User's manual
FLIR T10xx series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T10 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for FLIR T10 Series

Summary of Contents for FLIR T10 Series

  • Page 1 User’s manual FLIR T10xx series Distributed by: Sie haben Fragen oder wünschen eine Beratung? Angebotsanfrage unter 07121 / 51 50 50 oder über info@datatec.de...
  • Page 4 Important note Before operating the device, you must read, understand, and follow all instructions, warnings, cautions, and legal disclaimers. Důležitá poznámka Před použitím zařízení si přečtěte veškeré pokyny, upozornění, varování a vyvázání se ze záruky, ujistěte se, že jim rozumíte, a řiďte se jimi.
  • Page 5 User’s manual FLIR T10xx series #T559954; r. AT/65353/65353; en-US...

  • Page 7: Table Of Contents

    Table of contents Disclaimers ..................1 Legal disclaimer ............... 1 U.S. Government Regulations............1 Patents ................... 1 Quality assurance ..............1 Third-party licenses..............1 Usage statistics ................ 1 Copyright ................1 Safety information ................2 Notice to user ...................6 Calibration................6 Accuracy ................6 Disposal of electronic waste ............
  • Page 8 Table of contents 10.5 Neck strap attachment points ............ 24 10.5.1 Figure ................ 24 10.6 Battery condition LED indicator ..........24 10.6.1 Figure ................ 24 10.6.2 Explanation..............24 10.7 Power LED indicator ..............25 10.7.1 Figure ................ 25 10.7.2 Explanation..............25 10.8 Laser pointer .................
  • Page 9 Table of contents 13.11.2 Procedure ..............38 13.12 Using the camera lamp as a flash ..........38 13.12.1 General..............38 13.12.2 Procedure ..............38 13.13 Moving files to a computer ............39 13.13.1 General..............39 13.13.2 Procedure ..............39 13.14 Changing lenses..............40 13.15 Using the 7°...
  • Page 10 Table of contents 15.3 Creating a new folder............... 56 15.4 Renaming a folder..............56 15.5 Changing the active folder ............57 15.5.1 General..............57 15.5.2 Procedure ..............57 15.6 Moving files between folders ............. 57 15.7 Deleting a folder ..............57 15.8 Deleting an image or video file ...........
  • Page 11 Table of contents 18.5 Changing the measurement parameters ........73 18.5.1 General..............73 18.5.2 Types of parameters ............. 73 18.5.3 Recommended values........... 74 18.5.4 Procedure ..............74 18.5.5 Related topics ............. 75 18.6 Displaying values in the result table..........75 18.6.1 General..............
  • Page 12 26.2 Setting up a wireless access point (most common use) ....102 26.3 Connecting the camera to a WLAN (less common use) ....102 Fetching data from external FLIR meters .......... 103 27.1 General ................103 27.2 Technical support for external meters ........103 27.3...
  • Page 13 34.1 Introduction ................. 124 34.2 Definition—what is calibration? ..........124 34.3 Camera calibration at FLIR Systems ......... 124 34.4 The differences between a calibration performed by a user and that performed directly at FLIR Systems........125 34.5 Calibration, verification and adjustment........125 34.6...

  • Page 15: Disclaimers

    1.7 Copyright © 2020, FLIR Systems, Inc. All rights reserved worldwide. No parts of the software in- cluding source code may be reproduced, transmitted, transcribed or translated into any language or computer language in any form or by any means, electronic, magnetic, opti- cal, manual or otherwise, without the prior written permission of FLIR Systems.

  • Page 16: Safety Information

    WARNING Applicability: Digital devices subject to 15.21. NOTICE: Changes or modifications made to this equipment not expressly approved by FLIR Systems may void the FCC authorization to operate this equipment. WARNING Applicability: Digital devices subject to 2.1091/2.1093/OET Bulletin 65.
  • Page 17 Make sure that you read all applicable MSDS (Material Safety Data Sheets) and warning labels on con- tainers before you use a liquid. The liquids can be dangerous. Injury to persons can occur. CAUTION Only use the camera with a battery that has the item part number T199364 on it (that FLIR Systems supplies). CAUTION Do not point the infrared camera (with or without the lens cover) at strong energy sources, for example, devices that cause laser radiation, or the sun.
  • Page 18 Safety information CAUTION Do not put the batteries in or near a fire, or into direct sunlight. When the battery becomes hot, the built- in safety equipment becomes energized and can stop the battery charging procedure. If the battery be- comes hot, damage can occur to the safety equipment and this can cause more heat, damage or igni- tion of the battery.
  • Page 19 Safety information CAUTION Do not use too much force to clean the infrared lens. This can cause damage to the anti-reflective coating. CAUTION Make sure that the beams from the intensive energy sources do not go into the viewfinder. The beams can cause damage to the camera.

