen together. Reference the Maintenance Section for proper slip clutch maintenance. OPS-W- 0007_A SRW1000 08/17 Operation Section 4-14 © 2017 Alamo Group Inc.
Page 59 IMPORTANT: DO NOT use your hands to check for oil leaks. Use a piece of heavy paper or cardboard to check for hydraulic oil leaks. OPS-W-0010 SRW1000 08/17 Operation Section 4-15 © 2017 Alamo Group Inc.
Page 60 Inspect the windrower teeth and make sure that they are hard surfaced and that the bare tooth is not exposed. If the hard surfacing is not properly maintained, highly accelerated tooth wear will result. OPS-W-0012 SRW1000 08/17 Operation Section 4-16 © 2017 Alamo Group Inc.
Page 61 The engine coolant fluid level is full The radiator is free of debris The air filter is in good condition Operator’s Signature:__________________________________________________________________ DO NOT OPERATE an UNSAFE TRACTOR or IMPLEMENT SRW1000 08/17 Operation Section 4-17 © 2017 Alamo Group Inc.
Page 62 Tires are properly inflated and in good condition Wheel lug nuts are tight Transport locks are in good condition Operator’s Signature: ______________________________________________________ DO NOT OPERATE an UNSAFE TRACTOR or IMPLEMENT SRW1000 08/17 Operation Section 4-18 © 2017 Alamo Group Inc.
Page 63: Driving The Tractor And Implement
Such an impact could cause the Implement and Tractor to pivot violently resulting in loss of steering control, serious injury, or even death. Never allow the Implement to contact obstacles. (S3PT-12) SRW1000 08/17 Operation Section 4-19 © 2017 Alamo Group Inc.
Page 64: Starting The Tractor
If the power steering or engine ceases operating, stop the tractor immediately as the tractor will be difficult to control. SRW1000 08/17 Operation Section 4-20...
Page 65 This Implement is capable of throwing objects for significant distances and causing serious injury. Stop the Tractor and Implement immediately if a bystander or animal comes near the equipment. (STL-13) SRW1000 08/17 Operation Section 4-21 © 2017 Alamo Group Inc.
Page 66: Crossing Ditches And Steep Inclines
When crossing such terrain, the implement should be fully lowered for a lower center of gravity and added stability. OPS-R-0021 SRW1000 08/17 Operation Section 4-22 © 2017 Alamo Group Inc.
Page 67: Operating The Tractor And Windrower
Special attention should be paid to foreign debris, rough terrain, steep slopes, and passersby and animals in the area. SRW1000 08/17 Operation Section 4-23 © 2017 Alamo Group Inc.
Page 68: Foreign Debris Hazards
Do not operate this machine with anyone in the immediate area. Stop operating if anyone comes within 25 feet of the equipment. (STL-4) SRW1000 08/17 Operation Section 4-24 © 2017 Alamo Group Inc.
Page 69: Engaging The Power Take Off (Pto)
PTO speed. Do not exceed the rated PTO speed for the Implement. Excessive PTO speeds can cause Implement driveline or blade failures resulting in serious injury or death. (SG-26) SRW1000 08/17 Operation Section 4-25 © 2017 Alamo Group Inc.
Page 70: Operating The Windrower
The drum should be checked frequently for wear. Teeth must be hard surfaced before the bare tooth is exposed. If the hard surfacing is not properly maintained, highly accelerated tooth wear will result. SRW1000 08/17 Operation Section 4-26 © 2017 Alamo Group Inc.
Page 72: Disconnecting The Windrower From The Tractor
5. Remove the hydraulic hoses from the tractor and secure to the windrower to prevent contact with dirt. SRW1000 08/17 Operation Section 4-28 © 2017 Alamo Group Inc.
Page 73: Windrower Storage
If the implement has been exposed to such conditions, at the start of each season, and any time it is suspected that the slip clutch plates may be frozen together, readjust the slip clutch as explained in the maintenance section of this manual SRW1000 08/17 Operation Section 4-29 © 2017 Alamo Group Inc.
Page 74: Transporting The Tractor And Implement
Use extreme caution and avoid hard applications of the tractor brakes when towing heavy loads at road speeds. Never tow the implement at speeds greater than 20 MPH (32 kph). OPS-U- 0018 SRW1000 08/17 Operation Section 4-30 © 2017 Alamo Group Inc.
Page 75: Transporting On Public Roadways
Replace the SMV emblem if faded, damaged, or no longer reflective. OPS-U- 0020 SRW1000 08/17 Operation Section 4-31 © 2017 Alamo Group Inc.
