SaMASZ KDC 300 W Operator's Manual

Rear trailed disc mower
Hide thumbs Also See for KDC 300 W:
Table of Contents

Advertisement

Quick Links

Download this manual
OPERATOR'S MANUAL
REAR TRAILED DISC
MOWER
KDC 300 W - 3,0 m
KDC 340 W - 3,4 m
KDC 340 S - 3,4 m
W – Mowers with roller conditioner
S – Mowers with tine conditioner
SaMASZ Sp. z o.o.
Poland, 15-161 Białystok, ul. Trawiasta 15
Rok założenia – 1984
tel. (+48) (85) 654 45 84
fax (+48) (85) 664 70 41
e-mail: samasz@samasz.pl
EDITION NO. 0
NIP 966-159-29-76
www.samasz.pl
IN236EN000
01.05.2007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KDC 300 W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SaMASZ KDC 300 W

Summary of Contents for SaMASZ KDC 300 W

  • Page 1 OPERATOR’S MANUAL REAR TRAILED DISC MOWER KDC 300 W - 3,0 m KDC 340 W - 3,4 m KDC 340 S - 3,4 m W – Mowers with roller conditioner S – Mowers with tine conditioner IN236EN000 01.05.2007...
  • Page 2 Recommended inclination of cutterbar towards the ground is 5°. It is allowed to work in horizontal position. Different position may damage the cutterbar. DANGER TURNING THE DRIVE ON, IF THE MOWER IS NOT IN WORKING POSITION DANGER OPERATING WHEN ANY PERSON REMAINS IN THE DANGER AREA OF 50 m Written and translated by: Łukasz Łapiński...

  • Page 3: Table Of Contents

    Rear trailed disc mowers Operator’s manual KDC 300 S/W; KDC 340 S/W 1. INTRODUCTION ........................2 2. TECHNICAL DATA ........................2 2.1. Specifications ......................... 2 2.2. Design and working principle ....................3 2.3. Proper use ..........................5 2.4. Standard equipment and spare parts ..................5 3.

  • Page 4: Introduction

    Rear trailed disc mowers Operator’s manual KDC 300 S/W; KDC 340 S/W 1. INTRODUCTION Operator’s manual is attached to every machine in order that the operator can familiarize himself with design, working principles, service and adjustment of the mower. The user of the mower should be familiar with common safety rules and procedures.

  • Page 5: Design And Working Principle

    2.2. Design and working principle Fig. 1. Data plate Fig. 2a. Parts of SaMASZ rear trailed disc mower with tine conditioner KDC 300S and KDC 340S Fig. 2b. Parts of SaMASZ rear trailed disc mower with roller conditioner KDC 300W and KDC 340W...
  • Page 6 Rear trailed disc mowers Operator’s manual KDC 300 S/W; KDC 340 S/W - 4 -...

  • Page 7: Proper Use

    2.3. Proper use SaMASZ rear trailed disc mower with tine/roller conditioner is designed for mowing standing grass on meadows and in stone free fields. It is a machine for hay and green fodder production. Tine/roller conditioner provides effective conditioning and accelerates drying of the forage. Roller conditioner is recommended in case of fragile crops like lucerne (alfalfa).

  • Page 8: Safety Advice

    8 shaft operating hours (Fig. 3). The articulated telescoping shaft should also be lubricated before and after longer periods of disuse. PTO shafts of other brands with equivalent parameters could be used afer SaMASZ permission. CAUTION: Optional extra equipment should be ordered separately.

  • Page 9: Warning Decals

    Rear trailed disc mowers Operator’s manual KDC 300 S/W; KDC 340 S/W CAUTION: All service and repair operations must be done only after the tractor engine has been stopped, all rotating parts have come to the complete standstill and the cutterbar is on the ground. CAUTION: Be certain that children and animals are at a safe distance away from the machine.

  • Page 10: Transport And Working Positions

    Rear trailed disc mowers Operator’s manual KDC 300 S/W; KDC 340 S/W 7. N-2 8. N-9 9. N-28 Caution – cutting knives. CAUTION: rotor Approach during operation is forbidden! 10. P-2 4. TRANSPORT AND WORKING POSITIONS 4.1. Attaching the mower to the tractor The mower is connected to lower links of tractor’s 3-point linkage.
  • Page 11 Rear trailed disc mowers Operator’s manual KDC 300 S/W; KDC 340 S/W CAUTION: During transport the shut-off valves of mower’s hydraulic lift should always be closed. It protects the mower against incidental falling in case of hydraulic failure. Fig. 5a. Mower’s side safety guard lifted for transport Zawory hydrauliczne Fig.

  • Page 12: Mounting Pto Shaft

    Rear trailed disc mowers Operator’s manual KDC 300 S/W; KDC 340 S/W Fig. 6b. Rear trailed disc mower in its transport position 4.3. Mounting PTO shaft PTO shaft’s end with friction clutch should be mounted on mower’s side. When connecting PTO shaft between tractor and mower make sure, that external guard tube of the shaft is on the tracor’s side.