  • Page 20: Notice To User

    3.6 Important note about this manual FLIR Systems issues generic manuals that cover several cameras within a model line. This means that this manual may contain descriptions and explanations that do not apply to your particular camera model.

  • Page 21: Note About Authoritative Versions

    Notice to user 3.7 Note about authoritative versions The authoritative version of this publication is English. In the event of divergences due to translation errors, the English text has precedence. Any late changes are first implemented in English. #T559954; r. AT/65353/65353; en-US...

  • Page 22: Customer Help

    • The communication protocol, or method, between the camera and your device (e.g., SD card reader, HDMI, Ethernet, USB, or FireWire) • Device type (PC/Mac/iPhone/iPad/Android device, etc.) • Version of any programs from FLIR Systems • Full name, publication number, and revision number of the manual 4.3 Downloads...

  • Page 23: Introduction

    Introduction 5.1 General description The FLIR T10xx series is designed for the expert requiring the highest performance and the latest technology available. The camera series combines excellent ergonomics and feature-rich flexibility with superior image quality of 1024 × 768 pixel infrared resolution.

  • Page 24: Quick Start Guide

    7. Push the Save button fully down to save an image. 8. When you have completed the inspection, connect the camera to a computer using the USB cable. 9. Import the images into a FLIR Thermography software and create an inspection report. 6.2 To keep in mind •...

  • Page 25: Register The Camera

    Register your camera to receive an extended warranty and other related benefits. To register the camera, you must log in using a FLIR Customer Support account. If you already have an existing FLIR Customer Support account, you can use the same login credentials.
  • Page 26 Register the camera 3. To create a new FLIR Customer Support account, do the following: 3.1. Click Create a New Account. 3.2. Enter the required information and click Create Account. 4. On the camera, select (Settings) > Device settings > Camera information >...
  • Page 27 Register the camera 5. Select Register and push the joystick. This displays a dialog box with the serial num- ber of the camera. 6. On the computer, enter the serial number of the camera and click Validate. 7. When the serial number is validated, click Continue. #T559954;...
  • Page 28 9. When the registration is completed, the four-digit code is displayed. Note • The code is also sent by e-mail to the address registered with your FLIR Customer Support account. • The code is also displayed in your FLIR Customer Support portal under My Stuff >...
  • Page 29 Register the camera 10. On the camera, do the following to enter the code: • Move the joystick up/down to select a digit. • Move the joystick left/right to navigate to the previous/next digit. • When all digits have been entered, move the joystick right to select Submit. Push the joystick to confirm.

  • Page 30: Using The High-Speed Interface (Hsi)

    The high-speed interface (HSI) is included in the FLIR T10xx SC kit. The high-speed in- terface enables streaming of live video from the FLIR T10xx camera to a PC running the FLIR ResearchIR Max software. The high-speed interface is primarily intended for R&D usage and development purposes.

  • Page 31: Quick Start Guide

    2. Install FLIR ResearchIR Max. 3. Start FLIR ResearchIR Max. When asked for the license key, enter the license key that is printed on the FLIR Re- searchIR Max download card. The card is included with the HSI box. 4. Connect the HSI box to the computer using the provided USB 3 cable.

  • Page 32: Note About Ergonomics

    A note about ergonomics 9.1 General To prevent strain-related injuries, it is important that you hold the camera ergonomically correctly. This section gives advice and examples on how to hold the camera. Note • Always tilt the touch-screen LCD to suit your work position. •...

  • Page 33: Camera Parts

    Camera parts 10.1 View from the right 10.1.1 Figure 10.1.2 Explanation 1. Knob to change the dioptric correction for the viewfinder. 2. Hand strap. 3. Digital zoom button. 4. Save button (push fully down). Note The infrared camera can be configured to autofocus when you push the Save button half-way down.

  • Page 34: View From The Left

    Camera parts 10.2 View from the left 10.2.1 Figure 10.2.2 Explanation 1. Digital camera. 2. Camera lamp. 3. Laser pointer. 4. Infrared lens. 5. Camera lamp. 6. Digital camera. 7. Focusing ring. 8. Programmable button 9. Button to operate the laser pointer. 2.

  • Page 35: View From The Bottom

    Camera parts 10.3 View from the bottom 10.3.1 Figure 10.3.2 Explanation 1. Memory card. Note Empty or use a memory card that has not previously been used in another version or type of camera. The cameras may organize files differently on the memory card.

  • Page 36: View From The Rear

    Camera parts 10.4 View from the rear 10.4.1 Figure 10.4.2 Explanation 1. Sensor that adjusts the touch-screen LCD intensity automatically. button. Function: • Push to switch between touch-screen LCD mode and viewfinder mode. Note This item is dependent on the camera model. 3.
  • Page 37 Camera parts button. Function: • Push to switch between automatic and manual image adjustment mode. 9. Image archive button Function: • Push to open the image archive. • Push and hold for more than 2 seconds to perform a manual non-uniformity cor- rection (NUC).

