Launch and use the BACnet Configuration Tool

1. Navigate to the BACnet Configuration Tool (Start/
Programs/DaikinApplied/Chiller BACnet Configuration
Tool) or double-click on the desktop icon, if present.
2. When the Configuration Tool opens, the BACnet MAC
Layer Select dialog box appears
3. Select both BACnet MS/TP and No Router options and
click OK.
Figure 16: BACnet MAC Layer Select Dialog Box
NOTE: If you have trouble opening the MS/TP portion of
the BACnet Configuration Tool, make sure the COM
port on the PC is available and working properly,
then verify that the BACnet Configuration Tool is
using the same COM port. The default COM Port for
the Configuration Tool is 1. See
additional tips.
Table 6: Configuration Tool Default Values
Property
Communication Port
Baud Rate
MS/TP Station Address
Max Master
Max Info Frames
4. Verify that the Daikin Applied BACnet Configuration Win7
v2.30 or newer BACnet Device appears and the BACnet
Device tab is selected
2.30. The Device tab is the primary location for setting
network parameters.

Set Network Parameters

It is now possible to set the Device Instance Number, MS/TP
Station Address (i.e. MAC Address), Max Master, and Baud
Rate (in that order). Table 7
parameters, defaults, and descriptions.
NOTE: BACnet communication modules with software
application versions prior to 2.0 and firmware
revision AmBCM-16 - BmBCM-485-15g support 62
BACnet objects. BACnet communication modules
with software application versions 2.0 (AmBCM-16
- BmBCM-485-15g) and newer support 131 BACnet
objects. This difference in number of objects is visible
when reading the object lists as described in the
following section.
IM 906-4 • MICROTECH II CHILLER UNIT CONTROLLER
(Figure 16).
Troubleshooting
Default Values
COM1
38400
1
127
10
(Figure 17). The latest version is
shows the full list of available
1. Enter the communication module's current
Device Instance in the upper left of the screen
(Figure 17, box #1).
2. Select Read Object List
BACnet Configuration Tool is communicating with the
module, it counts from 0 to 131 (or 62) as shown in
Figure 17, box #3.
Figure 17: Initiate Communications
for
3. After the Configuration Tool has successfully counted
from 0 to 131 (or 62), press the Read button in the upper
left portion of the screen.
4. Verify that the Read/Write Status field counts up to
100%. Once this is complete, the MS/TP Station Address
and Max Master fields become populated with values
(Figure 18).
Figure 18: Configuration Tool Communicating Properly
14
Network Configuration
(Figure 18, box #2). If the
