OPERATOR'S MANUAL
FRONT DRUM MOWERS
K2BF 210 - 2,10 m - 2 Drums
K4BF 265 - 2,65 m - 4 Drums
K4BF 300 - 3,00 m - 4 Drums
IN033EN006
2011.09.13
EDITION NO 6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the K2BF 210 and is the answer not in the manual?

Questions and answers

Related Manuals for SaMASZ K2BF 210

Summary of Contents for SaMASZ K2BF 210

  • Page 1 (+48) (85) 664-70-41 e-mail: samasz@samasz.pl www.samasz.pl OPERATOR’S MANUAL FRONT DRUM MOWERS K2BF 210 - 2,10 m - 2 Drums K4BF 265 - 2,65 m - 4 Drums K4BF 300 - 3,00 m - 4 Drums IN033EN006 2011.09.13 EDITION NO 6...
  • Page 2 DANGER OPERATING WHEN ANY PERSON REMAINS IN THE DANGER AREA OF 50 m DANGER MOWER HAS TO BE SET HORIZONTALLY TO THE GROUND (GRASS)

  • Page 3: Table Of Contents

    Front drum mower Operator’s manual K2BF 210; K4BF 265; K4BF 300 Contents page INTRODUCTION ....................2 TECHNICAL DATA ................... 2 2.1. Specifications ........................... 2 2.2. Design and working principle ....................4 2.3. Proper use ..........................4 2.4. Standard equipment and spare parts: ..................5 SAFETY ADVICE ....................

  • Page 4: Introduction

    Front drum mower Operator’s manual K2BF 210; K4BF 265; K4BF 300 1. INTRODUCTION Operator’s manual is attached to every machine in order that the operator can familiarize himself with design, working principles, service and adjustment of the mower. The user of the mower should be familiar with common safety rules and procedures.
  • Page 5 Front drum mower Operator’s manual K2BF 210; K4BF 265; K4BF 300 Fig. 1. Data plate Kosiarka czterobębnowa Z 010/7 K4BF 265 K2BF 210 Kosiarka dwubębnowa Z 010/8 K4BF 300 Kosiarka czterobębnowa Z 007 The components of the mower Fig. 2.

  • Page 6: Design And Working Principle

    Over the cutting unit, there is a safety guard (pos. 8) with safety curtain, fastened to the main frame. 2.3. Proper use SaMASZ front drum mower is designed for mowing standing grass in meadows and in stone free fields. It is a machine for hay and green fodder production. CAUTION: Use of the mower for other purposes than the above mentioned is forbidden.

  • Page 7: Standard Equipment And Spare Parts

    5) (extra payment), Optional extra equipment: warning plates with combined lights and reflectors, warning triangle, tractor’s triangle. Tab. 2. PTO shafts for SaMASZ front drum mowers. Manufacturer - Bondioli & Pavesi PTO shaft Mower Symbol Moment Power Notes K4BF –...

  • Page 8: Safety Advice

    PTO direction (OET tractors), please do the following: Mower K4BF 210; K4BF 265; K4BF 300: remove intersecting axis gear (Tab. 1 pos. 14 – mower K2BF 210; tab 1 pos. 16 – mower K4BF 265; tab. 1 pos. 17 – mower K4BF 300) rotate it a 180 remove holders (Tab.

  • Page 9: Warning Decals

    Front drum mower Operator’s manual K2BF 210; K4BF 265; K4BF 300 CAUTION: All service and repair operations must be done only after the tractor engine has been stopped, all rotating parts have come to the complete standstill and the sliding saucers are on the ground 3.1.

  • Page 10: Transport And Working Positions

    During operation check mounting of the mower. The mower is mounted on the triangle which is connected to the tractor’s front 3-point linkage (the triangle cat. II is NOT a part of standard equipment – it can be ordered from SaMASZ as optional extra equipment).

  • Page 11: Adjusting The Clearance Between Triangle's Hook And Lock

    Front drum mower Operator’s manual K2BF 210; K4BF 265; K4BF 300 4.2. Adjusting the clearance between triangle’s hook and lock After the mower has been mounted and lifted and the clearance between triangle’s hook and lock has more than 1 mm (fig. 6a), please do the following: Trójkąt Mower’s...

  • Page 12: Mounting Pto Shaft

    Overlapping of the tubes must be at of the length of the tubes during operation. If the attached PTO shaft does not meet these conditions, ask SaMASZ to replace it. If the PTO shaft is damaged due to inappropriate length the warranty will be lost. WARNING: Operate machinery only with the articulated telescopic shafts designated for use with that machinery.

  • Page 13: Pto Shaft's Length Adjustment

    Front drum mower Operator’s manual K2BF 210; K4BF 265; K4BF 300 WARNING: PTO shaft’s end with friction clutch should be mounted to the tractor and with overrunning clutch to the mower. 4.6. PTO shaft’s length adjustment In case there is a necessity to shorten PTO shaft, please make it according to the drawings 9a and 9b.

  • Page 14: Mounting And Adjustments

    Front drum mower Operator’s manual K2BF 210; K4BF 265; K4BF 300 5. MOUNTING AND ADJUSTMENTS 5.1. Mounting and timing of the knives K2BF 210 K4BF 265 Kosiarka dwubębnowa Z 010/8 K4BF 300 Kosiarka czterobębnowa Z 007 Fig. 11. Timing of the knives on the mowing saucers...

  • Page 15: Maintenance And Service

    Front drum mower Operator’s manual K2BF 210; K4BF 265; K4BF 300 Reduced version Standard version Support saucer Distance ring Fastening bolts Sliding saucer Fig. 13. Adjusting the cutting height by fitting or removing the distance ring CAUTION: When mounting additional distance rings longer bolts - M10x35 must be used and tightened to a torque of 55 Nm.

  • Page 16: Lubrication Instruction

    Front drum mower Operator’s manual K2BF 210; K4BF 265; K4BF 300 5.3.2. After-season maintenance At the end of the season the mower should be cleaned, washed and dried. Carefully grease unpainted surfaces and 3-point linkage pins. After that the following work should be carried out: remove any traces of rust and paint the area affected.

  • Page 17: Defects And Their Repairs

    Front drum mower Operator’s manual K2BF 210; K4BF 265; K4BF 300 7. DEFECTS AND THEIR REPAIRS CAUTION: Before disassembly the mower should be disconnected from the tractor 7.1. Disassembly Before starting any repair or service the mower should be cleaned and any grass or dirt removed.

  • Page 18: Warranty Card

    Front drum mower Operator’s manual K2BF 210; K4BF 265; K4BF 300 9. WARRANTY CARD FRONT DRUM MOWERS: Serial number Date of manufacture Manufacturer’s stamp QC signature Date of purchase Dealer’s stamp Dealer’s signature The product quality has been checked and meets the required standards and regulations. The mower...

  • Page 19: Warranty Repairs Record

    Front drum mower Operator’s manual K2BF 210; K4BF 265; K4BF 300 c) lack of required inscriptions or arbitrary inscriptions in the warranty card, d) use of the mower not in accordance with operator’s manual or for incorrect purpose, CAUTION: Please ask your dealer to fill the warranty card with proper dates, stamps and signature when purchasing.

This manual is also suitable for:

K4bf 265K4bf 300

Table of Contents