  • Page 38: Neck Strap Attachment Points

    Camera parts 10.5 Neck strap attachment points 10.5.1 Figure 10.6 Battery condition LED indicator 10.6.1 Figure 10.6.2 Explanation Type of signal Explanation The green LED flashes twice per second. The battery is being charged. The green LED glows continuously. The battery is fully charged. #T559954;...

  • Page 39: Power Led Indicator

    Camera parts 10.7 Power LED indicator 10.7.1 Figure 10.7.2 Explanation Type of signal Explanation The LED is off. The camera is off. The LED is blue. The camera is on. 10.8 Laser pointer 10.8.1 Figure Figure 10.1 This figure shows the difference in position between the laser pointer and the optical center of the infrared lens.

  • Page 40: Laser Warning Label

    Camera parts Note • The symbol is displayed on the screen when the laser pointer is on. • The laser pointer is enabled by a setting. Select (Settings) > Device settings > Lamp & laser > Enable lamp & laser. Note The laser pointer may not be enabled in all markets.

  • Page 41: Screen Elements

    Screen elements 11.1 General 1. Programmable button P4. 2. Programmable button P3. 3. Digital zoom factor. 4. Result table. 5. Status icons. 6. Measurement tool (e.g., spotmeter). 7. Temperature scale. 8. Menu system button. 11.2 Menu system To display the menu system, push the joystick or tap the menu system button 1.

  • Page 42: Status Icons And Indicators

    Screen elements 11.3 Status icons and indicators Battery status indicator. • When the battery status is 20–100%, the indi- cator is white. • When the battery is charging, the indicator is green. • When the battery status is below 20%, the in- dicator is red.
  • Page 43 Screen elements #T559954; r. AT/65353/65353; en-US...

  • Page 44: Navigating The Menu System

    Navigating the menu system 12.1 General The figure above shows the two ways to navigate the menu system in the camera: • Using the index finger or a stylus pen specially designed for capacitive touch usage to navigate the menu system (left). •...

  • Page 45: Handling The Camera

    Handling the camera 13.1 Charging the battery WARNING Make sure that you install the socket-outlet near the equipment and that it is easy to get access to. Note You must charge the battery for 4 hours before you start using the camera for the first time.

  • Page 46: Turning Off The Camera

    Handling the camera 13.3 Turning off the camera 13.3.1 Procedure Follow this procedure: 1. To turn off the camera, push and hold the On/off button for more than 0.5 second. Note Do not remove the battery to turn off the camera. 13.4 Adjusting the viewfinder’s dioptric correction (sharpness) 13.4.1 Figure...

  • Page 47: Adjusting The Angle Of The Lens

    Handling the camera 13.5 Adjusting the angle of the lens 13.5.1 Figure 13.6 Adjusting the infrared camera focus manually 13.6.1 Figure 13.6.2 Procedure Follow this procedure: 1. Do one of the following: • For far focus, rotate the focus ring clockwise (looking at the touch-screen LCD side of the camera).

  • Page 48: Autofocusing The Infrared Camera

    Handling the camera Note • Do not touch the lens surface when you adjust the infrared camera focus manually. If this happens, clean the lens according to the instructions in 29.2 Infrared lens, page 109. • The focus ring can be rotated infinitely, but only a certain amount of rotation is needed when focusing.

  • Page 49: Procedure

    Handling the camera Note • In this mode, the digital camera is used, which means that continuous autofocus will not work in darkness. • When continuous autofocus is enabled, it is not possible to manually adjust the focus by rotating the focus ring. •...

  • Page 50: Using The Digital Zoom Function

    Handling the camera Note The symbol is displayed on the screen when the laser pointer is on. 13.10 Using the digital zoom function 13.10.1 General The current zoom factor is displayed in the upper left corner of the screen. In preview/edit mode, it is possible to pan a zoomed image by touching the screen. 13.10.2 Figure 13.10.3 Procedure Follow this procedure:...
  • Page 51 Handling the camera 1. Programmable button 2. Programmable button 3. Programmable button P3 (function assigned). 4. Programmable button P4. You can assign different functions to the programmable buttons. You can, for example, use a programmable button to easily switch between two settings you use often. You can also choose to define two different setups for saving and previewing: the usual setup for the Save button (which is defined by the Save options and storage settings, see section 28.1.3 Save options &...

  • Page 52: Procedure

    Handling the camera • Switch between two latest palettes: Switch between the two last-used color palettes. For more information, see section 16.5 Changing the color palette, page 64. • Switch temperature range: Cycle through the camera temperature ranges. For more information, see section 28.1.2 Camera temperature range, page 105.

