OPERATING MANUAL
REAR FLAIL MOWERS
ON A PANTOGRAPH
KBRP 160 – 1.60 m
KBRP 200 – 2.00 m
IN372EN002
Serial No.:
2011.09.27
Version 002
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SaMASZ KBRP 160
Summary of Contents for SaMASZ KBRP 160
- Page 1 NIP 966-159-29-76 tel. (+48) (85) 654 45 84 fax (+48) (85) 664 70 41 e-mail: samasz@samasz.pl www.samasz.pl OPERATING MANUAL REAR FLAIL MOWERS ON A PANTOGRAPH KBRP 160 – 1.60 m KBRP 200 – 2.00 m IN372EN002 Serial No.: 2011.09.27 Version 002...
- Page 2 IT IS FORBIDDEN TO OPERATE THE MOWER WITH UNAUTHORIZED PERSONELL CLOSER THAN 50 M IT IS FORBIDDEN TO START UP THE MOWER BEFORE IT IS IN THE OPERATING POSITION Written by: mgr Łukasz Łapiński Technical assistance: mgr inż. Artur Drożyner...
-
Page 3: Table Of Contents
Rear flail mower on a pantograph Operating manual KBRP 160; KBRP 200 Table of contents page 1. IDENTIFICATION........................2 2. INTRODUCTION ......................... 2 3. MOWER'S INTENDED USE ...................... 3 3.1. Technical data ..........................3 3.2. Construction and operation ......................4 3.3. -
Page 4: Identification
Rear flail mower on a pantograph Operating manual KBRP 160; KBRP 200 1. IDENTIFICATION The mower identification plate is affixed permanently to the body of the mower shown on Pic. 1. Pic. 1. Location of the identification plate Pic. 2. Identification plate... -
Page 5: Mower's Intended Use
Unauthorized modification of the mower may release the manufacturer from responsibility for any resulting malfunctions or damages. The KBRP 160 mower should be used with class II tractors with 70 HP of power. The KBRP 200 mower should be used with class II tractors with 80 HP of power. -
Page 6: Construction And Operation
Rear flail mower on a pantograph Operating manual KBRP 160; KBRP 200 3.2. Construction and operation Pic. 3. General view of rear flail mower KBRP 200 mounted on a pantograph 1 – Suspension frame; 2 – Pantograph arm 3 – Belt drive;... -
Page 7: Equipment And Spare Parts
Rear flail mower on a pantograph Operating manual KBRP 160; KBRP 200 3.3. Equipment and spare parts The mowers are sold with the following standard equipment: warranty card, operating manual and spare parts catalogue, flail blades 2 pcs., the articulated telescopic shaft, hydraulic hardware meaning: - hydraulic hoses 4 pcs. -
Page 8: Safety Rules And Warnings
Rear flail mower on a pantograph Operating manual KBRP 160; KBRP 200 4. SAFETY RULES AND WARNINGS 4.1. General rules The front axle of the driving tractor should be adequately loaded to maintain balance. If necessary use front wheel weights. -
Page 9: Transport
Rear flail mower on a pantograph Operating manual KBRP 160; KBRP 200 It is forbidden to operate the mower in reverse. Never climb on top of the mower. Lifting the mower on the hitch of the tractor while the drive is engaged and the discs are spinning is forbidden. -
Page 10: Operating Elements
Use only articulated telescopic shafts recommended by the manufacturer of the mower. 4.5. Residual risk Despite the fact that the manufacturer of the mower SaMASZ Bialystok, in order to eliminate danger, assumes responsibility for the design and construction of its mowers, some elements of risk are unavoidable during mower operation. - Page 11 Rear flail mower on a pantograph Operating manual KBRP 160; KBRP 200 WARNING: Residual risk is the result of inappropriate behavior of the operator. 4. Prohibitions Please remember that following activities are prohibited during mower operation: do not clear, adjust or repair the mower while it is in motion,...
-
Page 12: Warning Signs And Their Meaning
Rear flail mower on a pantograph Operating manual KBRP 160; KBRP 200 4.6. Warning signs and their meaning ATTENTION: a) all warning signs (labels) should be clean and legible, b) in the event of loss or damage of the sign (label) they should be replaced, c) signs (labels) can be purchased from the manufacturer. -
Page 13: Operation And Construction Of The Hydraulic Safety
5. OPERATING THE MOWER 5.1. Connecting the mower to the tractor The KBRP 160 mower should be used with class II tractors with at least 70 HP. The KBRP 200 should be used with class II tractors with at least 80 HP. -
Page 14: Preparing The Mower For Transport
Rear flail mower on a pantograph Operating manual KBRP 160; KBRP 200 5.2. Preparing the mower for transport Preparing the rear flail mower mounted on the tractor for transport - movement on roads - requires the following: mount the suspension frame on the lifting arms of the tractor, lift the mower on the lifting arms of the tractor using the hydraulic hoist so that the pins of the uspension frame are at least 50 cm above the ground (Pic. -
Page 15: Preparing The Mower For Transport Over Public Roadways
Rear flail mower on a pantograph Operating manual KBRP 160; KBRP 200 5.3. Preparing the mower for transport over public roadways Road safety and current traffic laws demand that during transport the mower be equipped with the following items: portable light unit consisting of a panel installed in the socket of the upper guard (not included with the mower). -
Page 16: Preparing The Mower For Operation
Rear flail mower on a pantograph Operating manual KBRP 160; KBRP 200 5.6. Preparing the mower for operation Before starting work please observe the above-mentioned instructions. Upon completion of these tasks the mower is considered ready for operation and the following can be done:... -
Page 17: Mounting And Settings
Rear flail mower on a pantograph Operating manual KBRP 160; KBRP 200 Pic. 12. Tilting range of the KBRP mower Pic. 13. Operating reach of the KBRP mowers Tab. 3. Operating reach of the KBRP mowers (mm). Pic 12 and 13... -
Page 18: Maintenance
Rear flail mower on a pantograph Operating manual KBRP 160; KBRP 200 6.2. Maintenance 6.2.1. Inspecting the tautness of the belts of the belt drive The tautness of the belts in the belt drive should be periodically inspected. In order to inspect the tautness of the belts remove the cover P and manually check the tautness. -
Page 19: End Of Season Maintenance
Rear flail mower on a pantograph Operating manual KBRP 160; KBRP 200 6.2.4. End of season maintenance After the end of mowing season the mower should be carefully cleaned and washed and after drying all working surfaces and suspension pins should be protected from rust by lubricating with grease. -
Page 20: Malfunctions And Thier Correction
Rear flail mower on a pantograph Operating manual KBRP 160; KBRP 200 Lubrication point Pic. 18. Bearing and joint lubrication points using STP grease 8. MALFUNCTIONS AND THIER CORRECTION Malfunction Cause Recommendations Adjust belt tautness using the bolt according to the instructions. -
Page 21: Warranty Card
Rear flail mower on a pantograph Operating manual KBRP 160; KBRP 200 10. WARRANTY CARD REAR FLAIL MOWER MOUNTED ON A PANTOGRAPH: Serial number Date of manufacture Guarantor seal Controller signature Date of sale Seller seal Seller signature This product has been checked and deemed fully serviceable and cleared for use. -
Page 22: Record Of Warranty Repairs
Rear flail mower on a pantograph Operating manual KBRP 160; KBRP 200 6. The buyer will be charged a service fee if the manufacturer assesses that the product being claimed under warranty has no faults or malfunctions confirmed by independent expert.
