Chapter 2 Install Your Product

2.1 Plug in Power

RGBlink mini+ is packaged with a 12V power link cable and two standard power plugs for British and Australian
standards.
When linking the power supply, please check the power supply standard used in your country/region. If you are
using a power supply that does not have a lock, please tighten the power connector of the device to ensure the
.
stability of the mini+'s power supply
Connect mini+ to power plug by the link cable Tighten the power connector

2.2 Turn on Your mini+

The device will enter to the boot interface automatically after being powered on.
2.3 Connect HDMI Input
You can use any camera, computer or other HDMI device as the input source of the mini+. It supports up to 1080P
standard and 4 sources of different formats and resolutions at the same time. If you are using interlaced
signal,mini+ supports one de-interlacement to all interlaced signals. This step is automatically recognized by the
mini+ and does not need to be done manually. You can see the resolution of the input signal in the mini+'s TFT
screen.