  • Page 53: Moving Files To A Computer

    • Move the files to the computer using a drag-and-drop operation. Note Moving a file using a drag-and-drop operation does not delete the file in the camera. • Import the images into a FLIR Thermography software. #T559954; r. AT/65353/65353; en-US...

  • Page 54: Changing Lenses

    Handling the camera 13.14 Changing lenses Note Do not touch the lens surface when you change lenses. If this happens, clean the lens according to the instructions in 29.2 Infrared lens, page 109. Follow this procedure: 1. Take a firm grip around the outermost part of the lens. 2.
  • Page 55 Handling the camera 3. Carefully pull out the lens from the lens bayonet mount. 4. The infrared detector is now fully exposed. Do not touch this surface. If you see dust on the detector, follow the instructions in 29.3 Infrared detector, page 110. #T559954;...
  • Page 56 Handling the camera 5. Note the index marks on the lens bayonet mount and on the lens. 6. Align the lens correctly to the bayonet mount. Carefully push the lens into position. #T559954; r. AT/65353/65353; en-US...

  • Page 57: Using The 7° Lens

    Handling the camera 7. Rotate the lens 45° clockwise. The lens makes a click when it locks in place. 13.15 Using the 7° lens 13.15.1 General This section applies to the IR lens f=142 mm (7°). CAUTION When you hold the camera, make sure that you support the lens with your hand. The lens is heavy and the joint between the optics and camera housings is not strong enough to hold the lens.

  • Page 58: Mounting The Lens Support

    Handling the camera 3. Align the index mark on the lens with the index mark on the lens bayonet mount on the camera. Carefully push the lens into position, and then rotate the lens 45° clock- wise. The lens makes a click when it locks into place. 13.15.3 Mounting the lens support 1.

  • Page 59: Removing The Lens

    Handling the camera 2. Tighten the screws; first the lens screws, and then the camera screw. 13.15.4 Removing the lens Follow this procedure: 1. Mount the front lens cap on the lens. 2. Untighten the camera screw and the lens screws of the lens support, and then re- move the lens support.

  • Page 60: Using The Close-Up Lens

    Handling the camera 5. Carefully pull out the lens from the bayonet mount. 6. The infrared detector is now fully exposed. Do not touch this surface. If you see dust on the detector, follow the instructions in 29.3 Infrared detector, page 110. 13.16 Using the close-up lens 13.16.1 General If you need to look at small objects very close up, you can attach the close-up lens to the...

  • Page 61: Attaching The Close-Up Lens

    Handling the camera 13.16.2 Attaching the close-up lens Note Do not touch the lens surfaces when you attach the close-up lens. If this happens, clean the lens according to the instructions in 29.2 Infrared lens, page 109. Follow this procedure: 1.

  • Page 62: Removing The Close-Up Lens

    Handling the camera 5. Activate the global parameter External IR window compensation by doing the following: 5.1. Push the joystick to display the menu system. 5.2. Select (Measurement parameters) and push the joystick. This displays a submenu. 5.3. Select (External IR window compensation) and push the joystick. This displays a dialog box.
  • Page 63 Handling the camera 2. Carefully pull out the close-up lens from the infrared lens. 3. Note the grooves on the infrared lens and their counterparts on the inside of the rub- ber protection. 4. Align the rubber protection with the infrared lens. #T559954;...

  • Page 64: Calibrating The Compass

    Handling the camera 5. Push the rubber protection into position. 6. Deactivate the global parameter External IR window compensation by doing the following: 6.1. Push the joystick to display the menu system. 6.2. Select (Measurement parameters) and push the joystick. This displays a submenu.

  • Page 65: Saving And Working With Images

    The image *.jpg file is fully radiometric and saved lossless, which enables full post-proc- essing in image analysis and reporting software from FLIR Systems. There is also a reg- ular *.jpg component (lossy) for convenient viewing in non-FLIR Systems software (e.g., Microsoft Explorer).

  • Page 66: Saving An Image

    UltraMax image. Some FLIR Thermography software has the ability to process UltraMax images. Other FLIR software will treat the image as a regular image.

  • Page 67: Procedure

    Saving and working with images 14.4.2 Procedure Follow this procedure: 1. Push the image archive button . This displays the Gallery with one or more folders. 2. Select a folder and push the joystick. 3. Select the image you want to view and push the joystick. 4.

  • Page 68: Related Topics

    14.7.1 General You can create a PDF report and save it to the memory card. You can then transfer the PDF report to a computer, using for example a FLIR Thermography software, and send the report to a customer. 14.7.2 Naming convention The naming convention for report files is REPORTxxxx.jpg, where xxxx is a unique...

  • Page 69: Zooming An Image

    Saving and working with images 14.8 Zooming an image 14.8.1 General You can zoom an image by using the camera’s digital zoom function. You can do this on live images and on saved images in edit mode. The digital zoom factor is displayed at the top of the screen. 14.8.2 Procedure Follow this procedure: 1.