Page 76 Such an impact could cause the Implement and Tractor to pivot violently resulting in loss of steering control, serious injury, or even death. Never allow the Implement to contact obstacles. (S3PT-12) SRW1000 08/17 Operation Section 4-32 © 2017 Alamo Group Inc.
Page 77 Implements, secure the center axle using cylinder stops or transport pin and properly attach a safety chain between the Implement and Tractor. Secure wings in upright position on folding Implements using wing transport locks. (STI-7) SRW1000 08/17 Operation Section 4-33 © 2017 Alamo Group Inc.
Page 78: Hauling The Tractor And Implement
Ensure that the load will be in compliance with the legal limits set for the areas that will be traveled through. OPS-U- 0024 SRW1000 08/17 Operation Section 4-34 © 2017 Alamo Group Inc.
Page 79 If during transport a hard braking, sharp turning, or swerving action was performed, stop at the next safe location to inspect the security of the load. OPS-U- 0026 SRW1000 08/17 Operation Section 4-35 © 2017 Alamo Group Inc.
Page 80: Troubleshooting Guide
Torque limiter slipping Excessive load. Machine is overloaded, reduce ground excessively speed & reduce depth Improper adjustment. Adjust springs. Friction plates worn. Replace plates. Oil on friction plates. Replace plates. SRW1000 08/17 Operation Section 4-36 © 2017 Alamo Group Inc.
Page 82: Nuts And Bolts
[Refer to the “Parts” section]. Do not replace lock nuts with nuts and lock washers. Use only original equipment lock nuts. Recommended Torques in foot pounds for SAE Grade 5 bolts, based on dry assembly: SRW1000 08/17 Maintenance Section 5-2 © 2017 Alamo Group Inc.
Page 83: Drive Chain
. T h e b o l t s s h o u l d b e t i g h t e n e d i n a n alternating pattern to 29 ft.-lbs (39 Nm). SRW1000 08/17 Maintenance Section 5-3...
Page 84: Hubs & Spindles
7. Check dust seal to ensure seal rubber is positioned correctly. 8. Install the small or outer bearing. 9. Install the axle washer and castle nut on the axle. 10. Fill dust cap with grease before re-assembling. SRW1000 08/17 Maintenance Section 5-4 © 2017 Alamo Group Inc.
Page 85: Tightening Instructions For 511 & 517 Hubs
To remove tires for repair or replacement, securely block the frame. Relieve hydraulic pressure Shut off tractor, apply parking brake and disengage PTO. AVOID PERSONAL INJURY. DO NOT work under windrower without support blocks to keep the frame from falling. SRW1000 08/17 Maintenance Section 5-5 © 2017 Alamo Group Inc.
Page 86: Shear Bolt
The springs should be tightened down to the heights indicated in the following illustration. SRW1000 08/17 Maintenance Section 5-6 © 2017 Alamo Group Inc.
Page 87: Lubrication
7. Dispose of the old oil in accordance with the local regulations. Gear case oil should meet the following specifications: -API Service Classifications GL-5 -Military Specification MIL-L-2105C Consult the following chart for the oil viscosity recommendations: SRW1000 08/17 Maintenance Section 5-7 © 2017 Alamo Group Inc.
Page 88: Grease Schedule
• SAE Multi-purpose grease containing 3 to 5 percent molybdenum disulfide Use SAE (NLGI) #2 IMPORTANT: Before attaching the driveline, clean and grease the tractor PTO and the Implement shaft. SRW1000 08/17 Maintenance Section 5-8 © 2017 Alamo Group Inc.
Page 89: Universal Joint Assemblies
When disconnecting from the tractor for a short period of time, use the driveline holders. When storing the rock windrower for an extended period of time, it is recommended the drivelines be removed from machine and stored inside. SRW1000 08/17 Maintenance Section 5-9 © 2017 Alamo Group Inc.
Page 91 GENERAL STATEMENT AFFECTING ALL SCHULTE WARRANTY Schulte Industries Ltd. warrants to the original purchaser only, that in the event of any defect in material or workmanship in the product sold by Schulte Industries, the subject of this warranty (“the goods”) during the warranty period mentioned below the manufacturer will provide the coverage specified below.
Page 92 • The Dealer must keep the failed part until the claim is processed, to allow Schulte Industries the option of further examination of the part.
Page 94 SRW1000 - 08/17 P/N R900-010C Printed Canada...
