Advantage Controls MegaTron XS Quick Steps page 2

Upgrading MegaTron XS to "H" Communication Card
Step 5:
Select COMMUNICATIONS, and in this pop-up
use the up arrow until "Advantage Eth" is shown.
Press Enter to accept.
>COM CARD SETUP<
COMMUNICATIONS
MAC ADDRESS
WRITE ACCESS
WIFI
>COM CARD SETUP<
COMMUNICATIONS
COM CARD TYPE (ADVANTAGE ETH)
- > ADVANTAGE ETH
MAC ADDRESS
WRITE ACCESS PRESS UP/DOWN KEYS TO CHANGE
PRESS ENTER TO ACCEPT
WIFI
Step 6:
Select MAC ADDRESS. In this pop-up, use the
arrow keys to enter the factory provided MAC
address for the serial number of your controller.
Press Enter to accept.
Note: If a new communications card was provided
with your upgrade the MAC address can be found
on a sticker on the card. If the MAC address is
missing contact Advantage Controls' customer
service and ask for the factory assigned MAC
address for your controller's serial number.
>COM CARD SETUP<
COMMUNICATIONS
MAC ADDRESS
WRITE ACCESS
WIFI
>COM CARD SETUP<
COMMUNICATIONS
ETHERNET MAC ADDRESS
E4:38:F2:00:00:07
MAC ADDRESS
USE ARROW KETS TO CHANGE, PRESS
WRITE ACCESS
ENTER TOA CCEPT OR BACK TO ERASE.
WIFI
Step 7:
Press the Set-Up/Run key after making the
Factory setting changes to save changes.
MegaTron Quick Steps
Step 8:
Install new model / serial number label on side of controller
over old label.
Step 9:
Navigate to the CONFIGURE menu and select
NETWORK and review network settings to insure that
they are properly configured to for the controller to
communicate with WebAdv3. Follow the instructions
provided in the WebAdvantage 3 Migration Quick Steps.
SETPOINTS
CALIBRATION
TIMERS
CUSTOMIZE
ALARMS
PASSWORD
RELAYS
HISTORY
FLOW SW
Step 10:
Register your controller with Advantage Controls
following the supplied User ID Setup Quick Steps if it is
not already registered.
>HOME SETUP<
DATE/TIME
CONFIGURE
HISTORY
WATER METER
RELAYS
>CONFIGURE<
CONTRAST
TEMP SCALE
NETWORK
SYS INFO
FACTORY