  • Page 70: Working With The Image Archive

    Working with the image archive 15.1 General When you save an image or video clip, the camera stores the image/video file in the im- age archive on the memory card. You can open an image in the image archive and, for example, select another image mode, apply color alarms, and add measurement tools.

  • Page 71: Changing The Active Folder

    Working with the image archive Follow this procedure: 1. Push the image archive button . This displays the Gallery . 2. On the top toolbar, select the icon and push the joystick. 3. Select the folder to rename and push the joystick. 4.

  • Page 72: Deleting An Image Or Video File

    Working with the image archive Follow this procedure: 1. Push the image archive button . This displays the Gallery . 2. On the top toolbar, select the icon and push the joystick. 3. Select the folder to delete and push the joystick. 4.

  • Page 73: Deleting All Files

    Working with the image archive 4. Use the joystick to select the image and video items you want to delete. You can also select the items by touching the screen. Selected items are marked with a tick. 5. On the right toolbar, select the icon and push the joystick.

  • Page 74: Achieving A Good Image

    Achieving a good image 16.1 General A good image depends on several different functions and settings, although some func- tions and settings affect the image more than others. These are the functions and settings that you need to experiment with: •...

  • Page 75: Example 1

    Achieving a good image In manual mode, you can adjust the image by touching the screen or by using the joy- stick. For more information, see sections 16.3.4 Manual adjustment by touching the screen, page 62 and 16.3.5 Manual adjustment by using the joystick, page 63. •...

  • Page 76: Manual Adjustment By Touching The Screen

    Achieving a good image 16.3.4 Manual adjustment by touching the screen 16.3.4.1 General The touch functionality for manual image adjustments is enabled/disabled by a setting. Select (Settings) > Device settings > User interface options > Manual adjustment us- ing touch > On/Off. When manual image adjustment mode is active, an adjustment wheel is displayed to the right of the temperature scale.

  • Page 77: Manual Adjustment By Using The Joystick

    Achieving a good image 16.3.4.4 Locking the touch screen When you have adjusted the image to levels that allow you to study your area of interest, you can lock the touch screen to prevent further unintentional adjustments. To lock the screen, touch the icon to the left of the temperature scale.

  • Page 78: Changing The Temperature Range

    Achieving a good image 16.4 Changing the temperature range 16.4.1 General The camera is calibrated for different temperature ranges. Available temperature range options are dependent on the camera model. For accurate temperature measurements, you must change the Camera temperature range setting to suit the expected temperature of the object you are inspecting. Note For more information, see section 34 About calibration, page 124.

  • Page 79: Procedure

    Achieving a good image This table explains the different types of color palettes. Iron Arctic Rainbow Rainbow high contrast White hot Black hot Lava 16.5.2 Procedure Follow this procedure: 1. Push the joystick to display the menu system. #T559954; r. AT/65353/65353; en-US...

  • Page 80: Changing The Measurement Parameters

    Achieving a good image 2. Select (Color) and push the joystick. This displays a submenu. 3. Use the joystick to select a different palette. 4. Push the joystick to confirm and exit the menu mode. 16.6 Changing the measurement parameters For accurate measurements, it is important to set the measurement parameters: •...

  • Page 81: Hiding All Overlay

    Achieving a good image 16.8 Hiding all overlay 16.8.1 General The camera overlay consists of overlay graphics and image overlay information. The overlay graphics include items such as measurement tool symbols, result tables, and status icons. The image overlay information, which you activate on the Settings menu, provides additional information such as the date, emissivity, and atmospheric tempera- ture.

  • Page 82: Working With Image Modes

    • For the Thermal MSX, Thermal, and Picture in picture image modes, all thermal and visual information is stored when an image is saved. This means that you can edit the image later, in the image archive or in a FLIR Thermography software, and select any of the image modes.

  • Page 83: Selecting An Image Mode

    Working with image modes Image mode Image Thermal Thermal MSX Picture in picture Digital camera 17.3 Selecting an image mode Follow this procedure: 1. Push the joystick to display the menu system. 2. Select (Image mode) and push the joystick. This displays a submenu. #T559954;...
  • Page 84 Working with image modes 3. Use the joystick to select one of the following: • (Thermal MSX). • (Thermal). • (Picture in picture). • (Digital camera). Note • If the *.csq video format is selected (Settings > Save options & storage > Video compression) and the recording mode Video is selected, it will only be possible to select the image mode Thermal.

  • Page 85: Working With Measurement Tools

    Working with measurement tools 18.1 General To measure a temperature, you can use one or more measurement tools, e.g., a spot- meter or a box. 18.2 Adding/removing measurement tools Follow this procedure: 1. Push the joystick to display the menu system. 2.