  • Page 13: Preparing The Mower For Work

    Rear trailed disc mowers Operator’s manual KDC 300 S/W; KDC 340 S/W Preparing the mower for work 4.4. Before the work begins, please carry out the procedures included in the previous chapters and after that the mower is considered to be ready for work, and then: lower the mower until the cutterbar comes into contact with the ground, by means of upper regulating bar of the mower, adjust the cutterbar’s height and inclination towards the ground.

  • Page 14: Mounting And Adjustments

    Rear trailed disc mowers Operator’s manual KDC 300 S/W; KDC 340 S/W Fig. 8a. Rear trailed disc mower in its working position Hydraulic cylinders Fig. 8b. Rear trailed disc mower in its working position 5. MOUNTING AND ADJUSTMENTS Mounting and timing of the knives 5.1.

  • Page 15: Replacing The Knives

    Rear trailed disc mowers Operator’s manual KDC 300 S/W; KDC 340 S/W 5.2. Replacing the knives Worn and/or damaged knives should be immediately replaced (Fig. 13). Replace knives, if necessary, only in sets. Make sure all knives in a set are of the same length and weight. The knife holders must not be damaged or deformed.

  • Page 16: Adjusting The Space Between Tine Conditioner's Mask And Its Shaft

    Rear trailed disc mowers Operator’s manual KDC 300 S/W; KDC 340 S/W CAUTION: Different mounting of the knives will block the mower. When mounting pay particular attention to loose rotation of the knife on the knife holder pin. CAUTION: Because of high discs rpm, knife holders should be changed in sets of the same weight –...

  • Page 17: Adjusting Force Of The Pressure Of Roller Conditioner

    Rear trailed disc mowers Operator’s manual KDC 300 S/W; KDC 340 S/W 1. Conditioner’s shaft 2. Self-locking nut M16 z. cl. 10.9 3. Washer ∅16 4. Rubber insert 5. Tine 6. Bolt M16x90 cl. 10.9 Fig. 14. Parts of tine conditioner 5.5.

  • Page 18: Checking The Tension Of Tine And Roller Conditioners' Driving Chain

    Rear trailed disc mowers Operator’s manual KDC 300 S/W; KDC 340 S/W 5.6.2. Checking the tension of tine and roller conditioners’ driving chain (Models KDC 300 S/W and KDC 340 S/W) Drive from PTO shaft is transmitted by means of driving chain on the conditioner. The tensioner provides the constant tension of the chain and is regulated by the nut N (Fig.

  • Page 19: After-Season Maintenance

    Rear trailed disc mowers Operator’s manual KDC 300 S/W; KDC 340 S/W 5.6.4. After-season maintenance At the end of the season the mower should be cleaned, washed and dried. Carefully grease unpainted surfaces and 3-point linkage pins. After that the following work should be carried out: remove any traces of rust and paint the area affected, check lubrication of intersecting axis gear and cutterbar.

  • Page 20: Roller Conditioner's Gearbox

    Rear trailed disc mowers Operator’s manual KDC 300 S/W; KDC 340 S/W Fig. 20a. Intersecting axis gears’s lubrication points Fig. 20b. Intersecting axis gear lubrication point Tab. 4. Oil capacities Model Oil capacity [l] Oil type Lubrication frequency (acc. to ISO 3448 oil viscosity grade : Once every 3 seasons All models about 1...

  • Page 21: Bearings And Joints

    Rear trailed disc mowers Operator’s manual KDC 300 S/W; KDC 340 S/W Tab. 6. Oil capacities Oil capacity Models Oil type Lubrication frequency Once every 3 seasons All models 0,\.5 80W90 (if working intensively) Fig. 21. Roller conditioner’s gearbox lubrication points Bearings and joints 6.4.
  • Page 22 Rear trailed disc mowers Operator’s manual KDC 300 S/W; KDC 340 S/W Lubrication point Lubrication points Fig. 24. Bearing lubrication point Fig. 23. Bearing lubrication points Lubrication point Fig. 26. Tensioner lubrication point - 20 -...

  • Page 23: Defects And Their Repairs

    Rear trailed disc mowers Operator’s manual KDC 300 S/W; KDC 340 S/W 7. DEFECTS AND THEIR REPAIRS Tab. 5. Defects and their repair Defect Reason Repair Worn knives Replace knives Put on knives strictly acc. to Improperly mounted knives instructions. Reduce PTO rpm (recommended Too high PTO rpm 1800-2000 rpm)

  • Page 24: Warranty Card

    2. The warranty period is for two years from the date of sale to the purchaser, stated above. 3. Any repair which is subject to warranty should be carried out by an authorised SaMASZ dealer. Upon completion of the repair the dealer must submit a warranty claim within 14 days.

  • Page 25: Warranty Repairs Record

    Rear trailed disc mowers Operator’s manual KDC 300 S/W; KDC 340 S/W c) lack of needed records in the warranty card or filling in the warranty card independently, d) use of the mower not in accordance with operator’s manual or for incorrect purpose, CAUTION: Please ask your dealer to complete and return the warranty card,...
