2. SETTING UP THE ADV7282-M EVALUATION BOARD

The Analog Devices (ADI) DVP Eval program and ADV7282-M script files are needed to operate the ADV7282-M evaluation board. The
DVP Eval program and ADV7282-M script files are available on an ADI File Transfer Protocol (FTP) site.
The following setup process is recommended, and is described in detail in Section
1.

Download and install an FTP client.

2. Download the DVP Eval program and ADV7282-M script files from the ADI FTP site.
3. Install the DVP Eval program.
4. Load the ADV7282-M script files.
5. Power up the ADV7282-M evaluation board.
6. Program the ADV7282-M evaluation board.
2.1. DOWNLOAD AND INSTALL AN FTP CLIENT
Download and install an FTP client such as FileZilla in order to access the ADI FTP site.
1. Go to the http://filezilla-project.org/download.php?type=client
2. Download the FileZilla FTP client .exe installation file.
3. When the download is completed, run the .exe installation file and follow the onscreen instructions.

2.2. DOWNLOAD ADV7282-M FILES FROM ADI FTP SITE

The DVP Eval program and ADV7282-M script files are available on the ADI FTP site.
1. Open the FTP client, for example, FileZilla.
2. A quick connect bar appears near the top of the FileZilla client window. Enter the following information. (Note that the boxes
are case sensitive.)
a. In the Host box, enter ftp.analog.com.
In the Username box, enter adv728x.
b.
In the Password box enter1dN62jy.
c.
Leave the Port box blank.
d.
Press the Quickconnect button.
3.
FileZilla then shows two panes (refer to
pane displays the Remote Site Pane (that is, the ADI FTP site).
Rev. A, March 2013
website.
Figure 2). The left pane displays the Local Site Pane (that is, your computer). The right
6
ADV7282-M Installation Guide
2.1 to Section 2.6.