  • Page 86: Moving And Resizing A Measurement Tool

    Working with measurement tools 4. Push and hold the joystick. This displays the Edit user preset menu. 5. Select (Add measurement) and push the joystick. This displays a submenu. 6. Use the joystick to select one of the following: • Select (Add spot) to add a spot.

  • Page 87: Moving And Resizing A Box, Circle, Or Line Tool

    Working with measurement tools 18.4.3 Moving and resizing a box, circle, or line tool Note You can also move and resize the measurement tool by touching the screen. Follow this procedure: 1. To select the measurement tool, touch the tool on the screen. The tool is now dis- played with one or more handles.

  • Page 88: Recommended Values

    Working with measurement tools Note There is an Emissivity mode setting, which you can use to enter the emissivity by material instead of by value. Select (Settings) > Device settings > User inter- face options > Emissivity mode > Select from materials table. Emissivity is the most important measurement parameter to set correctly.

  • Page 89: Related Topics

    Working with measurement tools A P next to the measurement tool on the screen indicates that local parameters have been activated for the tool. Follow this procedure: 1. To select the measurement tool, touch the tool on the screen. The tool is now dis- played with one or more handles.

  • Page 90: Procedure

    Working with measurement tools 18.6.2 Procedure Follow this procedure: 1. To select the measurement tool, touch the tool on the screen. The tool is now dis- played with one or more handles. 2. Push the joystick—or touch and hold the tool. This displays a context menu. 3.

  • Page 91: Creating And Setting Up A Difference Calculation

    Working with measurement tools 4. Push the joystick. This displays a submenu. 5. Select (Graph). 6. Push the joystick to toggle the function between inactive and active: • When the icon with the unfilled indicator is displayed, the function is inactive. •...

  • Page 92: Alarm Signals

    Working with measurement tools • Below: Triggers an alarm when the temperature is below the preset alarm temperature. 18.9.3 Alarm signals When an alarm is set, the symbol is displayed in the result table. When an alarm is triggered, the value in the result table is displayed in red (above alarm) or blue (below alarm) and the symbol (above alarm) or (below alarm) is blinking.
  • Page 93 Working with measurement tools 4. In the dialog box, you can define the settings for the alarm. • Alarm condition: The condition that triggers the alarm. Applicable values are Above, Below, or Off. • Select measurement: Applicable settings are the values you have previously de- fined (Max, Min, and/or Avg).

  • Page 94: Working With Color Alarms And Isotherms

    Working with color alarms and isotherms 19.1 Color alarms 19.1.1 General By using color alarms (isotherms), anomalies can easily be discovered in an infrared im- age. The isotherm command applies a contrasting color to all pixels with a temperature above, below, or between the set temperature levels. The camera also features isotherm types that are specific to the building trade: condensation and insulation alarms.

  • Page 95: Setting Up Above, Below, And Interval Alarms

    Working with color alarms and isotherms Image Color alarm Interval alarm Condensation alarm Insulation alarm 19.1.3 Setting up above, below, and interval alarms Follow this procedure: 1. Push the joystick to display the menu system. 2. Select (Color) and push the joystick. This displays a submenu. 3.

  • Page 96: Building Isotherms

    Working with color alarms and isotherms 19.1.4 Building isotherms 19.1.4.1 About the Condensation alarm To detect areas with potential moisture problems, you can use the Condensation alarm. You can set the relative humidity above which the isotherm will colorize the image. 19.1.4.2 About the Insulation alarm The Insulation alarm can detect areas where there may be an insulation deficiency in the building.
  • Page 97 Working with color alarms and isotherms 4. Push the joystick. This displays a dialog box where you can define the settings for the alarm. For the Condensation alarm, the following parameters can be set: • Atmospheric temperature: The current atmospheric temperature. •...

  • Page 98: Annotating Images

    Annotating images 20.1 General You can save additional information with an infrared image by using annotations. Annota- tions make reporting and post-processing more efficient by providing essential informa- tion about the image, e.g., conditions and information about where an image is taken. Annotations are added to the image file, and can be viewed and edited in the image ar- chive, and also when moving files from the camera to reporting software on the computer.

  • Page 99: Procedure

    20.3.3.2 Manually creating a table template 20.3.3.2.1 General A text comment file (*.tcf) is an annotation format that is proprietary to FLIR Systems. It defines a table structure that can be used to add text table annotations to FLIR images.
  • Page 100 Annotating images The camera ships with an example text comment table file: example_text_comment.tcf. The file is stored on the memory card in the subfolder \TextTableTemplates. You can make a copy of the example file and modify it using a text editor such as Microsoft Notepad.

  • Page 101: Adding A Voice Annotation

    A voice annotation is an audio recording that is saved to the infrared image file. The re- cording can be played back in the camera, and in image analysis and reporting software from FLIR Systems. The voice annotation is recorded using a Bluetooth headset. For information on how to pair a headset with the camera, see section 25 Pairing Bluetooth devices, page 101.

  • Page 102: Procedure

    Annotating images 20.5.2 Procedure Follow this procedure: 1. Open the image in the image archive. 2. Push the joystick to display the top toolbar. 3. On the top toolbar, select the icon and push the joystick. 4. On the right toolbar, select the icon and push the joystick.

  • Page 103: Programming The Camera (Time-Lapse)

    Programming the camera (time- lapse) 21.1 General You can program the camera to save images periodically (time-lapse). 21.2 Procedure Follow this procedure: 1. Push the joystick to display the menu system. 2. Select (Recording mode) and push the joystick. This displays a submenu. 3.

  • Page 104: Recording Video Clips

    • Radiometric storage (*csq): A *.csq file supports full radiometry but is only supported by FLIR Systems software. The file does not include any visual image information. With this setting, only Thermal image mode is supported when recording video. If any other image mode is active when Video recording mode is selected, the camera will auto-switch to Thermal image mode.

  • Page 105: Inspection Route

    1. Prepare the inspection route file, using one of the following methods: • FLIR thermography software that has inspection route support. • Your own solution. The FLIR Thermal SDK can be used to build your own export/ import software or to interface your existing asset management system.

  • Page 106: Drop-Down Menu

    Inspection Route ◦ Displays an image icon if there is an image saved for the inspection point. ◦ Displays the status of the inspection point. • Next arrow Tap to go to the next inspection point. • Document icon This icon is displayed if there is a description and/or comment available for the inspec- tion point.

  • Page 107: Performing An Inspection

    Inspection Route Figure 23.1 Figure 23.1 shows an example of the inspection list: • The first inspection route is completed and locked, which is indicated by the check mark to the right. • The second inspection route has started. It includes a total of 91 inspection points, and one of them has been inspected.

  • Page 108: Capturing Inspection Data

    Inspection Route 4. Activate the Inspection Route function by selecting (Settings) > Save options & storage > Inspection route > On. 5. The camera is now ready. 23.3.2 Capturing inspection data Once the camera is prepared, the inspection can start. Note You can turn off the camera in the middle of an inspection.

  • Page 109: Editing Inspection Point Data

    Inspection Route 8. When you have completed the inspection, transfer the inspection results to a com- puter for post-processing. For more information, see section 23.3.9 Transferring in- spection results. 23.3.3 Editing inspection point data You can edit the data for the inspection point displayed by the current point indicator. To go to another inspection point, use the back or next arrow or select the inspection point from the inspection list, see section 23.3.7 Inspection list.

  • Page 110: Inspection List

    Inspection Route 23.3.7 Inspection list In the inspection list, you can see the progress of the inspection routes and review the in- spection point results. To see the progress and review the results, do the following: 1. Tap the current point indicator. This displays a drop-down menu. 2.

  • Page 111: Creating An Inspection Route

    The inspection route file can be created using one of the following methods: • FLIR thermography software that has inspection route support. • Your own solution. The FLIR Thermal SDK can be used to build your own export/im- port software or to interface your existing asset management system.

  • Page 112: Manually Editing An Xml File

    Inspection Route 9. When the inspection route is completed, make sure to copy the XML file on the mem- ory card to a computer for future use. When you start an inspection in the camera, the inspection data will be written to the XML file on the memory card. 23.5.2 Manually editing an XML file An example or empty XML file can be created on the memory card in the camera.

  • Page 113: Screening Alarm

    Screening alarm 24.1 General The screening alarm can be used, for example, at airports to detect passengers with ele- vated body temperatures, which may indicate the presence of a fever. The screening alarm can also be used to detect temperature anomalies in a series of in- spected objects in a similar/fixed setup.
  • Page 114 Screening alarm 7. Aim the camera toward a point of interest. The object should be within the frame of the measurement box. 8. To reset the sampled average, push and hold the programmable button 9. To sample, push the programmable button 10.

  • Page 115: Pairing Bluetooth Devices

    • You can remove a device by selecting the device and then selecting Unpair device. • After adding a METERLiNK device, such as the FLIR MR77 or FLIR DM93, the result from the meter will be visible in the result table and stored with the images. For more information, see section 27 Fetching data from external FLIR meters, page 103.

  • Page 116: Configuring Wi-Fi

    Configuring Wi-Fi 26.1 General Depending on your camera configuration, you can connect the camera to a wireless local area network (WLAN) using Wi-Fi, or let the camera provide Wi-Fi access to other devices. You can connect the camera in two different ways: •...

  • Page 117: Fetching Data From External Flir Meters

    The live value is displayed with a dotted outline. If the screen display for values is full, it is still possible to add more values from the FLIR meter. Added values are then indicated by a box with a number that counts up each time a new value is added.

  • Page 118: Typical Moisture Measurement And Documentation Procedure

    Fetching data from external FLIR meters 4. On the FLIR meter, choose the quantity that you want to use (voltage, current, resist- ance, etc.). Refer to the user documentation for the meter for information on how to do this. Results from the meter will now automatically be displayed in the result table in the top left corner of the infrared camera screen.

  • Page 119: Changing Settings

    ◦ Save & add note: The note annotation tool will be displayed. ◦ Save & add table: The table annotation tool will be displayed. 4. This item is available with the FLIR Inspection Route camera software option. #T559954; r. AT/65353/65353; en-US...

  • Page 120: Device Settings

    ◦ Radiometric storage (*.csq): A CSQ file supports full radiometry but is only sup- ported by FLIR Systems software. The file does not include any visual image infor- mation. With this setting, only the image modes Thermal and Macro are supported when recording video.
  • Page 121 Changing settings ◦ Image overlay information: This setting specifies what image information the cam- era will display as an overlay on the image. For more information, see section 11.5 Image overlay information, page 28. You can select the following information to display: –...
  • Page 122 Changing settings ◦ Reset device settings to factory default...: This setting will affect all camera settings, including regional settings. Saved images will not be affected. The camera will be restarted and you will be prompted to set the regional settings. ◦...

  • Page 123: Cleaning The Camera

    Cleaning the camera 29.1 Camera housing, cables, and other items 29.1.1 Liquids Use one of these liquids: • Warm water • A weak detergent solution 29.1.2 Equipment A soft cloth 29.1.3 Procedure Follow this procedure: 1. Soak the cloth in the liquid. 2.

  • Page 124: Infrared Detector

    Cleaning the camera 29.3 Infrared detector 29.3.1 General Even small amounts of dust on the infrared detector can result in major blemishes in the image. To remove any dust from the detector, follow the procedure below. Note • This section only applies to cameras where removing the lens exposes the infrared detector.

  • Page 125: Mechanical Drawings

    Mechanical drawings [See next page] #T559954; r. AT/65353/65353; en-US...

  • Page 133: Digital I/O Pin Configuration

    Digital I/O pin configuration 31.1 Pin configuration for the Digital I/O connector on the HSI box Function Data IN 1 opto-isolated, 0–1.5 V = low, 3– 25 V = high IN 2 opto-isolated, 0–1.5 V = low, 3– 25 V = high OUT 1 opto-isolated, ON = supply (max.

  • Page 134: Digital I/O Connection Diagram

    Digital I/O connection diagram [See next page] #T559954; r. AT/65353/65353; en-US...

  • Page 136: Ce Declaration Of Conformity

    CE Declaration of conformity [See next page] #T559954; r. AT/65353/65353; en-US...

  • Page 138: About Calibration

    34.3 Camera calibration at FLIR Systems Without calibration, an infrared camera would not be able to measure either radiance or temperature. At FLIR Systems, the calibration of uncooled microbolometer cameras with a measurement capability is carried out during both production and service. Cooled cam- eras with photon detectors are often calibrated by the user with special software.

  • Page 139: The Differences Between A Calibration Performed By A User And That Performed Directly At Flir Systems

    The calibration information, no matter if the calibration is done by FLIR Systems or the user, is stored in calibration curves, which are expressed by mathematical functions. As...

  • Page 140: Non-Uniformity Correction

    About calibration Calibration is also a prerequisite for adjustment, which is the set of operations carried out on a measuring system such that the system provides prescribed indications corre- sponding to given values of quantities to be measured, typically obtained from measure- ment standards.

  • Page 141: About Flir Systems

    • Extech Instruments (2007) Figure 35.1 Patent documents from the early 1960s FLIR Systems has three manufacturing plants in the United States (Portland, OR, Boston, MA, Santa Barbara, CA) and one in Sweden (Stockholm). Since 2007 there is also a manufacturing plant in Tallinn, Estonia.

  • Page 142: More Than Just An Infrared Camera

    35.1 More than just an infrared camera At FLIR Systems we recognize that our job is to go beyond just producing the best infra- red camera systems. We are committed to enabling all users of our infrared camera sys- tems to work more productively by providing them with the most powerful camera–...

  • Page 143: Supporting Our Customers

    35.3 Supporting our customers FLIR Systems operates a worldwide service network to keep your camera running at all times. If you discover a problem with your camera, local service centers have all the equipment and expertise to solve it within the shortest possible time.
  • Page 144 #T559954; r. AT/65353/65353; en-US...
  • Page 146 Disclaimer Specifications subject to change without further notice. Models and accessories subject to regional market considerations. License procedures may apply. Products described herein may be subject to US Export Regulations. Please refer to exportquestions@flir.com with any questions. Publ. No.: T559954...

This manual is also suitable for:

T1020725010101725010102725010103

Table of Contents
